Quick Links

Download this manual
InteliATS2 70
SW version 1.2.0
Copyright © 2023 ComAp a.s.
Written by Michal Slavata
Prague, Czech Republic
ComAp a.s., U Uranie 1612/14a,
170 00 Prague 7, Czech Republic
Tel: +420 246 012 111
E-mail: info@comap-control.com, www.comap-control.com
Automatic Transfer Switch
Global Guide
Controller
4
9
14
19
44
138
158
159
