ComAp InteliATS2 50 Global Manual

ComAp InteliATS2 50 Global Manual

Automatic transfer switch controller
Hide thumbs

Advertisement

Quick Links

Download this manual
InteliATS2 50
SW version 1.2.0
Copyright © 2023 ComAp a.s.
Written by Michal Slavata
Prague, Czech Republic
ComAp a.s., U Uranie 1612/14a,
170 00 Prague 7, Czech Republic
Tel: +420 246 012 111
E-mail: info@comap-control.com, www.comap-control.com
Automatic Transfer Switch
Global Guide
Controller
4
9
14
19
36
112
132
133

Advertisement

loading
Need help?

Need help?

Do you have a question about the InteliATS2 50 and is the answer not in the manual?

Questions and answers

Related Manuals for ComAp InteliATS2 50

Summary of Contents for ComAp InteliATS2 50

  • Page 1: Table Of Contents

    3 Applications overview 4 Installation and wiring 5 Controller setup 6 Communication 7 Technical data 8 Appendix Copyright © 2023 ComAp a.s. Written by Michal Slavata Prague, Czech Republic ComAp a.s., U Uranie 1612/14a, 170 00 Prague 7, Czech Republic Global Guide Tel: +420 246 012 111 E-mail: info@comap-control.com, www.comap-control.com...

  • Page 2: Alarms Level

    4.4 Recommended wiring 4.4.1 General 2 System overview 4.4.2 Grounding 2.1 General description 4.4.3 Power supply 2.1.1 The key features of InteliATS2 50 4.4.4 Measurement wiring 2.2 True RMS measurement 4.4.5 Binary inputs 2.3 Configurability and monitoring 4.4.6 Binary outputs 2.3.1 Supported configuration and...

  • Page 3: User Button

    5.2.3 Ethernet 6.2.1 SNMP 5.3 Operator Guide 6.2.2 MODBUS-RTU, MODBUS/TCP 5.3.1 Front panel elements 7 Technical data 5.3.2 Display screens 5.3.3 Browsing alarms 8 Appendix 5.3.4 Login 8.1 Controller objects 5.3.5 Production mode 8.1.1 List of controller objects types 5.3.6 Information screen 8.1.2 Setpoints 5.3.7 Language selection 8.1.3 Values...

  • Page 4: Document Information

    AGREEMENT CONDITIONS – COMAP CONTROL SYSTEMS SOFTWARE” (License Agreement) and/or in the “ComAp a.s. Global terms and conditions for sale of Products and provision of Services” (Terms) and/or in the “Standardní podmínky projektů komplexního řešení ke smlouvě o dílo, Standard Conditions for Supply of Complete Solutions”...

  • Page 5: General Security Recommendations And Set Of Measures

    End User's Guide/Manual without the prior written consent of ComAp is expressly prohibited! Even if the prior written consent from ComAp is acquired, ComAp does not take any responsibility for the content, trustworthiness and quality of any such translation. ComAp will deem a translation equal to this End User's Guide/Manual only if it agrees to verify such translation.

  • Page 6: Used Open Source Software

    in closed private network infrastructures. Avoid using MODBUS/TCP in unprotected networks (e.g. Internet). 5. SNMP The SNMP protocol (port UDP/161) version 1 and version 2 are not encrypted. They are intended to be used only in closed private network infrastructures. Avoid using SNMP v1 and v2 in unprotected networks (e.g.

  • Page 7: Functions And Protections

    Note: The controller contains a large number of configurable setpoints, because of this it is impossible to describe all of its functions. Some functions can be changed or have different behavior in different SW versions. Always check the Global guide and New feature list for SW version which is used in a controller. This manual only describes the product and is not guaranteed to be set for your application.

  • Page 8: Symbols In This Manual

    1.8 Symbols in this manual Connector – RS232 male 3 x Phases Grounding male Active RS232 Contact current female sensor Source 1 Contactor AirGate modem Source 2 Controller Alternating Jumper simplified current Starter Module Analog Load Switch – simplified modem manually operated Current Mains Battery...

  • Page 9: System Overview

    2.1 General description This manual describes the InteliATS2 50 controller which is designed for automatic transfer switch applications and provides general information on how to install and operate the InteliATS2 50 controller. This manual is dedicated for Automatic transfer switch panel builders...

  • Page 10: Configuration Parts

    Note: Use the InteliConfig PC software to read, view and modify configuration from the controller or disk and write the new configuration to the controller or disk. The firmware of the controller contains a large number of logical binary inputs and outputs needed for all necessary functions available.

  • Page 11: Pc Tools

    Special graphical controller monitoring software used mainly for commissioning and Source 2 troubleshooting. See more in the WinScope 1000 Reference guide. This tool provides the following functions: Monitoring and archiving of ComAp controller’s parameters and values View of actual / historical trends in controller...

  • Page 12: Plug-In Modules

    2.5 Plug-in Modules 2.5.1 CM3-Ethernet Internet/Ethernet module. 0/100 Mbit interface over RJ45 socket Remote control and monitoring of the controller via InteliConfig, WebSupervisor Modbus TCP support Full SNMP support including traps (v1 & v2c) Active e-mail sending AirGate 2.0 technology support for easy connection –...

  • Page 13: Em-Bio8-Efcp

    2.5.4 EM-BIO8-EFCP Input and binary input/output extension module. Up to 8 additional configurable binary inputs or outputs 6 back to System overview InteliATS 50 Global Guide...

  • Page 14: Applications Overview

    6 back to Table of contents 3.1 Mains-Mains/Gen The InteliATS2 50 firmware comes with 2 archives. One archive is dedicated for Mains-Gen (MG) application. The second one is dedicated for Mains-Mains (MM) application. The name of the firmware contains abbreviation MG or MM for choosing correct archive. To switch between the archives the user has to use InteliConfig ->Firmware Upgrade button.

  • Page 15: Mains-Mains

    3.3 Mains-Mains The typical schematic of Mains-Mains application is shown below. The controller controls two breakers – a Source 1 breaker and a Source 2 breaker. Feedback from the breaker is not necessary. InteliATS2 50 controllers can also work without breaker feedback.

  • Page 16: Applications Using Automatic Transfer Switch

    3.4 Applications using Automatic Transfer Switch 3.4.1 Two position ATS with feedback Automatic remote engine start when the Source 1 fails (AUTO mode, application Mains-Gen) Automatic transfer of the load when the Source 1 fail (AUTO mode, application Mains-Mains) Two-position ATS control with feedback Transfer with power interruption on Source 1 failure Return transfer with power interruption on Source 1 Image 3.4 Two positions ATS with feedback...

  • Page 17: Three Positions Ats With Feedback Without Neutral Control

    3.4.2 Three positions ATS with feedback without Neutral control Automatic remote engine start when the Source 1 fails (AUTO mode, application Mains-Gen) Automatic transfer of the load when the Source 1 fail (AUTO mode, application Mains-Mains) Three-position ATS control with feedbacks, pass through neutral position Transfer with power interruption on Source 1 failure Return transfer with power interruption on Source 1 Image 3.5 Three positions ATS with feedback without Neutral control...

  • Page 18: Three Positions Ats With Feedback With Neutral Control

    3.4.3 Three positions ATS with feedback with Neutral control Automatic remote engine start when the Source 1 fails (AUTO mode, application Mains-Gen) Automatic transfer of the load when the Source 1 fail (AUTO mode, application Mains-Mains) Three-position ATS control with feedbacks Transfer with power interruption on Source 1 failure Return transfer with power interruption on Source 1 Image 3.6 Three positions ATS with feedback with Neutral control 6 back to Applications overview...

  • Page 19: Installation And Wiring

    4 Installation and wiring 4.1 Package content 4.2 Controller installation 4.3 Terminal Diagram 4.4 Recommended wiring 4.5 Plug-in module installation 4.6 Maintenance 6 back to Table of contents 4.1 Package content The package contains: Controller Mounting holders Terminal blocks Note: The package does not contain any communication or extension modules. The required modules should be ordered separately.

  • Page 20: Mounting

    4.2.2 Mounting The controller should be mounted onto the switchboard door. Requested cutout size is 172 × 112 mm. Use the screw holders delivered with the controller to fix the controller into the door as described in pictures below. Recommended torque for holders is 0.15 N·m. Panel door mounting Note: Enclosure Type rating with mounting instruction –...

  • Page 21: Terminal Diagram

    4.3 Terminal Diagram SOURCE2 VOLTAGE SOURCE1 VOLTAGE BINARY MEASUREMENT MEASUREMENT INPUTS BIN1 BIN2 BIN3 BIN4 BIN5 BIN6 Image 4.1 Terminal diagram for InteliATS2 50 BINARY OUTPUTS POWER SUPPLY BOUT1 BATT - BOUT2 BATT + BOUT3 BOUT4 BOUT5 BOUT6 InteliATS 50 Global Guide...

  • Page 22: Recommended Wiring

    4.4 Recommended wiring Voltage inputs 44, 46, 48, 50 Voltage measurement wiring (page 24) Voltage inputs 52, 54, 56, 58 Voltage measurement wiring (page 24) Binary inputs 60-65 Binary inputs (page 32) Binary outputs 11-17 Binary outputs (page 33) Power supply "+", "-"...

  • Page 23: Grounding

    Tightening torque, allowable wire size and type, for the Field-Wiring Terminals: For Mains Voltage, Generator Voltage and Current terminals Specified tightening torque is 0.56 Nm (5.0 In-lbs) use only diameter 0.5 - 2.0 mm (12 - 26 AWG) conductor, rated for 90 °C minimum. For other controller field wiring terminals Specified tightening torque 0.79 nm (7.0 In-lb) Use only diameter 0.5 - 2.0 mm (12 - 26 AWG) conductor,...

  • Page 24: Measurement Wiring

    IMPORTANT: When the controller is powered up only by USB and the USB is disconnected then the actual statistics can be lost. Note: Suitable conductor protection shall be provided in accordance with NFPA 70, Article 240. Note: Low voltage circuits (35 volts or less) shall be supplied from the engine starting battery or an isolated secondary circuit.
  • Page 25 Connection Type: 3 Phase 4 Wires Image 4.2 3 phase application with neutral Note: Fuse on "N" wire is not obligatory but recommended. Image 4.3 Typical 3 Phase 4 Wires generator wiring, also known as 3ph High Y InteliATS 50 Global Guide...
  • Page 26 Image 4.4 3 Phase 4 Wires generator wiring, also known as 3ph Low Y Connection Type: High Leg D Image 4.5 High Leg Delta application Note: Fuse on "N" wire is not obligatory but recommended. InteliATS 50 Global Guide...
  • Page 27 Image 4.6 Typical High Leg D generator wiring Connection Type: 3 Phase 3 Wires Image 4.7 3 phase application without neutral InteliATS 50 Global Guide...
  • Page 28 Image 4.8 Typical 3 Phase 3 Wires generator wiring Connection Type: SplPhL1L2 Image 4.9 Split phase L1L2 application Note: Fuse on "N" wire is not obligatory but recommended. InteliATS 50 Global Guide...
  • Page 29 Image 4.10 Typical Split Phase generator wiring Image 4.11 Typical Split Phase generator wiring InteliATS 50 Global Guide...
  • Page 30 Connection Type: SplPhL1L3 Image 4.12 Split phase L1L3 application Note: Fuse on "N" wire is not obligatory but recommended. Image 4.13 Typical Split Phase generator wiring InteliATS 50 Global Guide...
  • Page 31 Image 4.14 Typical Split Phase generator wiring Connection Type: Mono Phase Image 4.15 Mono phase application Note: Fuse on "N" wire is not obligatory but recommended. InteliATS 50 Global Guide...

  • Page 32: Binary Inputs

    Image 4.16 Typical Mono Phase generator wiring 4.4.5 Binary inputs Use minimally 1 mm cables for wiring of Binary inputs. Image 4.17 Wiring binary inputs Note: The name and function or alarm type for each binary input must be assigned during the configuration. InteliATS 50 Global Guide...

  • Page 33: Binary Outputs

    4.4.6 Binary outputs Use min. 1 mm cables for wiring of binary outputs. Use external relays as indicated on the schematic below for all outputs except those where low-current loads are connected (signalization etc.). IMPORTANT: Use suppression diodes on all relays and other inductive loads! Image 4.18 Binary outputs wiring Note: Every single low current binary output can provide up to 0.5 A of steady current.

  • Page 34: Usb

    IMPORTANT: Suppression diodes are not indicated, but required. 4.4.8 USB This is required for computer connection. Use the shielded USB A-B cable. Image 4.20 USB connection Controller can be also powered by USB (only for service purpose like an uploading firmware, change of configuration etc.).

  • Page 35: Maintenance

    4.6 Maintenance 4.6.1 Backup battery replacement This battery serves to maintain the run of RTC (real time clock) so that controller does not lose information about time and date when disconnected from power supply. The internal backup battery lifetime is approx. 6 years. If replacement of backup battery is needed, follow these instructions: Connect the controller to a PC and save an archive for backup purposes (not necessary but recommended).

  • Page 36: Controller Setup

    5 Controller setup 5.1 Default configuration 5.2 Controller configuration and PC tools connection 5.3 Operator Guide 6 back to Table of contents 5.1 Default configuration 5.1.1 Binary inputs Number Description Configured function BIN1 Circuit breaker feedback S1CB F 289) EEDBACK PAGE BIN2 Circuit breaker feedback...

  • Page 37: Rs232

    Connection using InteliConfig Image 5.1 First screen of InteliConfig – select connect to controller Image 5.2 Second screen of InteliConfig – select detected controllers Connection using WinScope 1000 Image 5.3 WinScope 1000 screen – select USB connection Select your controller from the HID Device drop-down list. Note: Username and password are not mandatory.
  • Page 38 COM1 Mode (page 213) = Direct Controller Address (page 148) must be set Connection using InteliConfig Image 5.4 First screen of InteliConfig – select connect to controller Image 5.5 Second screen of InteliConfig – select Serial link InteliATS 50 Global Guide...

  • Page 39: Ethernet

    Note: Username and password are not mandatory. 5.2.3 Ethernet It is possible to connect to the controller using Ethernet port either directly or using ComAp's AirGate service. Direct connection If you use a direct connection the controller needs to be reachable directly from the PC you use (i.e. one LAN or WAN without any firewalls and other points that may not allow the connection).
  • Page 40 Connection using InteliConfig Image 5.7 First screen of InteliConfig – select connect to controller Image 5.8 Second screen of InteliConfig – select Internet / Ethernet Connection using WinScope 1000 Image 5.9 WinScope 1000 screen – select Ethernet Following information has to be filled to establish connection:  IP address Controller address User name and Password...
  • Page 41 AirGate connection You can use ComAp's AirGate service that allows you to connect to any controller via the internet regardless of the restrictions of the local network (as long as the controller can connect to the internet AirGate service will work).
  • Page 42 Image 5.10 First screen of InteliConfig – select connect to controller Image 5.11 Second screen of InteliConfig – AirGate Connection using WinScope 1000 In order to connect to WinScope 1000 following information have to be filled out: AirGate ID (page 277) AirGate Server → AirGate Address (page 242) Controller Address (page 148) User name and Password...
  • Page 43 Image 5.12 WinScope 1000 screen – select AirGate InteliATS 50 Global Guide...

  • Page 44: Operator Guide

    5.3 Operator Guide 5.3.1 Front panel elements Image 5.13 Operator interface of InteliATS2 50 Control buttons Position Picture Description LEFT button. Use this button to move left or to change the mode. The button can change the mode only if the main screen with the indicator of currently selected mode is displayed.
  • Page 45 PAGE button. Use this button to switch over display pages. DOWN button. Use this button to move down or decrease value. ENTER button. Use this button to finish editing a setpoint or moving right in the history page. START button. Works in MAN mode and in Mains-Gen application. Press this button to initiate the start sequence of the engine.

  • Page 46: Display Screens

    5.3.2 Display screens The displayed information is structured into "pages" and "screens". Use the PAGE button to switch over the pages. The page Measurement consists of screens which display measured values such as voltages, current etc.; computed values such as Source 2 power, statistic data and the alarm list on the last screen. The page setpoints contains all setpoints organized to groups and also a special group for a user to log in.
  • Page 47 Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. InteliATS 50 Global Guide...
  • Page 48 Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. Note: Available only with plug-in module. Note: Use the Up and Down buttons to move between measurement pages.
  • Page 49 Note: Use the Up and Down buttons to move between measurement pages. Note: Available only with plug-in module. Note: Use the Up and Down buttons to move between measurement pages. Note: Available only with plug-in module. Note: Use the Up and Down buttons to move between measurement pages. Note: Available only with plug-in module.
  • Page 50 Note: Use the Up and Down buttons to move between measurement pages. Note: Available only with plug-in module. Note: Use the Up and Down buttons to move between measurement pages. Note: Use the Up and Down buttons to move between measurement pages. Note: From all of these pages it is possible to switch seamlessly to the setpoint group page by pressing Page button.

  • Page 51: Setpoint Screens

    Setpoint Screens Note: From all measurement pages you can easily go to the setpoint group page by pressing the Page button. Note: Use Up and Down button to select required setpoint group. Note: Use the Enter button to enter selected setpoint group. Note: Use Up and Down button to select required...
  • Page 52 Note: Use Up and Down button to set required value of selected setpoint. Note: Use the Enter button to confirm adjusted value of setpoint. Note: Use the Page button to discard changes, to set setpoint to previous value and to return to the list of setpoints of selected group.
  • Page 53 Note: Use the Up and the Down button to select required alarm reason. Note: Use the Enter button to move to the next page of history log. Note: Use the Up and the Down button to select required alarm reason. Note: Use the Enter button to move to the next page of history log.
  • Page 54 Note: Use the Up and the Down button to select required alarm reason. Note: Use the Enter button to move to the next page of history log. Note: Use the Up and the Down button to select required alarm reason. Note: Use the Enter button to move to the next page of history log.

  • Page 55: Browsing Alarms

    5.3.3 Browsing alarms Note: Use the Up button to move to alarm list from main measurement screen. Active alarms are displayed as white text on black background. It means the alarm is still active, i.e. the appropriate alarm conditions are still present. Inactive alarms are displayed as black text on white background.
  • Page 56 might be or is connected to an untrusted interface and cybersecurity rules are not fulfilled because there is default administrator password. Wrn Password reset e-mail address is not set appears in alarm list when there is no email address set and the administrator password is not the default one.

  • Page 57: Login

    5.3.4 Login Note: From all measurement pages you can easily go to the setpoint group page by pressing the Page button. Note: Use the Up and the Down button to select setpoint group Login. Note: Use the Enter button to enter setpoint group Login. Note: Use the Up and the Down Button to select Login.
  • Page 58 UserID Edit Note: Use the Up and the Down Button to change the digit. Note: Use the Left and the Right buttons to move between digits. Note: Use the Enter button to confirm the UserID or Page button to cancel entering Login. PIN Edit Note: Use the Up and the Down Button...
  • Page 59 Note: In case that invalid UserID or PIN are entered, the controller shows Wrong Credentials screen. Use the Enter button to enter Login again or the Page Button to go back to menu. InteliATS 50 Global Guide...

  • Page 60: Production Mode

    5.3.5 Production mode Note: From all measurement pages you can fluently go to the setpoint group page by pressing the Page button. Note: Use the Enter button to enter setpoint group Login. Note: Use the Up and the Down Button to select Production Mode Note: Use the Enter button to enter the Production Mode.
  • Page 61 Note: Use the Up and the Down Button to change to disabled Note: Use the Enter button to disable the Production Mode. Note: Once Disabled is confirmed by Enter button the option Enabled is no longer on the screen and therefore it is not possible to enable Production mode by HMI display screen.

  • Page 62: Information Screen

    5.3.6 Information screen Note: On Main measurement screen press the Enter and the Page button together. The Enter button has to be pressed first. Note: Use the Page button to move to the next page. Note: Use the Page button to move to the next page. Note: Use the Up button to move back to main measurement screen.

  • Page 63: Language Selection

    5.3.7 Language selection Note: On Main measurement screen press the Enter and the Page button together. The Enter button has to be pressed first. Note: Use the Page button to move to the next page. Note: Use the Page button to move to the next page. Note: Use the Page button to move to the next page.
  • Page 64 Note: Use the Up and the Down button to select required language. Note: Use the Enter button to confirm the selected language. InteliATS 50 Global Guide...

  • Page 65: Display Contrast Adjustment

    5.3.8 Display contrast adjustment Note: On any measurement screen press the Enter Note: On any measurement screen press the Enter and the Up button together for higher contrast. and the Down button together for lower contrast. Note: After setting the contrast, no another action is needed. 5.4 Functions 5.4.1 Analog switches 5.4.2 Breaker control...

  • Page 66: Analog Switches

    5.4.1 Analog switches There are logical analog function dedicated for analog switches. Each analog switch has setpoints for level ON and level OFF and logical binary output. Analog switch Setpoints Binary output AIN Switch01On (page 193) AIN S 01 ( 317) AIN S 01 (...
  • Page 67 Breaker control outputs Output type Description An output for control of a contactor (2 position switch) or 3 S1CB C 306) LOSE PAGE positions switch. Its state represents the contactor or 3 S2CB C 310) LOSE PAGE Close/Open positions switch position requested by the controller. The contactor or 3 positions switch must react within 5 s to a EUTRAL LOSE...
  • Page 68 Outputs controlling 3 positions switch Breaker state Output activation S1CB Close/Open S1 Oper S1CB ON Coil Neutral Close/Open Breakers Off Neutral On Coil S2CB Close/Open S2 Oper S2CB ON Coil Breaker failure detection Breaker fail detection is based on binary output breaker close/open comparing with binary input breaker feedback.
  • Page 69 When binary output breaker close/open is in steady closed state and breaker feedback is changed to opened state the binary output close/open changes to open for minimum 5 s otherwise according to the time set in S1CB Close Delay (page 150) S2CB Close Delay (page 163) setpoints.

  • Page 70: Elevator Switch

    Image 12.6 Breaker failure – breaker close/open closes 5.4.3 Elevator Switch Elevator switch functionality consists of: Setpoints: Elevator Switch (page 142), Pre Elevator Delay (page 142), Post Elevator Delay (page 143) LBO: 301) LEVATOR WITCH PAGE 301) is activated before predicted transfer of the load from one source to LEVATOR WITCH PAGE...
  • Page 71 Note: Following pictures stands for both applications (Mains-Gen, Mains-Mains). For Mains-Mains application Minimal Stabilization Time, Start Time and Stop Time are not valid. Image 12.7 Elevator switch when LBI S2 ( 293) is activated RANSFER TO PAGE Image 12.8 Elevator switch when LBI S2 ( 293) is deactivated...

  • Page 72: Evaluation Of Sources

    5.4.4 Evaluation of sources Evaluation of sources depends on how the setpoints Source 1 Measurement (page 153) Source 2 Measurement (page 168) are set and if LBIs  1 R 290)  2 R OURCE EADY PAGE OURCE EADY 291) are configured PAGE Setpoint Source Description Measurement The measured source voltages and frequency are considered for evaluation...

  • Page 73: Once Mode

    Available modes of each timer: This is a single shot mode. The timer will be activated only once at preset date/time for Once preset duration. The timer is activated every "x-th" day. The day period "x" is adjustable. Weekends can be Daily excluded.

  • Page 74: Daily Mode

    Set-up via controller interface In controller go to the Scheduler setpoint group. Select the function of timer via Timer 1 Function (page 200) setpoint. Then go to Timer 1 Setup and press the Enter button. In Timer 1 Repetition (page 201) setpoint select Once mode.
  • Page 75 adjust Timer 1 Refresh Period (page 206) (xth day of repetition) and Timer 1 Weekends (page 207) (behavior of timer on weekends). Note: Use the Left and the Right buttons to move between timer setpoints. Weekly mode Set-up via InteliConfig To set-up timer via InteliConfig go to the setpoint ribbon, setpoint group scheduler and setpoint Timer 1 Setup.
  • Page 76 Note: Use the Left and the Right buttons to move between timer setpoints. Monthly mode Set-up via InteliConfig To set-up timer via InteliConfig go to the setpoint ribbon, setpoint group scheduler and setpoint Timer 1 Setup. Note: First, the timer functions must be adjusted via setpoint Timer 1 Function (page 200).
  • Page 77 Second type of monthly repetition is based on repeating days in week in month. Image 12.14 Monthly mode – InteliConfig In timer mode select Repeat. In repetition type select Monthly. In timer settings adjust date and time of first occurrence of timer. Also adjust the duration of each occurrence of timer. Then select the type of monthly repetition, the xth week of repetition and days in week.

  • Page 78: Firewall

    Note: Use the Left and the Right buttons to move between timer setpoints. 5.4.6 Firewall The firewall function allows to restrict the access to the controller application services (ComAp/TCP server, MODBUS/TCP server etc.) or to the specific computers or networks. Firewall can be activated on Ethernet port.

  • Page 79: Geo-Fencing

    Example: Adress: 192.168.1.0 Netmask: 255.255.255.0 Port: 23 Any computer with IP address from the network range 192.168.1.0 – 192.168.1.255 can connect to ComAp/TCP server (= connect to the controller with InteliConfig via Ethernet). Example: Adress: 192.168.1.100 Netmask: 255.255.255.255 Port: 502 Only the single computer with IP address 192.168.1.100 can connect to MODBUS/TCP server...

  • Page 80: Load Transfers

    Date Date Date Controller Mode Mode Mode of the controller Source 1 Frequency S1fr Source 1 Frequency Source 1 Voltage L1 S1V1 Source 1 Voltage Ph1 Source 1 Voltage L2 S1V2 Source 1 Voltage Ph2 Source 1 Voltage L3 S1V3 Source 1 Voltage Ph3 Source 1 Voltage L1L2 S1V12 Source 1 Voltage Ph12 Source 1 Voltage L2L3 S1V23...
  • Page 81 After the timer has elapsed, the binary output 302) is activated together with TART PAGE the timer Start Time (page 164). During the Start Time (page 164) the controller waits for parameters to be in the limits. Which parameters are taken into account depends on the setpoint Source 2 Measurement (page 168).
  • Page 82 Image 12.17 Mains-Gen Source 1 Fail, S1CB Opens On = S2 OK Source 1 Return When the Source 1 is restored to normal, the timer Primary Source Return Delay (page 149) begins to count down. Once it is elapsed, the S2CB opens and Open Transfer Min Break (page 150) starts to count.

  • Page 83: Operating Modes

    AMF Mains-Mains Source 1 Fail When the Source 1 failure is detected If the setpoint S1CB Opens On (page 152) is set to S1 Fail: The S1CB is opened. The timers Open Transfer Min Break (page 150) is counting down. The S2CB closes after the timer has elapsed. If the setpoint S1CB Opens On (page 152) is set to S2 OK:...
  • Page 84 Remote OFF (page 287) Remote MAN (page 287) Remote AUTO (page 286) If the respective input is active the controller will change the mode to the respective position according to the active input. If multiple inputs are active, the mode will be changed according to priorities of the inputs. The priorities match the order in the list above.

  • Page 85: Protections

    Mains-Mains Operating Modes OFF mode – Mains-Mains If the setpoint Activity At OFF (page 153) is enabled, the S1CB is opened/closed depending on whether the mains is present or not. If the setpoint Activity At OFF (page 153) is disabled, the S1CB is opened permanently. The buttons S1CB , S2CB , Start...
  • Page 86 Fixed Protection types Fault LBO Horn LBO Alarm Action: Alarm Action: Application Name Level Abbreviation History Reset activation (inc. activation (inc. Source 2 Common LBO List CB open needed Flashing) Flashing) stop AL C OMMON Both Warning 298) PAGE History Record Both Only Alarm List...

  • Page 87: Setpoint Options

    Protection blocking Source 1 protections are always active. Source 2 fixed protections in Mains-Gen application are blocked when engine is starting, stopping or stopped. Exceptions are: Total Stop and Emergency Stop Several protections in Mains-Gen application can be disabled (see Mains-Gen Source 2 level 2 protections on page 88) by dedicated setpoint.
  • Page 88 Mains-Gen Source 2 level 2 protections Setpoint for protection ON / OFF Alarms / Protection name Source 2 Frequency Protection BOS Source 2 Overfrequency (page 350) (page 184) Frequency Source 2 Frequency Protection BOS Source 2 Underfrequency (page 350) (page 184) BOS Source 2 L1 Overvoltage (page 345) BOS Source 2 L2 Overvoltage (page 346) BOS Source 2 L3 Overvoltage (page 348) BOS Source 2 L1L2 Overvoltage (page 346)
  • Page 89 ALI Source 2 Ph Rotation Opposite (page 331) User Protections InteliATS2 50 allows users to configure their own protections to any analog value or binary input/output. Only one protection of 1st level and/or one protection of 2nd level can be configured on logical binary input/output.
  • Page 90 Protection activation Type Name of activation Description Over Limit Protection is activated if value is over limit. Over Limit + Fls Protection is activated if value is over limit or in a fault state. Analog Under Limit Protection is activated if value is under limit. Under Limit + Fls Protection is activated if value is under limit or in a fault state.
  • Page 91 User Protection types Fault LBO Horn LBO Alarm Action: Alarm Action: Application Name Level Abbreviation History Reset activation (inc. activation (inc. Source 2 Common LBO List CB open needed Flashing) Flashing) stop AL C OMMON Mains-Mains, Warning PAGE Mains-Gen 298) Mains-Mains, History Record Only Mains-Gen Mains-Mains,...
  • Page 92 Protection blocking It is possible to configure one Protection Blocking to any User Protections (page 89). This function is used to block certain protections when their function is unwanted or meaningless. Each user protection has an option to set the blocking condition. Protection blocking Block Type Description...
  • Page 93 Adding analog protection Selecting the input source see User Protections on page 89. Selecting the protection type see Fixed Protection types on page 86. Selecting the protection activation see Protection activation on page 90. Selecting the block type see Protection blocking on page 92. Selecting if the occurrence of a protection is recorded every time or only once after a Fault Reset.

  • Page 94: Protection States

    Adding binary protection Selecting the input source see User Protections on page 89. Selecting the protection type see Fixed Protection types on page 86. Selecting the protection activation see Protection activation on page 90. Selecting the block type see Protection blocking on page 92. Selecting if the occurrence of a protection is recorded every time or only once after a Fault Reset.

  • Page 95: Alarm Management

    User protections states During the configuration of protections in InteliConfig, you can decide whether you want to add user protection state for the protection. The name is the same as the alarm's message. User protection states are in a group of 32 values. Note: Group of User protection states is showed only when there is at least 1 protection state in it.
  • Page 96 Image 12.21 Alarm List Alarm types – Level 1 The level 1 alarm indicates that a value or parameter is out of normal limits, but has still not reached critical level. This alarm does not cause any actions regarding the control. Warning (Wrn) The alarm appears in the Alarm list and is recorded into the history log.
  • Page 97 Mains Protection Source 2 + Fault Reset (MPR2) The alarm appears in the Alarm list and is recorded into the history log. It causes immediate opening of the S2CB. Source 2 is in the failure until there is active alarm or inactive but not confirmed alarm in the Alarm list. It activates the output AL C MPR2 (...

  • Page 98: Source Failure Detection

    5.4.12 Source Failure detection Source 1 Failure detection The automatic start can be enabled or disabled by binary input S1 F 289) or by switching the LOCK PAGE controller mode to MAN or OFF mode. The Source 1 is considered as faulty when one or more of the following conditions are valid: The Source 1 voltage is out of the limits given by the setpoints Source 1 Undervoltage (page 156) Source 1 Overvoltage (page 154)

  • Page 99: Test Of The Gen-Set

    5.4.13 Test of the Gen-set For test of the Gen-set in Mains-Gen application it is possible to configure LBIs S2 ( 293) RANSFER TO PAGE 288). EMOTE TART PAGE Activation of the LBI 288) in AUTO mode causes the Gen-set to start and run EMOTE TART PAGE...
  • Page 100 Command Description When the setting of pulse duration is changed while the pulse is active, the current pulse will have the original duration and the new setting is applied for the next pulse. If the User Button is active (as a result of COMMAND ON or COMMAND TOGGLE) and COMMAND PULSE comes, User Button remains active for the duration of the pulse and then it deactivates.

  • Page 101: User Setpoints

    5.4.15 User setpoints Controller allows user to create their own setpoints, as well as edit and delete created setpoints. The number of setpoints created by the user is limited to 64. All setpoints created by user are located in Group: User Setpoints.

  • Page 102: Voltage Phase Sequence Detection

    Contents of the user setpoint Max. 32 characters Name Note: Does not consider duplicities (It is possible to have setpoints with the same name, but it is not recommended.) Can be chosen from a list or Dimension User can create their own with a limit of 32 characters. Resolution Max.

  • Page 103: Types Of Interfaces

    5.5.1 Types of interfaces The controller communication interfaces are split into two categories according to what kind of environment the interface is exposed to. Trusted Trusted interfaces are operated locally inside a closed environment/ infrastructure where additional measures against misuse or attack take place (e.g. physical access limitation). Due to the nature of this interface less strict cybersecurity rules may be applied.

  • Page 104: User Login

    User login To login to the controller the username and password must be provided into the login form of the application (InteliConfig (page 11) WebSupervisor (page 11). Alternatively, at trusted interfaces, it is possible to login using UID and PIN instead of username and password.

  • Page 105: Managing Accounts

    Wrn Default Password appears in Alarm list when the default administrator password is set and communication module is plugged in the controller. The purpose of alarm is to inform that the controller might be or is connected to an untrusted interface and cybersecurity rules are not fulfilled because there is default administrator password.

  • Page 106: Adding An Account

    Adding an account Click on the "+" button in the lower left corner of the user management window, then provide the account properties as described in User accounts (page 103). Note: Rules for the User accounts (page 103) credentials apply and some items are optional Deleting an account Select the account that has to be deleted and click on the "-"...

  • Page 107: Account Break Protection

    5.5.4 Account break protection The controller protectis the user accounts against a brute-force attack, i.e against breaking into the controller by fast repeating attempts to login with credentials generated from the range of all possible combinations. If the account break protection detects a possible attack and blocks an account or interface the alarm Brute Force Protection Active (page 325) is activated.

  • Page 108: Special Situations

    IMPORTANT: There is a backup e-mail address defined in the controller to which and only which ComAp will send the "password reset action code". Please be sure, that you have adjusted this e- mail address correctly. Use InteliConfig to adjust the backup e-mail address...
  • Page 109 Reset password procedure 1. Connect InteliConfig. 2. Get the password reset request code and send it via e-mail to support@comap-control.com InteliATS 50 Global Guide...
  • Page 110 3. Once you receive the reply from ComAp, copy the code from the e-mail (all characters inside the box as indicated below) InteliATS 50 Global Guide...
  • Page 111 4. Paste the code into the password reset window Encryption of the communication New technology "CCS v.1" is used for an authentication and an encryption of the ComAp protocol via Internet/ethernet/AirGate. This technology is based on strong and proven cryptographic algorithms and has successfully passed penetration tests and cybersecurity audit.

  • Page 112: Communication

    6 Communication 6.1 PC 6.2 Connection to 3rd party systems 6 back to Table of contents 6.1 PC 6.1.1 Direct communication 6.1.2 Remote communication 6.1.1 Direct communication A RS232, USB, RS485 or ethernet interface can be used for direct cable connection to a PC. Connection via RS232 A plug-in communication module CM-RS232-485 is necessary for communication via RS232 connection.

  • Page 113: Connection Via Usb

    Image 13.3 Plug-in module CM RS232-485 is used Connection via Ethernet A plug-in communication module CM3-Ethernet is necessary for Ethernet connection. The module is plugged into the slot located on the rear side of the controller. To find more information about installation of the modules see Plug-in module installation on page 34.

  • Page 114: Internet Connection

    Note: If you have troubles with setting up static and public IP address for direct connection from Internet try using AirGate connection instead. Image 13.6 Ethernet LAN connection Setting-up static IP address There are two basic ways to get the static IP address. First way is to switch the CM3-Ethernet to manual IP address mode.
  • Page 115 AirGate This connection type is intended for remote connection from InteliConfig, or any other ComAp PC tool over the Internet in situations, where obtaining fixed public IP address is not possible. Only two remote clients can be connected at the same time.

  • Page 116: Alarm Sms

    Source 1 Returned hh:mm:ss Load on Source 1 hh:mm:ss AMF Stop Alarm SMS The InteliATS2 50 controller equipped with the CM2-4G-GPS communication module is able to send Alarm SMS according to the setting of setpoints: Wrn Message (page 253) BOS Message (page 251)

  • Page 117: Alarm E-Mail

    Event 1 hh:mm:ss Event 2 hh:mm:ss Event 3 Alarm Email The InteliATS2 50 controller equipped with the CM3-Ethernet communication module is able to send Alarm Emails according to the setting of setpoints: Wrn Message (page 253) BOS Message (page 251)

  • Page 118: Connection To 3Rd Party Systems

    Message structure: Controller ----------------------------------------------- Name: XXX Serial number: XXX SW branch: XXX SW version: XXX Application: XXX Appl. version: XXX Date: dd/mm/yyyy Time: hh:mm:ss Alarm list ----------------------------------------------- Alarm 1 Alarm 2 Alarm 3 History events ----------------------------------------------- 0 dd/mm/yyyy hh:mm:ss.0 Event 1 -1 dd/mm/yyyy hh:mm:ss.0 Event 2 -2 dd/mm/yyyy hh:mm:ss.0 Event 3 Note: An asterisk means that alarm is unconfirmed and an exclamation mark means that alarm is active.

  • Page 119: Snmp Notifications

    MIB table is different and must be exported separately for each controller. The root OID of the InteliATS2 50 controller is 1.3.6.1.4.1.28634.35. Under this node can be found following sub-nodes : Notifications group (SMI v2 only) contains definitions of all notification-type objects that the Agent may send to the Manager.

  • Page 120: Modbus-Rtu, Modbus/Tcp

    The notification message also contains controller name, serial number and textual description of the event. SMI version In InteliConfig the MIB table may be exported in two different formats – SMI v1 and SMI v2. The format which shall be used for export depends on the SNMP Manager and the SMI version that it supports. Typically, SMI v1 is used for SNMP v1 and vice versa, but it is not a rule and SMI v2 may also be used for SNMP v1.
  • Page 121 MODBUS MODICON object Meaning Access MODBUS function address type 0000 .. Binary Read only Discrete Inputs Read: 01, 02 0999 objects 1000 .. Values Read only Input Registers Read: 03, 04 2999 Read: 03, 04 3000 .. Setpoints Read/Write Holding Registers 3999 Write: 06, 16 Input Registers...
  • Page 122 Number of Data type Meaning Data maping registers LSB2 = value, bits 0-7 MSB = 0 Char 1-byte ASCII character LSB = ASCII value of the character MSB = 0 StrList Index into a list of strings LSB = index into the list MSB1 = ASCII value of the 1.

  • Page 123: Reserved Registers

    Error codes (exception codes) An exception code is returned by the controller (server) if the query sent from the client could not be completed successfully. The controller responds with the error codes in as follows: 01 – Illegal function is returned if an incompatible type of operation is applied for a specific object, e.g. if function 03 is applied to a binary object.
  • Page 124 Register Number of Access Data type Meaning addresses registers 4404 - 4430 read Alarm 8. record in alarm list 4431 - 4457 read Alarm 9. record in alarm list 4458 - 4484 read Alarm 10. record in alarm list 4485 - 4511 read Alarm 11.
  • Page 125 MCB toggle *) 0x02 0x12ED0000 0x000012EE MCB on 0x02 0x12EE0000 0x000012EF MCB off 0x02 0x12EF0000 0x000012F0 Note: *) This action is an equivalent of pressing the front panel button MODBUS examples Modbus RTU examples Reading of Battery voltage Export table of values from InteliConfig Table: Values Allowed Modbus functions: 03, 04 Register...
  • Page 126 Reading Nominal power Export table of values from InteliConfig Table: Values Allowed MODBUS functions: 03, 04 Register Com.Obj. Name Dimension Type Group Nominal 01227 9018 Integer 32767 Generator Power Request: (Numbers in Hex) Register address Controller address Modbus function Number of registers 04CC 1228 Response: (Numbers in Hex)
  • Page 127 Reading all binary inputs as Modbus register Table: Values Allowed Modbus functions: 03, 04 Register Com.Obj. Name Dimension Type Group Binary Controller 01089 8235 Binary#2 Inputs Request: (Numbers in Hex) Register address Controller address Modbus function Number of registers 042C 1068 Response: (Numbers in Hex) Data...
  • Page 128 Reading binary inputs as coil status. Table: Binaries Allowed Modbus functions: 01, 02 Addresses Source Name of Bit Name C.O.# Value Modbus Addr. = Value Bit # Group Activated by protection State # Name of State (s): Prot. Addr. = State 00000 Value 8235...
  • Page 129 Starting the engine Before starting engine you may need to write password depending on the settings in controller. Table Reserved registers (page 123) Register Number of Access Data type Meaning addresses registers Writing:command argument 4207 - 4208 read/write Unsigned32 Reading: command return value 4209 write...
  • Page 130 Nominal Power – writing Table: Setpoints Allowed Modbus functions: 03, 04, 06, 16 Register Com.Obj. Name Dimension Type Group Nominal Basic 03008 8276 Unsigned 5000 Power Settings Request: (Numbers in Hex) Data Register address Controller address Modbus function 0064 0BC0 = 3008 Response: (Numbers in Hex) Register address...
  • Page 131 Modbus TCP examples Reading of Battery voltage Export table of values from InteliConfig Table: Values Allowed Modbus functions: 03, 04 Register Com.Obj. Name Dimension Type Group BatteryVoltag Controller 01053 8213 Integer Request: (Numbers in Hex) Register transaction protocol Length of address Controller Modbus...

  • Page 132: Technical Data

    7 Technical data Power supply 6 back to Table of contents 8-36 VDC Power supply range Power consumption 2.0 W (without modules) RTC battery Replaceable (3 V) Fusing power 4 A w/o BOUT consumption Max. Power Dissipation Operating conditions Protection degree IP 65 (front panel) Operating temperature -20 ˚C to +70 ˚C...

  • Page 133: Appendix

    8 Appendix 8.1 Controller objects 8.2 Alarms 8.3 Modules 6 back to Table of contents 8.1 Controller objects 8.1.1 List of controller objects types 8.1.2 Setpoints 8.1.3 Values 8.1.4 Logical binary inputs 8.1.5 Logical binary outputs 8.1.6 Logical analog inputs 8.1.2 Setpoints What setpoints are: Setpoints are analog, binary or special data objects which are used for adjusting the controller to the specific...
  • Page 134 List of setpoints Secondary Source Switch Group: Basic settings Subgroup: Name Primary Source Return Delay Controller Name S1CB Close Delay Subgroup: Voltage settings Open Transfer Min Break Connection type Return From Secondary Source Nominal Voltage Ph-N S1CB Opens On Nominal Voltage Ph-Ph Source 1 Measurement Source 1 VT Ratio Activity At OFF...
  • Page 135 Genset Stop Fail User Button 6 Subgroup: Voltage Protection User Button 7 Source 2 Overvoltage User Button 8 Source 2 Overvoltage BOS Group: Analog Switches Subgroup: Analog Switches 1 Source 2 Overvoltage Wrn AIN Switch01On Source 2 Overvoltage Hys AIN Switch01 Off Source 2 Undervoltage Subgroup: Analog Switches 2 Source 2 Undervoltage BOS AIN Switch02 On Source 2 Undervoltage Wrn...
  • Page 136 Subgroup: Fence 1 Direct Connection Fence 1 Protection Direct Connection Port Fence Radius 1 ComAp Client Inactivity Timeout Fence 1 Delay Subgroup: E-mail Settings Subgroup: Fence 2 SMTP Server Address Fence 2 Protection SMTP Sender Address Fence Radius 2 SMTP User Name Fence 2 Delay...
  • Page 137 RemoteControl2B 4 AirGate Port RemoteControlBin Subgroup: ComAp Client Settings 6 back to Controller objects Direct Connection Direct Connection Port ComAp Client Inactivity Timeout Subgroup: MODBUS Settings MODBUS Server MODBUS Client Inactivity Timeout Subgroup: SNMP Settings SNMP Agent SNMP Trap Format SNMP Traps IP Address 1...
  • Page 138 Group: Basic settings Subgroup: Name Controller Name Setpoint group Basic settings Related FW 1.2.0 Range [units] 0 .. 15 characters [-] Default value InteliATS2 Alternative config Step Comm object 8637 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User defined name, used for the controller identification at remote phone or mobile connection.
  • Page 139 3Ph3Wire Ungrounded Delta connection Open Delta Ungrounded Wye Corner-Grounded Delta Split Phase Delta Three phase voltage measurement L1,L2,L3 with 120° phase shift 3Ph4Wire Grounded Star (Grounded Wye) connection – 3PY Three phase voltage measurement L1,L2,L3 with 120° phase shift High Leg D High Leg Delta connection Three phase voltage measurement L1,L2,L3 6 back to List of setpoints...

  • Page 140: Nominal Frequency

    Source 1 VT Ratio Setpoint group Basic settings Related FW 1.2.0 Range [units] 0.1 .. 500.0 [V/V] Default value 1.0 V/V Alternative config Step 0.1 V/V Comm object 9580 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description Source 1 voltage potential transformers ratio. If no VTs are used, adjust the setpoint to 1. 6 back to List of setpoints Source 2 VT Ratio Setpoint group...
  • Page 141 Subgroup: Battery protections Battery Undervoltage Setpoint group Basic settings Related FW 1.2.0 Range [units] 8.0 V .. Battery Overvoltage (page 141) Default value 18.0 V Alternative config Step 0.1 [V] Comm object 8387 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Warning threshold for low battery voltage.
  • Page 142 Subgroup: Elevator Switch Settings Elevator Switch Setpoint group Basic settings Related FW 1.2.0 Range [units] Enabled / Disabled [-] Default value Disabled [-] Alternative config Step Comm object 20327 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Setpoint enables or disables elevator switch functionality (for more information see Elevator Switch on page 70).
  • Page 143 Post Elevator Delay Setpoint group Basic settings Related FW 1.2.0 Range [units] 0 .. 600 [s] Default value 10 s Alternative config Step Comm object 20325 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description The delay defines how long after predicted transfer of the load the LBO 301) LEVATOR WITCH...

  • Page 144: Controller Mode

    Conversion Coefficient Pulse 2 Setpoint group Basic settings Related FW 1.2.0 Range [units] 0 ... 65 000 [-] Default value Alternative config Step Comm object 10995 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Only if LBI 286) is configured ULSE OUNTER PAGE...

  • Page 145: Power On Mode

    Power On Mode Setpoint group Basic settings Related FW 1.2.0 Range [units] Previous / OFF [-] Default value Previous Alternative config Step Comm object 13000 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description This setpoint adjusts controller mode after power on of controller. Previous When controller is power on, controller is switched to last mode before power off.

  • Page 146: Backlight Timeout

    Backlight Timeout Setpoint group Basic settings Related FW 1.2.0 Range [units] Disabled / 1 .. 255 [min] Default value Disabled Alternative config Step 1 min Comm object 10121 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description The display backlight is switched off when this timer exceed. When setpoint is adjusted to disabled then the display will be backlighted all the time.
  • Page 147 User Logging Record Setpoint group Basic settings Related FW 1.2.0 Range [units] Enabled / Disabled Default value Enabled Alternative config Step Comm object 23885 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description This setpoint enables recording of user logings. 6 back to List of setpoints Subgroup: HMI Settings Main Screen Line 1...

  • Page 148: Controller Address

    Screen Filter Setpoint group Basic settings Related FW 1.2.0 Range [units] Enable / Disabled [-] Default value Disabled Alternative config Step Comm object 15889 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description Every analog value showed on CU screen is filtered when setpoint is enabled. 6 back to List of setpoints Group: Communication Settings Subgroup: Controller Address...
  • Page 149 Group: Source 1 Subgroup: Source 1 settings Secondary Source Switch Setpoint group Source 1 Related FW 1.2.0 Range [units] 0 .. 6 000 [s] Default value Alternative config Step Comm object 8301 Related applications Mains-Gen Config level Standard Setpoint visibility Always Description Delay for Switch of Secondary Source.
  • Page 150 S1CB Close Delay Setpoint group Source 1 Related FW 1.2.0 Range [units] 0.0 .. 60.0 [s] Default value 5.0 s Alternative config Step 0.1 s Comm object 8389 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Delay after Source 1 returns to S1CB closing when transfer to Source 2 is not finished. When the controller restarts and Source 1 is healthy the closing of S1CB is done after S1CB Close Delay.
  • Page 151 Image 15.2 Open Transfer Min Break If some delay between S1CB F 289) deactivation and closing of S2CB C EEDBACK PAGE LOSE PAGE 310) output is required, then the Open Transfer Min Break must be set to sum of "S1CB opening" + "Delay"...
  • Page 152 Return From Secondary Source Setpoint group Source 1 Related FW 1.2.0 Range [units] Manual / Auto [-] DefaultFixed Auto Alternative config value Step Comm object 9590 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description Setpoint adjusts the behavior of S2CB opening and S1CB closing when Source 1 returns. The controller waits during the timer Primary Source Return Delay for pushing the S1CB button to open S2CB breaker in order to initiate the transfer.
  • Page 153 Source 1 Measurement Setpoint group Source 1 Related FW 1.2.0 Range [units] ENABLED / DISABLED [-] Default value ENABLED [-] Alternative config Step Comm object 19575 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Enables / Disables Source 1 Measurement. Source 1 evaluation (S2 is OK or S2 is NOK ) is based on frequency and voltages ENABLED and on user protections and on the LBI...
  • Page 154 Subgroup: Voltage protections Source 1 Overvoltage Setpoint group Source 1 Related FW 1.2.0 Range [units] 100 .. 150 [%] Default value 110 % Alternative config Step 1 % of Nominal Voltage Ph-Ph (page 139) Comm object 20478 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description...
  • Page 155 Source 1 Overvoltage Hys Setpoint group Source 1 Related FW 1.2.0 Range [units] 100 .. Source 1 Overvoltage (page 154) Default value 105 % Alternative config Step Comm object 20476 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold defines the level of turning off Source 1 overvoltage protection. Image 15.4 Source 1 Overvoltage Hys 6 back to List of setpoints InteliATS 50 Global Guide...
  • Page 156 Source 1 Undervoltage Setpoint group Source 1 Related FW 1.2.0 Range [units] 50 .. 100 [%] Default value 60 % Alternative config Step 1 % of Nominal Voltage Ph-Ph (page 139) Comm object 20477 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold for Source 1 undervoltage.
  • Page 157 Source 1 Undervoltage Hys Setpoint group Source 1 Related FW 1.2.0 Range [units] Source 1 Undervoltage (page 156) .. 100 [%] Default value 65 % Alternative config Step Comm object 20475 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold defines the level of turning off Source 1 undervoltage protection.
  • Page 158 Source 1 Voltage Unbalance Setpoint group Source 1 Related FW 1.2.0 1 .. 150 [%] of Nominal Voltage Ph-Ph (page 139) Nominal Voltage Ph-N Range [units] (page 139) Default value 10 % Alternative config Step Comm object 20455 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always...
  • Page 159 Source 1 Overfrequency Hys Setpoint group Source 1 Related FW 1.2.0 Range [units] 100 .. Source 1 Overfrequency (page 158) Default value 102.0 % Alternative config Step 0.1 % Comm object 20450 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold defines the level of turning off Source 1 overfrequency protection.
  • Page 160 Source 1 Underfrequency Setpoint group Source 1 Related FW 1.2.0 Range [units] 50 .. 100 [%] Default value 98.0 % Alternative config Step 1.0 % of Nominal Frequency (page 140) Comm object 20451 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold for Source 1 underfrequency.
  • Page 161 Source 1 Underfrequency Hys Setpoint group Source 1 Related FW 1.2.0 Range [units] Source 1 Underfrequency (page 160) .. 100 [%] Default value 98.0 % Alternative config Step 0.1 % Comm object 20449 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Threshold defines the level of turning off Source 1 underfrequency protection.

  • Page 162: Phase Rotation

    Source 1 < > Frequency Delay Setpoint group Source 1 Related FW 1.2.0 Range [units] 0.0 .. 600.0 [s] Default value 0.5 s Alternative config Step 0.1 s Comm object 20448 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Delay for Source 1 Underfrequency (page 160)

  • Page 163: Phase Rotation Protection

    Phase Rotation Protection Setpoint group Basic settings Related FW 1.2.0 Range [units] Enabled / Disabled / ExtDisable [-] Default value Enabled Alternative config Step Comm object 19709 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description This setpoint enables or disables Phase Rotation Protection. Protection is enabled.

  • Page 164: Start Time

    Start Time Setpoint group Source 2 Related FW 1.2.0 Range [units] Minimal Stabilization Time (page 166) .. 600 [s] Default value 20 s Alternative config Step Comm object 20329 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description The timer starts when LBO 302)

  • Page 165: Cooling Time

    Cooling Time Setpoint group Engine settings Related FW 1.2.0 Range [units] 0 .. 300 [s] Default value Alternative config Step Comm object 8258 Related applications Mains-Gen Config level Standard Setpoint visibility Always Description Cooling Time defines the period when LBO 302) is still active before stop of the TART...
  • Page 166 Minimal Stabilization Time Setpoint group Source 2 Related FW 1.2.0 Range [units] 1 .. 300 [s] Default value Alternative config Step Comm object 8259 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Minimal time triggered in starting period during which the conditions for closing S2CB breaker have to be continuously fulfilled.
  • Page 167 Run Only Block Delay Setpoint group Source 2 Related FW 1.2.0 Range [units] 0.0 .. 600.0 [s] Default value 5.0 s Alternative config Step 0.1 s Comm object 10023 Related applications Mains-Gen Config level Advanced Setpoint visibility Always Description If any protection is configured with blocking condition "Run Only Block" this setpoint influences the blocking condition.
  • Page 168 Source 2 Measurement Setpoint group Source 2 Related FW 1.2.0 Range [units] ENABLED / DISABLED [-] Default value ENABLED [-] Alternative config Step Comm object 17011 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Enables / Disables Source 2 Measurement. Source 2 evaluation (S2 is OK or S2 is NOK ) is based on frequency and voltages ENABLED and on user protections and on the LBI...
  • Page 169 Subgroup: Voltage Protection Source 2 Overvoltage Setpoint group Source 2 Related FW 1.2.0 Range [units] 100 .. 150 [%] Default value 110 % Alternative config Step Comm object 20469 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold for Source 2 overvoltage.
  • Page 170 Source 2 Overvoltage Wrn Setpoint group Source 2 Related FW 1.2.0 Range [units] 100 .. 150 [%] Default value 110 % Alternative config Step Comm object 20467 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Threshold for Source 2 overvoltage protection. All three phases are checked. Maximum out of three is used.
  • Page 171 Source 2 Overvoltage Hys Setpoint group Source 2 Related FW 1.2.0 Range [units] 100 .. Source 2 Overvoltage (page 169) Default value 100 % Alternative config Step Comm object 20465 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold defines the level of turning off Source 2 overvoltage protection.
  • Page 172 Source 2 Undervoltage Setpoint group Source 2 Related FW 1.2.0 Range [units] 50 .. 100 [%] Default value 60 % Alternative config Step Comm object 20468 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold for Source 2 undervoltage. All three phases are checked. Minimum voltage out of three phases is used.
  • Page 173 Source 2 Undervoltage Wrn Setpoint group Source 2 Related FW 1.2.0 Range [units] 50 .. 100 [%] Default value 60 % Alternative config Step Comm object 20466 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Threshold for Source 2 undervoltage protection. All three phases are checked. Minimum out of three is used.
  • Page 174 Source 2 Undervoltage Hys Setpoint group Source 2 Related FW 1.2.0 Range [units] Source 2 Undervoltage (page 172) .. 100 [%] Default value 100 % Alternative config Step Comm object 20464 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold defines the level of turning off Source 2 undervoltage protection.
  • Page 175 Source 2 < > Voltage Delay Setpoint group Source 2 Related FW 1.2.0 Range [units] 0.0 .. 600.0 [s] Default value 2.0 s Alternative config Step 0.1 s Comm object 20463 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Delay for voltage protections.
  • Page 176 Source 2 Voltage Unbalance Setpoint group Source 2 Related FW 1.2.0 1 .. 150 [%] of Nominal Voltage Ph-Ph (page 139) Nominal Voltage Ph-N Range [units] (page 139) Default value 10 % Alternative config Step Comm object 20432 Related applications Mains-Mains Config level Advanced Setpoint visibility Always...
  • Page 177 Subgroup: Frequency Protection Source 2 Overfrequency Setpoint group Source 2 Related FW 1.2.0 Range [units] 100.0 .. 150.0 [%] Default value 102.0 % Alternative config Step 0.1 % Comm object 20437 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold for Source 2 overfrequency.
  • Page 178 Source 2 Overfrequency Hys Setpoint group Source 2 Related FW 1.2.0 Range [units] 100.0 .. Source 2 Overfrequency (page 177) Default value 102.0 % Alternative config Step 0.1 % Comm object 20435 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold defines the level of turning off Source 2 overfrequency protection.
  • Page 179 Source 2 Underfrequency Setpoint group Source 2 Related FW 1.2.0 Range [units] 50.0 .. 100.0 [%] Default value 98.0 % Alternative config Step 0.1 % Comm object 20436 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold for Source 2 underfrequency. 6 back to List of setpoints Source 2 Underfrequency BOS Setpoint group...
  • Page 180 Source 2 Underfrequency Hys Setpoint group Source 2 Related FW 1.2.0 Range [units] Source 2 Underfrequency (page 179) .. 100.0 [%] Default value 100.0 % Alternative config Step 0.1 % Comm object 20434 Related applications Mains-Mains Config level Standard Setpoint visibility Only in Mains-Mains. Description Threshold defines the level of turning off Source 2 underfrequency protection.
  • Page 181 Source 2 Overfrequency Wrn Setpoint group Source 2 Related FW 1.2.0 Range [units] 100.0 .. 150.0 [%] Default value 102.0 % Alternative config Step 0.1 % Comm object 20439 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description Threshold for Source 2 phase L1 overfrequency. 6 back to List of setpoints Source 2 Underfrequency Wrn Setpoint group...
  • Page 182 Source 2 <> Frequency Delay Setpoint group Source 2 Related FW 1.2.0 Range [units] 0.0 .. 600.0 [s] Default value 0.5 s Alternative config Step 0.1 s Comm object 20433 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Delay for frequency protections.
  • Page 183 Phase Rotation Protection Setpoint group Basic settings Related FW 1.2.0 Range [units] Enabled / Disabled / ExtDisable [-] Default value Enabled Alternative config Step Comm object 19709 Related applications Mains-Mains, Mains-Gen Config level Advanced Setpoint visibility Always Description This setpoint enables or disables Phase Rotation Protection. Protection is enabled.

  • Page 184: Voltage Unbalance Protection

    Voltage Unbalance Protection Setpoint group Source 2 Protections Related FW 1.2.0 Range [units] Enabled / Disabled / ExtDisable [-] Default value Enabled Alternative config Step Comm object 15669 Related applications Mains-Gen Config level Standard Setpoint visibility Only in Mains-Gen. Description This setpoint enables or disables Voltage Unbalance Protection. Protection is enabled.
  • Page 185 Group: User Buttons User Button 1 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20826 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 186 User Button 2 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20827 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 187 User Button 3 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20828 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 188 User Button 4 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20829 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 189 User Button 5 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20830 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 190 User Button 6 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20831 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 191 User Button 7 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20832 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 192 User Button 8 Setpoint group User Buttons Related FW 1.2.0 Range [units] COMMAND / MAN OFF / MAN ON [-] Default value COMMAND Alternative config Step Comm object 20833 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description User button is a binary signal which value can be set by its setpoint or by remote connection (WebSupervisor or by third party device(Modbus).
  • Page 193 Group: Analog Switches Subgroup: Analog Switches 1 AIN Switch01On Setpoint group Analog Switches Related FW 1.2.0 Range [units] the range is defined by an analog sensor curve the value is defined by Default value Alternative config an analog sensor curve Step the step is defined by an analog sensor curve Mains-Mains, Mains- Comm object 11407...
  • Page 194 AIN Switch01 Off Setpoint group Analog Switches Related FW 1.2.0 Range [units] the range is defined by an analog sensor curve the value is defined by Default value Alternative config an analog sensor curve Step the step is defined by an analog sensor curve Mains-Mains, Mains- Comm object 11410...
  • Page 195 Subgroup: Analog Switches 2 AIN Switch02 On Setpoint group Analog Switches Related FW 1.2.0 Range [units] the range is defined by an analog sensor curve the value is defined by Default value Alternative config an analog sensor curve Step the step is defined by an analog sensor curve Mains-Mains, Mains- Comm object 11408...
  • Page 196 AIN Switch02 Off Setpoint group Analog Switches Related FW 1.2.0 Range [units] the range is defined by an analog sensor curve the value is defined by Default value Alternative config an analog sensor curve Step the step is defined by an analog sensor curve Mains-Mains, Mains- Comm object 11411...
  • Page 197 Date Setpoint group Scheduler Related FW 1.2.0 Range [units] DD/MM/YYYY [-] Default value 1.1.2015 Alternative config Step Comm object 24553 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Actual date adjustment. 6 back to List of setpoints Time Stamp Period Setpoint group Scheduler...
  • Page 198 Time Zone CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] GMT-12:00 .. GMT+13:00 [hours] Default value GMT+1:00 hour Alternative config Step Comm object 24366 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint is used to select the time zone where the controller is located.

  • Page 199: Time Mode

    Time Mode Setpoint group Scheduler Related FW 1.2.0 Range [units] STD / DST Default value Alternative config Step Comm object 20249 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description In manual DST Switching Mode (page 198) this input is used to adjust the actual time mode. If DST Switching Mode is set to any other option, this input is not taken into account.
  • Page 200 Subgroup: Timer 1 Timer 1 Function Setpoint group Scheduler Related FW 1.2.0 Range [units] Disable / No Func / Mode OFF / Manual On / Rem Start/Stop / S1 FailBlock [-] Default value Disable Alternative config Step Comm object 15358 Related applications Mains-Mains, Mains-Gen Config level...
  • Page 201 Timer 1 Setup Setpoint group Scheduler Related FW 1.2.0 Range [units] Default value Alternative config Step Comm object 10969 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Always Description Related setpoints for timer 1 are: Timer 1 Function (page 200) 6 back to List of setpoints Timer 1 Repetition Setpoint group...
  • Page 202 Timer 1 First Occur. Time Setpoint group Scheduler Related FW 1.2.0 Range [units] [HH:MM] Default value 00:00 Alternative config Step Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description Time of first occurrence of Timer 1 Function (page...
  • Page 203 Timer 1 Repeated Setpoint group Scheduler Related FW 1.2.0 Range [units] Daily / Weekly / Monthly / Short Period [-] Default value Daily Alternative config Step Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description Repeated interval of...
  • Page 204 Timer 1 Day Setpoint group Scheduler Related FW 1.2.0 Range [units] Monday / Tuesday / Wednesday / Thursday / Friday / Saturday/ Sunday[-] Default value All OFF Alternative config Step Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description Use this setpoint to include or exclude individual days of week.
  • Page 205 Timer 1 Repeat Week In Month Setpoint group Scheduler Related FW 1.2.0 Range [units] 1 .. 5 [week] Default value 1 week Alternative config Step 1 week Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description This setpoint adjust the week of month in which the...
  • Page 206 Timer 1 Refresh Period Setpoint group Scheduler Related FW 1.2.0 Range [units] Default value Alternative config Step Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description Refresh period of Timer 1 Function (page 200).
  • Page 207 Timer 1 Weekends Setpoint group Scheduler Related FW 1.2.0 Range [units] Including / Skip / Postpone [-] Default value Including Alternative config Step Comm object Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 200) Description Behavior of Timer 1 Function (page 200)
  • Page 208 Group: Geo-Fencing Subgroup: Geo Fencing Geo-Fencing Setpoint group Geo-Fencing Related FW 1.2.0 Range [units] Disabled / Enabled / LBI Enable [-] Default value Disabled Alternative config Step Comm object 11681 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint enables or disables geo-fencing function.
  • Page 209 Home Longitude Setpoint group Geo-Fencing Related FW 1.2.0 Range [units] -180,0000..180,0000 [°] Default value 0,0000 ° Alternative config Step 0,0001 ° Comm object 14607 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint adjust longitude of "home"...

  • Page 210: Protection Types

    Subgroup: Fence 1 Fence 1 Protection Setpoint group Geo-Fencing Related FW 1.2.0 Range [units] HistRecOnl / Wrn / Sd / BOC[-] Default value HistRecOnl Alternative config Step Comm object 14610 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Protection type for geo-fencing 1 protection.
  • Page 211 Fence 1 Delay Setpoint group Geo-Fencing Related FW 1.2.0 Range [units] 0..3600 [s] Default value Alternative config Step Comm object 11682 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Delay for Fence 1 Protection (page 210).
  • Page 212 Fence Radius 2 Setpoint group Geo-Fencing Related FW 1.2.0 Range [units] 0,0..99,9 [km] Default value 0,0 km Alternative config Step 0,1 km Comm object 14608 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Radius for circle area 2.
  • Page 213 Description This setpoint enable or disable module in slot A. 6 back to List of setpoints Group: CM-RS232-485 Subgroup: COM1 Setting COM1 Mode Setpoint group CM-RS232-485 Related FW 1.2.0 Range [units] Direct / MODBUS [-] Default value Direct Alternative config Step Comm object 24522 Related applications...

  • Page 214: Possible Options

    COM1 Modbus Mode Setpoint group CM-RS232-485 Related FW 1.2.0 Range [units] 8N1 / 8N2 / 8E1 [-] Default value Alternative config Step Comm object 23867 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint adjusts communication mode of Modbus-RTU.
  • Page 215 Subgroup: COM2 Setting COM2 Mode Setpoint group CM-RS232-485 Related FW 1.2.0 Range [units] Direct / MODBUS [-] Default value Direct Alternative config Step Comm object 24451 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Communication protocol switch for the COM2 channel.
  • Page 216 COM2 Modbus Mode Setpoint group CM-RS232-485 Related FW 1.2.0 Range [units] 8N1 / 8N2 / 8E1 [-] Default value Alternative config Step Comm object 23866 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint adjusts communication mode of Modbus-RTU.

  • Page 217: Network Mode

    Group: CM-4G-GPS Subgroup: Cellular Interface Internet Connection Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Enabled / Disabled [-] Default value Enabled Alternative config Step Comm object 24315 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint adjust the communication mode of module.
  • Page 218 Connection Check IP1 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Default value "empty" Alternative config Step Comm object 23978 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217) Description IP address of reliable server in the internet.
  • Page 219 Connection Check IP2 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Default value "empty" Alternative config Step Comm object 23977 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217) Description IP address of reliable server in the internet.
  • Page 220 Connection Check IP3 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Default value "empty" Alternative config Step Comm object 23976 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217) Description IP address of reliable server in the internet.

  • Page 221: Dns Mode

    Subgroup: TCP/IP Settings DNS Mode Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Automatic / Manual [-] Default value Automatic Alternative config Step Comm object 23988 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint enables to enter DNS server addresses manually, even with the Internet Connection (page...
  • Page 222 DNS IP Address 2 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Valid IP address [-] Default value 8.8.8.8 Alternative config Step Comm object 23986 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description The setpoint is used to select the method how the DNS Address 2 is adjusted.
  • Page 223 Connection (page 217) Description This setpoint is used for entering the domain name or IP address of the AirGate server. Use the free AirGate server provided by ComAp at global.airgate.link. 6 back to List of setpoints InteliATS 50 Global Guide...

  • Page 224: Direct Connection

    Setpoint visibility Only if relevant module is installed Description Use this to enable/disable direct connection of a ComAp client (e.g. InteliConfig) to the IP address of the controller. Note: For Direct connection the controller IP address must be reachable from the client IP address.
  • Page 225 Setpoint visibility Only if relevant module is installed Description This port is used to listen for an incoming TCP connection if Direct Connection is ENABLED. 6 back to List of setpoints ComAp Client Inactivity Timeout CM-Ethernet Setpoint group Related FW 1.2.0...
  • Page 226 Subgroup: E-mail Settings SMTP Server Address Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value global.airgate.link:9925 Alternative config Step Comm object 23962 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint is used for entering the domain name (e.g.

  • Page 227: Smtp User Name

    SMTP User Name Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value Alternative config Step Comm object 24313 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Use this setpoint to enter the username for the SMTP server.

  • Page 228: E-Mail Address

    SMTP Encryption Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] None / SSL-TLS / STARTTLS [-] Default value None Alternative config Step Comm object 23965 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217)
  • Page 229 Email Address 2 CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] 0..63 characters [-] Default value Alternative config Step Comm object 24297 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid e-mail address where the alarm and event e-mails shall be sent. Leave this setpoint blank if alarm and event email should not be send.
  • Page 230 Email Address 4 CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] 0..63 characters [-] Default value Alternative config Step Comm object 24144 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid e-mail address where the alarm and event e-mails shall be sent. Leave this setpoint blank if alarm and event email should not be send.

  • Page 231: Event Message

    Event Message CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] ON / OFF [-] Default value Alternative config Step Comm object 10926 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint enables or disables Event Messages. This setpoint is common for CM3-Ethernet and CM2-4G-GPS modules.
  • Page 232 MPR1 Messages CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] ON / OFF [-] Default value Alternative config Step Comm object 8484 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint enables or disables MPR1 Messages. This setpoint is common for CM3-Ethernet and CM2-4G-GPS modules.

  • Page 233: Telephone Number

    Telephone Number 1 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value Alternative config Step Comm object 24296 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid GSM phone number where the alarm messages shall be sent.
  • Page 234 Telephone Number 3 Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value Alternative config Step Comm object 24143 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid GSM phone number where the alarm messages shall be sent.

  • Page 235: Gps Tracking

    Subgroup: GPS Settings GPS Tracking Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Enabled / Disabled [-] Default value Enabled Alternative config Step Comm object 23975 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217)
  • Page 236 GPS Clock Sync Setpoint group CM-4G-GPS Related FW 1.2.0 Range [units] Enabled / Disabled [-] Default value Enabled Alternative config Step Comm object 23974 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217)
  • Page 237 Group: CM-Ethernet Subgroup: TCP/IP Settings IP Address Mode Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] MANUAL / AUTOMATIC / DISABLED [-] Default value AUTOMATIC Alternative config Step Comm object 23939 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description The setpoint is used to select the method how the ethernet connection is adjusted.

  • Page 238: Subnet Mask

    IP Address Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] 0 .. 15 characters [-] Default value 192.168.1.254 Alternative config Step Comm object 23950 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint IP Address Mode Setpoint visibility (page 237)
  • Page 239 Gateway IP Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] Valid IP address [-] Default value 192.168.1.1 Alternative config Step Comm object 23948 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint IP Address Mode Setpoint visibility (page 237)
  • Page 240 DNS IP Address 1 Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] Valid IP address [-] Default value 8.8.8.8 Alternative config Step Comm object 23947 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description The setpoint is used to select the method how the DNS Address 1 is adjusted.
  • Page 241 IP Firewall Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] ENABLED / DISABLED [-] Default value DISABLED Alternative config Step Comm object 23920 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoints enables to switch on the built-in Firewall functionality. DISABLED The firewall function is switched off The firewall function is switched on, use InteliConfig to setup the firewall rules...
  • Page 242 Setpoint visibility Only if relevant module is installed Description This port is used for TCP data communication with the AirGate server. Note: Use port 21, 23 or 6127 for standard ComAp AirGate service. 6 back to List of setpoints InteliATS 50 Global Guide...
  • Page 243 Setpoint visibility Only if relevant module is installed Description Use this to enable/disable direct connection of a ComAp client (e.g. InteliConfig) to the IP address of the controller. Note: For Direct connection the controller IP address must be reachable from the client IP address.

  • Page 244: Modbus Server

    ComAp Client Inactivity Timeout CM-Ethernet Setpoint group Related FW 1.2.0 CM-4G-GPS Range [units] 0 .. 600 [s] Default value 60 s Alternative config Step Comm object 24098 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Connection (TCP socket) is closed by controller, if a client (e.g.
  • Page 245 Subgroup: SNMP Settings SNMP Agent Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] DISABLED / ENABLED [-] Default value DISABLED Alternative config Step Comm object 23936 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enable or disable SNMP Agent.
  • Page 246 SNMP Traps IP Address 2 Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] Valid IP address [-] Default value DISABLED Alternative config Step Comm object 24094 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description IP address 2 for receiving SNMP Traps.

  • Page 247: Smtp Server Address

    Subgroup: E-mail Settings SMTP Server Address Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value global.airgate.link:9925 Alternative config Step Comm object 23942 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint is used for entering the domain name (e.g.
  • Page 248 SMTP UserName Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] 0 .. 31 characters [-] Default value Alternative config Step Comm object 23943 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Use this setpoint to enter the username for the SMTP server. Leave the setpoint blank if the SMTP server does not require authentication.

  • Page 249: E-Mail Address

    SMTP Encryption Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] None / SSL-TLS / STARTTLS [-] Default value None Alternative config Step Comm object 23938 Related applications Mains-Mains, Mains-Gen Config level Standard Only if relevant module is installed + conditioned by the setpoint Internet Setpoint visibility Connection (page 217)
  • Page 250 Email Address 2 CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] 0..63 characters [-] Default value Alternative config Step Comm object 24297 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid e-mail address where the alarm and event e-mails shall be sent. Leave this setpoint blank if alarm and event email should not be send.
  • Page 251 Email Address 4 CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] 0..63 characters [-] Default value Alternative config Step Comm object 24144 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Enter in this setpoint a valid e-mail address where the alarm and event e-mails shall be sent. Leave this setpoint blank if alarm and event email should not be send.
  • Page 252 E-mail/SMS Language CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] Depends on CU languages [-] Default value English Alternative config Step Comm object 24299 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description Use this setpoint to set the language of SMS and e-mail.
  • Page 253 Event Message CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] ON / OFF [-] Default value Alternative config Step Comm object 10926 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint enables or disables Event Messages. This setpoint is common for CM3-Ethernet and CM2-4G-GPS modules.
  • Page 254 Subgroup: NTP Settings NTP Clock Synchronization Setpoint group CM-Ethernet Related FW 1.2.0 Range [units] DISABLED / ENABLED [-] Default value DISABLED Alternative config Step Comm object 23934 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint is used to enable/disable controller time synchronization with exact time from an NTP server.
  • Page 255 Time Zone CM-4G-GPS Setpoint group Related FW 1.2.0 CM-Ethernet Range [units] GMT-12:00 .. GMT+13:00 [hours] Default value GMT+1:00 hour Alternative config Step Comm object 24366 Related applications Mains-Mains, Mains-Gen Config level Standard Setpoint visibility Only if relevant module is installed Description This setpoint is used to select the time zone where the controller is located.

  • Page 256: Values

    RemoteControl2B 3 Value group Remote Control Related FW 1.2.0 Units Comm object 16673 Related applications Mains-Mains, Mains-Gen Description This value contains user data written over MODBUS-RTU, MODBUS/TCP. Data type of this value is Int16. 6 back to List of values RemoteControl2B 4 Value group Remote Control...
  • Page 257 List of values Connection Type AirGate Status Group: Source 1 Source 1 Frequency SPI Module A AirGate ID Source 1 Voltage L1-N Timer Value AirGate Servicing Node Source 1 Voltage L2-N ID String Current IP Address Source 1 Voltage L3-N FW Version Primary DNS Source 1 Voltage L1-L2 Application Secondary DNS Source 1 Voltage L2-L3...
  • Page 258 Group: Source 1 Source 1 Frequency Value group Source 1 Related FW 1.2.0 Units Comm object 20519 Related applications Mains-Mains, Mains-Gen Description Frequency of Source 1. 6 back to List of values Source 1 Voltage L1-N Value group Source 1 Related FW 1.2.0 Units Comm object 20530 Related applications Mains-Mains, Mains-Gen...
  • Page 259 Source 1 Voltage L2-L3 Value group Source 1 Related FW 1.2.0 Units Comm object 20526 Related applications Mains-Mains, Mains-Gen Description Source 1 phase to phase voltage between L2 and L3 phases. 6 back to List of values Source 1 Voltage L3-L1 Value group Source 1 Related FW 1.2.0 Units...
  • Page 260 Source 2 Voltage L1-N Value group Source 2 Related FW 1.2.0 Units Comm object 20517 Related applications Mains-Mains, Mains-Gen Description Source 2 voltage on phase 1. 6 back to List of values Source 2 Voltage L2-N Value group Source 2 Related FW 1.2.0 Units Comm object 20516 Related applications Mains-Mains, Mains-Gen...

  • Page 261: Slip Frequency

    Source 2 Voltage L3-L1 Value group Source 2 Related FW 1.2.0 Units Comm object 20512 Related applications Mains-Mains, Mains-Gen Description Source 2 phase to phase voltage between L3 and L1 phases. 6 back to List of values Source 2 Voltage Unbalance Ph-N Value group Source 2 Related FW 1.2.0...
  • Page 262 Group: Controller I/O Battery Volts Value group Controller I/O Related FW 1.2.0 Units Comm object 8213 Related applications Mains-Mains, Mains-Gen Description Controller supply voltage. 6 back to List of values Binary Inputs Value group Controller I/O Related FW 1.2.0 Units Comm object 8235 Related applications...
  • Page 263 Pulse Counter 2 Value group Statistics Related FW 1.2.0 Units Comm object 10987 Related applications Mains-Mains, Mains-Gen Description This is the value of 286) function. ULSE OUNTER PAGE Note: Maximum value is 1000000. 6 back to List of values Group: Info Active Application Value group Info...

  • Page 264: Connection Type

    Timer Text Value group Info Related FW 1.2.0 Units Comm object 10040 Related applications Mains-Mains, Mains-Gen Description The value contains the "Current process timer" text which is shown on the main screen of the controller. 6 back to List of values Connection Type Value group Info...
  • Page 265 FW Version Value group Info Related FW 1.2.0 Units Comm object 24339 Related applications Mains-Mains, Mains-Gen Description Major and minor firmware version number. 6 back to List of values Application Value group Info Related FW 1.2.0 Units Comm object 8480 Related applications Mains-Mains, Mains-Gen Description...
  • Page 266 Log Bout 3 Value group Log Bout Related FW 1.2.0 Units Comm object 9145 Related applications Mains-Mains, Mains-Gen Description State of binary outputs. 6 back to List of values Log Bout 4 Value group Log Bout Related FW 1.2.0 Units Comm object 9146 Related applications...
  • Page 267 Group: Fixed Protection States Fixed Protections States 1 Fixed Protection Value group Related FW 1.2.0 States Units Comm object 20744 Related applications Mains-Mains, Mains-Gen Description Values of LBO Fixed Protections State. 6 back to List of values Fixed Protections States 2 Fixed Protection Value group Related FW...
  • Page 268 Date Value group Date/Time Related FW 1.2.0 Units DD.MM.YYYY Comm object 24553 Related applications Mains-Mains, Mains-Gen Description Shows setup date. 6 back to List of values Time Mode Value group Date/Time Related FW 1.2.0 Units HH:MM:SS Comm object 20252 Related applications Mains-Mains, Mains-Gen Description Indicates actual time mode.

  • Page 269: Network Status

    Network Status Value group CM-4G-GPS Related FW 1.2.0 Units Comm object 24290 Related applications Mains-Mains, Mains-Gen Description The text of this value represents the status of the GSM modem. Code Description Not availab Not available Available Available Attached Attached 6 back to List of values InteliATS 50 Global Guide...
  • Page 270 Last Email Result Value group CM-4G-GPS Related FW 1.2.0 Units Comm object 24307 Related applications Mains-Mains, Mains-Gen Description Result of last email, which was sent by controller. Code Description Email was successfully sent. It is not possible to establish connection with SMTP server. SMTP server is not ready for communication.

  • Page 271: Network Name

    Network Name Value group CM-4G-GPS Related FW 1.2.0 Units Comm object 24147 Related applications Mains-Mains, Mains-Gen Description The name of operator which to SIM card is connected. Note: If roaming service is used then prefix "R" is added before the name of operator. 6 back to List of values Network Mode Value group...
  • Page 272 Longitude Value group CM-4G-GPS Related FW 1.2.0 Units Comm object 24267 Related applications Mains-Mains, Mains-Gen Description Actual GPS longitude. Positions on east hemisphere have positive value, position on west hemisphere have negative value. 6 back to List of values Active Satellites Value group CM-4G-GPS Related FW...
  • Page 273 AirGate Status Value group CM-4G-GPS Related FW 1.2.0 Units Comm object 24308 Related applications Mains-Mains, Mains-Gen Description Diagnostic code for AirGate connection. Helps in troubleshooting. AirGate Status Code Description Not defined Setpoint AirGate Connection is Disabled Wait to connect Waiting to connect Resolving Resolving Connecting...
  • Page 274 Current IP Address Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24184 Related applications Mains-Mains, Mains-Gen Description Current IP address of the controller. 6 back to List of values Primary DNS CM-Ethernet Value group Related FW 1.2.0 CM-4G-GPS Units Comm object 24181 Related applications...
  • Page 275 It is not possible to set manually chosen network mode 2G/3G/4G/Automatic It is not possible to register into cellular network. Possible reasons: No signal (no coverage, broken or unconnected antenna) E registration Manually chosen network mode 2G/3G/4G is not available It is not possible to set PDP (Packet Data Protocol) context for defined APN (Access Point Name).
  • Page 276 Current IP Address Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24184 Related applications Mains-Mains, Mains-Gen Description Current IP address of the controller. 6 back to List of values Current Subnet Mask Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24183 Related applications...
  • Page 277 AirGate ID Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24345 Related applications Mains-Mains, Mains-Gen Description Identification string generated by AirGate server for the purpose of establishing communication via InteliConfig or any other supported PC tool. 6 back to List of values AirGate Servicing Node Value group CM-Ethernet...
  • Page 278 Last Email Results Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24332 Related applications Mains-Mains, Mains-Gen Description Result of last email, which was sent by controller. Code Description Email was successfully sent. It is not possible to establish connection with SMTP server. SMTP server is not ready for communication.
  • Page 279 Ethernet PHY Mode Value group CM-Ethernet Related FW 1.2.0 Units Comm object 24088 Related applications Mains-Mains, Mains-Gen Description Ethernet interface mode: 10- HD 10 Mbit Half-Duplex 10- FD 10 Mbit Full-Duplex 100- HD 100 Mbit Half-Duplex 10- FD 100 Mbit Full-Duplex 6 back to List of values Group: Plug-In I/O EM BIO A...
  • Page 280 User Button 2 Value group User Buttons Related FW 1.2.0 Units Comm object 20827 Related applications Mains-Mains, Mains-Gen Description State of User Button 2. Note: For more information see User Buttons on page 99. 6 back to List of values User Button 3 Value group User Buttons...
  • Page 281 User Button 6 Value group User Buttons Related FW 1.2.0 Units Comm object 20831 Related applications Mains-Mains, Mains-Gen Description State of User Button 6. Note: For more information see User Buttons on page 99. 6 back to List of values User Button 7 Value group User Buttons...

  • Page 282: Logical Binary Inputs

    8.1.4 Logical binary inputs What Logical binary inputs are: Logical binary inputs are inputs for binary values and functions. Alphabetical groups of Logical binary inputs LBI: A LBI: E LBI: F LBI: G LBI: H LBI: N LBI: P LBI: R LBI: S LBI: T For a full list of Logical binary inputs go to the chapter...
  • Page 283 Logical binary inputs alphabetically Access Lock Emergency Stop Fault Reset Button Geo Home Position Geo-Fencing Enable Horn Reset Button Neutral Position Protection Force Disable 285 Pulse Counter 1 Pulse Counter 2 Remote AUTO Remote Ctrl Lock Remote MAN Remote OFF Remote Start/Stop S1 Fail Block S1CB Button S1CB Feedback...

  • Page 284: Access Lock

    1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description Binary input has the same function as Fault Reset button on the InteliATS2 50 front panel. 6 back to Logical binary inputs alphabetically LBI: G Geo Home Position Related FW 1.2.0 Related applications...

  • Page 285: Geo-Fencing Enable

    1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description Binary input has the same function as Horn reset button on the InteliATS2 50 front panel. 6 back to Logical binary inputs alphabetically LBI: N Neutral Position Related FW 1.2.0 Related applications...

  • Page 286: Pulse Counter 1

    Pulse Counter 1 Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description This is the input of the Pulse Counter 1 function. The module counts pulses at the input and if the input pulses counter reaches value given by the setpoint Conversion Coefficient Pulse 1 (page 143) counter value Pulse Counter 1 (page 262)

  • Page 287: Remote Ctrl Lock

    Remote Ctrl Lock Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description If the input is active, the controller will not accept any actions regarding the system control – e.g. writing of commands and setpoint changes via remote communication interfaces. 6 back to Logical binary inputs alphabetically Remote MAN Related FW...

  • Page 288: Remote Start/Stop

    Remote Start/Stop Related FW 1.2.0 Related applications Mains-Gen Comm object Description Use this input to start and stop the engine in AUTO mode. Note: If the binary input Remote Start/Stop is active and engine is running and Source 1 failure occurs, the S1CB breaker opens, after Open Transfer Min Break (page 150) the S2CB breaker is closed.

  • Page 289: S1 Fail Block

    Use this input for indication whether the Source 1 circuit breaker is open or closed. Image 15.18 S1CB Feedback Note: InteliATS2 50 controller can work even without breaker feedbacks, in this case do not configure the feedback to binary inputs. 6 back to Logical binary inputs alphabetically...

  • Page 290: S2 Block

    Use this input for indication whether the Source 2 circuit breaker is open or closed. Image 15.19 S2CB Feedback 1 Note: InteliATS2 50 controller can work even without breaker feedbacks, in this case do not configure the feedback to binary inputs.

  • Page 291: Source 2 Ready To Load

    Related applications Mains-Gen Comm object Description Binary input has the same function as Start Button on the InteliATS2 50 front panel. It is evaluated in MAN mode only. 6 back to Logical binary inputs alphabetically Stop Button Related FW 1.2.0...

  • Page 292: Switch To Man

    Switch To MAN Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 1111 Description When the first rising edge appears on the binary input, the MODE is changed to MAN. Falling edge has no effect and controller stays in MAN MODE. There is no blocking between these "Switch To"...

  • Page 293: Total Emergency Stop

    LBI: T Total Emergency Stop Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description This binary input opens S1CB or S2CB breaker depends which one is at the moment of input activation closed. In addition when Source 2 is the engine it deactivates LBO 302).

  • Page 294: Logical Binary Outputs

    8.1.5 Logical binary outputs What Logical binary outputs are: Logical binary outputs are outputs for binary values and functions. Alphabetical groups of Logical binary outputs LBO: A LBO: C LBO: E LBO: F LBO: G LBO: H LBO: I LBO: M LBO: N LBO: R LBO: S LBO: U...

  • Page 295: Back To Controller

    Logical binary outputs alphabetically AIN Switch01 Neutral Close/Open 6 back to Controller objects AIN Switch02 Neutral ON Coil AL Common BOS Not In AUTO AL Common MP Not Used AL Common MP2 Ready To AMF AL Common MPR S1 Healthy AL Common MPR2 S1 Ready To Load AL Common Wrn...

  • Page 296: Ain Switch01

    LBO: A AIN Switch01 Mains-Mains, Mains- Related FW 1.2.0 Related applications Comm object 1400 Description This is an output from the General Analog Input 1 switch function. The behavior of the switch depends on the adjustment of the setpoints AIN Switch01On (page 193) AIN Switch01 Off (page 194).

  • Page 297: Al Common Bos

    AL Common BOS Related FW 1.2.0 Related applications Mains-Gen Comm object Description Output is activated when any BOS alarm appears. The output opens, if: No BOS alarm is active and Fault reset button is pressed 6 back to Logical binary outputs alphabetically AL Common MP Related FW 1.2.0...

  • Page 298: Al Common Mpr2

    AL Common MPR2 Related FW 1.2.0 Related applications Mains-Mains Comm object Description Output is activated when MPR2 alarm appears. The output opens, if: No MPR2 alarm is active and Fault reset button is pressed 6 back to Logical binary outputs alphabetically AL Common Wrn Related FW 1.2.0...

  • Page 299: Al S2 Fail

    AL S2 Fail Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 2561 Description This output is active when there is active any Source 2 level 2 protection (fixed or user protection). 6 back to Logical binary outputs alphabetically AL S2 Freq Wrn Related FW 1.2.0 Related applications...

  • Page 300: Alarm

    Alarm Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description The output is designed to be used as external alarm indication such as a red bulb in the control room etc. The output is active when there is active alarm or inactive unconfirmed alarm present in the alarmlist and remains active until confirmation of alarm.

  • Page 301: Electrical Alarm

    LBO: E Electrical Alarm Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 2410 Description LBO Electrical Alarm is active when any fixed protection of level 2 is unconfirmed in the alarmlist (counts both active and inactive alarms). 6 back to Logical binary outputs alphabetically Elevator Switch Related FW 1.2.0...

  • Page 302: Fltres Button State

    FltRes Button State Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 2695 Description LBO is active as long as it's button is pressed or it's LBI is active. 6 back to Logical binary outputs alphabetically LBO: G Gen Start/Stop Related FW 1.2.0 Related applications...

  • Page 303: Horn

    Horn Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description The output designed to be used for acoustic indication of a newly appeared alarm. The output is activated each time a new alarm has appeared and remains active until one of the following events occurs: Fault reset is pressed Horn reset...

  • Page 304: Mode Auto

    The output controls the neutral position of the three positions ATS switch. The ATS switch must react within 5 seconds to a close or open command, otherwise an alarm is issued. Note: InteliATS2 50 controllers can work even without breaker feedbacks, in this case do not configure the feedback to binary inputs.

  • Page 305: Not In Auto

    Not In AUTO Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 1248 Description This output is active when controller isn’t in AUTO mode. 6 back to Logical binary outputs alphabetically Not Used Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description Output has no function.

  • Page 306: S1 Ready To Load

    The breaker must react within 5 seconds to a close or open command, otherwise an alarm is issued. Note: InteliATS2 50 controllers can work even without breaker feedbacks, in this case do not configure the feedback to binary inputs. InteliATS 50 Global Guide...

  • Page 307: S1Cb Off Coil

    Image 15.22 S1CB Close command 6 back to Logical binary outputs alphabetically S1CB OFF Coil Mains-Mains, Mains- Related FW 1.2.0 Related applications Comm object Description The output is intended for control of open coil of Source 1 circuit breaker. The output gives a pulse in the moment the breaker has to be opened.

  • Page 308: S1Cb On Coil

    S1CB ON Coil Mains-Mains, Mains- Related FW 1.2.0 Related applications Comm object Description The output is intended for control of close coil of S1CB circuit breaker. Image 15.24 S1CB ON Coil close command 6 back to Logical binary outputs alphabetically S1CB Status Related FW 1.2.0...

  • Page 309: S1Cb Uv Coil

    S1CB UV Coil Mains-Mains, Mains- Related FW 1.2.0 Related applications Comm object Description The output is intended for control of undervoltage coil of S1CB circuit breaker. The output is active the whole time when the controller is switched on. The output is deactivated for 5 seconds in the moment the breaker has to be switched off.

  • Page 310: S2 Healthy

    S2 Healthy Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object 2551 Description The LBO is active when Source 2 frequency and voltages are within the protection limits. AL S1 Fail – is active when: active S1 protection (fixed or user) level 2. inactive S1 protection (fixed or user) level 2 not confirmed.
  • Page 311 The breaker must react within 5 seconds to a close or open command, otherwise an alarm is issued. Note: InteliATS2 50 controllers can work even without breaker feedbacks, in this case do not configure the feedback to binary inputs. Image 15.27 S2CB Close command Image 15.28 S2CB Open command...

  • Page 312: S2Cb Off Coil

    S2CB OFF Coil Mains-Mains, Mains- Related FW 1.2.0 Related applications Comm object Description The output is intended for control of open coil of generator circuit breaker. The output gives a pulse in the moment the breaker has to be opened. Image 15.29 S2CB OFF Coil command 6 back to Logical binary outputs alphabetically S2CB ON Coil...

  • Page 313: S2Cb Status

    S2CB Status Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description This output indicates the S2CB position (circuit breaker is closed or opened) as it is internally considered by the controller. In case the S2CB feedback is configured the S2CB Status reflects the S2CB F EEDBACK PAGE...

  • Page 314: Start Button Echo

    Image 15.32 S2CB UV Coil open command 6 back to Logical binary outputs alphabetically Start Button Echo Related FW 1.2.0 Related applications Mains-Gen Comm object Description This output provides 1s pulse when: Start button is pressed on the controller front facia or Start button is pressed on any of external local/remote terminals or Start command is received via communication line or the input S...

  • Page 315: User Button

    Still Log 1 Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description Logical binary output which is still in logical 1. 6 back to Logical binary outputs alphabetically Stop Button Echo Related FW 1.2.0 Related applications Mains-Gen Comm object Description This output provides 1s pulse when: Stop button is pressed on the controller front facia or...
  • Page 316 User button 3 Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description 6 back to Logical binary outputs alphabetically User button 4 Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description 6 back to Logical binary outputs alphabetically User button 5 Related FW 1.2.0...

  • Page 317: Logical Analog Inputs

    8.1.6 Logical analog inputs What Logical analog inputs are: Logical analog inputs are inputs for analog values. AIN Switch 01 AIN Switch 02 AIN Switch 01 Related FW 1.2.0 Related applications Mains-Mains, Mains-Gen Comm object Description Logical analog input designed for any analog value available in the controller. This analog input controls logical binary output AIN S 01 (...
  • Page 318 List of alarms level 1 Wrn Module(slotA) - false module Wrn S2CB Fail To Open Wrn Module(slotA) - unknown module Wrn S2CB Fail To Close Wrn Module(slotA) - unattended Wrn Source 2 L1 Overvoltage Wrn Module(slotA) - comm. outage Wrn Source 2 L2 Overvoltage Wrn Module(slotA) - unexpected Wrn Source 2 L3 Overvoltage Wrn EM(A) - a message lost...

  • Page 319: Wrn Module(Slota) - False Module

    Wrn Module(slotA) - false module Alarm Type Alarmlist message Module(slotA) - fake module Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen Description This alarm indicates that false module is inserted in slot. 6 back to List of alarms level 1 Wrn Module(slotA) - unknown module Alarm Type Alarmlist message...

  • Page 320: Wrn Em(A) - A Message Lost

    Wrn EM(A) - a message lost Alarm Type Alarmlist message EM(A) - a message lost Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm indicates that there is a problem with communication between Description controller and module in slot. 6 back to List of alarms level 1 Wrn EM(A) - configuration mistake Alarm Type...

  • Page 321: Wrn Event Email 2 Fail

    wasn't send. 6 back to List of alarms level 1 Wrn Event Email 2 Fail Alarm Type Alarmlist message Event Email 2 Fail Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen The alarm indicates that there was a request to send an event email to email Description address which is adjusted in setpoint Email Address 2 (page 250)

  • Page 322: Wrn Event Sms 2 Fail

    Wrn Event SMS 2 Fail Alarm Type Alarmlist message Event SMS 2 Fail Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen The alarm indicates that there was a request to send an event SMS to telephone Description number which is adjusted in setpoint Telephone Number 2 (page 233) SMS wasn't send.

  • Page 323: Wrn Alarm Email 3 Fail

    Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen The alarm indicates that there was a request to send an alarm email to email Description address which is adjusted in setpoint Email Address 2 (page 250) and email wasn't send. 6 back to List of alarms level 1 Wrn Alarm Email 3 Fail Alarm Type...

  • Page 324: Wrn Alarm Sms 3 Fail

    SMS wasn't sent. 6 back to List of alarms level 1 Wrn Alarm SMS 3 Fail Alarm Type Alarmlist message Alarm SMS 3 Fail Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen The alarm indicates that there was a request to send an alarm SMS to telephone Description number which is adjusted in setpoint Telephone Number 3 (page 234)

  • Page 325: Wrn Passwenterblock

    Wrn PasswEnterBlock Alarm Type Alarmlist message PasswEnterBlock Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm is issued to indicate that user will not be able to type in password for set amount of time. Description Note: This is cause by too many invalid attempts. 6 back to List of alarms level 1 Wrn Default Password Alarm Type...

  • Page 326: Wrn Stop Fail

    Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm is active when there is no email address set in the controller and simultaneously controller administrator password is not the default password. Description Note: When default password is changed the Wrn Password reset e-mail addr is not set will be active after the restart of the controller.

  • Page 327: Wrn S1Cb Fail To Open

    Wrn S1CB Fail To Open Alarm Type Alarmlist message Wrn S1CB Fail To Open Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen The alarm is activated when the breaker (feedback) doesnt react to the open Description command of the controller. 6 back to List of alarms level 1 Wrn S1CB Fail To Close Alarm Type...

  • Page 328: Wrn Source 2 L1 Overvoltage

    6 back to List of alarms level 1 Wrn Source 2 L1 Overvoltage Alarm Type Alarmlist message Source 2 L1 > Voltage Alarm evaluated Engine running Related applications Mains-Gen This alarm evaluates the Source 2 phase voltage in phase 1. The following setpoints are related to it: Description Source 2 Overvoltage Wrn (page 170) Source 2 <...

  • Page 329: Wrn Source 2 L2L3 Overvoltage

    Source 2 < > Voltage Delay (page 175) 6 back to List of alarms level 1 Wrn Source 2 L2L3 Overvoltage Alarm Type Alarmlist message Source 2 L2L3 > Voltage Alarm evaluated Engine running Related applications Mains-Gen This alarm evaluates the Source 2 phase to phase voltage between phases 2 and 3.

  • Page 330: Wrn Source 2 L3 Undervoltage

    Source 2 Undervoltage Wrn (page 173) Source 2 < > Voltage Delay (page 175) 6 back to List of alarms level 1 Wrn Source 2 L3 Undervoltage Alarm Type Alarmlist message Source 2 L3 < Voltage Alarm evaluated Engine running Related applications Mains-Gen This alarm evaluates the Source 2 phase voltage in phase 3. The following setpoints are related to it: Description Source 2 Undervoltage Wrn (page 173)

  • Page 331: Wrn Source 2 Overfrequency

    This alarm evaluates the Source 2 phase to phase voltage between phases 3 and 1. The following setpoints are related to it: Description Source 2 Undervoltage Wrn (page 173) Source 2 < > Voltage Delay (page 175) 6 back to List of alarms level 1 Wrn Source 2 Overfrequency Alarm Type Alarmlist message...

  • Page 332: Wrn Battery Overvoltage

    Wrn Battery Overvoltage Alarm Type Alarmlist message All the time Alarm evaluated Wrn Battery > Voltage Related applications Mains-Mains, Mains-Gen This alarm informs the operator that the controller supply voltage is too high. The following setpoints are related to it: Description Battery Overvoltage (page 141) Battery <>...

  • Page 333: Back To Alarms

    List of alarms level 2 BOS Emergency Stop MP2 Source 2 Voltage Unbalance ph-n Total Emergency Stop MP2 Source 2 Voltage Unbalance ph-ph BOS Start Fail Parallel Work BOS S2CB Fail To Open BOS Source 2 L1 Overvoltage BOS S2CB Fail To Open BOS Source 2 L1 Undervoltage BOS Fence 1 Alarm BOS Source 2 L1L2 Overvoltage...

  • Page 334: Bos Emergency Stop

    BOS Emergency Stop Alarm Type Alarmlist message BOS Emergency Stop Alarm evaluated All the time Related applications Mains-Gen Alarm is activated when binary input 284) is activated. MERGENCY PAGE The Source 2 shuts down in the moment the input is activated and starting is blocked until the input is deactivated and fault reset is pressed.

  • Page 335: Bos S2Cb Fail To Open

    stays active until the mismatch between the output and feedback disappears. If there was no command issued by the controller and the breaker (feedback) changes suddenly the position itself, the alarm will be issued immediately. Self-opening of the breaker is not considered a fault and if all Source 2 values are within limits, the command to reclose the breaker is issued after 5s delay.

  • Page 336: Bos Fence 2 Alarm

    Geo-Fencing (page 208) Fence 1 Protection (page 210) Fence Radius 1 (page 210) 6 back to List of alarms level 2 BOS Fence 2 Alarm Alarm Type Alarmlist message BOS Fence 2 Alarm Alarm evaluated All the time Related applications Mains-Gen This alarm evaluates the GPS position of Source 2.

  • Page 337: Mp Source 1 L1L2 Overvoltage

    MP Source 1 L1L2 Overvoltage Alarm Type Alarmlist message Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm evaluates the Source 1 phase voltage in phases L1 and L2. The following setpoints are related to it: Source 1 Overvoltage (page 154) Description Source 1 Overvoltage Delay (page 154) Note: Alarm is active only in case the setpoint...

  • Page 338: Mp Source 1 L2L3 Overvoltage

    Alarmlist message Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm evaluates the Source 1 L2-N voltage. The following setpoints are related to it: Source 1 Overvoltage (page 154) Description Source 1 Overvoltage Delay (page 154) Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph4Wire.

  • Page 339: Mp Source 1 L3 Undervoltage

    This alarm evaluates the Source 1 L3-N voltage. The following setpoints are related to it: Source 1 Overvoltage (page 154) Description Source 1 Overvoltage Delay (page 154) Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph4Wire. 6 back to List of alarms level 2 MP Source 1 L3 Undervoltage Alarm Type...

  • Page 340: Mp Source 1 Voltage Unbalance Ph-Ph

    Source 1 Overvoltage Delay (page 154) Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph3Wire or High Leg D or SplitPhase. 6 back to List of alarms level 2 MP Source 1 Voltage Unbalance ph-ph Alarm Type Alarmlist message MP Source 1 Voltage Unbalance ph-ph...

  • Page 341: Mp Source 1 Underfrequency

    MP Source 1 Underfrequency Alarm Type Alarmlist message Source 1 Underfrequency Alarm evaluated All the time Related applications Mains-Mains, Mains-Gen This alarm is active when Mains frequency is bellow the setpoint Source 1 Description Underfrequency (page 160) for the period longer than Source 1 < > Frequency Delay (page 162).

  • Page 342: Mp2 Source 2 L1L2 Undervoltage

    MP2 Source 2 L1L2 Undervoltage Alarm Type Alarmlist message Alarm evaluated All the time Related applications Mains-Mains This alarm evaluates the Source 2 phase voltage in phases L1 and L2. The following setpoints are related to it: Description Source 2 Undervoltage (page 172) Source 2 <...

  • Page 343: Mp2 Source 2 L2L3 Undervoltage

    6 back to List of alarms level 2 MP2 Source 2 L2L3 Undervoltage Alarm Type Alarmlist message Alarm evaluated All the time Related applications Mains-Mains This alarm evaluates the Source 2 phase voltage in phases L2 and L3. The following setpoints are related to it: Description Source 2 Undervoltage (page 172) Source 2 <...

  • Page 344: Mp2 Source 2 L3L1 Undervoltage

    Source 2 < > Voltage Delay (page 175) 6 back to List of alarms level 2 MP2 Source 2 L3L1 Undervoltage Alarm Type Alarmlist message Alarm evaluated All the time Related applications Mains-Mains This alarm evaluates the Source 2 phase voltage in phases L3 and L1. The following setpoints are related to it: Description Source 2 Undervoltage (page 172)

  • Page 345: Mp2 Source 2 Voltage Unbalance Ph-Ph

    difference between the highest and lowest phase voltage at any given time. Source 2 Voltage Unbalance Delay (page 176) adjusts the alarm delay. 6 back to List of alarms level 2 MP2 Source 2 Voltage Unbalance ph-ph Alarm Type Alarmlist message MP2 Source 2 Voltage Unbalance ph-ph Alarm evaluated All the time Related applications...

  • Page 346: Bos Source 2 L1L2 Overvoltage

    Alarm evaluated Engine running Related applications Mains-Gen This alarm evaluates the Source 2 L1-N voltage. The following setpoints are related to it: Source 2 Undervoltage (page 172) Description Source 2 < > Voltage Delay (page 175) Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph4Wire or MonoPhase.

  • Page 347: Bos Source 2 L2 Undervoltage

    related to it: Source 2 Overvoltage (page 169) Source 2 < > Voltage Delay (page 175) Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph4Wire. 6 back to List of alarms level 2 BOS Source 2 L2 Undervoltage Alarm Type Alarmlist message BOS Source 2 L2 Undervoltage...

  • Page 348: Bos Source 2 L3 Overvoltage

    Note: Alarm is active only in case the setpoint Connection type (page 138) is set to 3Ph3Wire or High Leg D. 6 back to List of alarms level 2 BOS Source 2 L3 Overvoltage Alarm Type Alarmlist message BOS Source 2 L3 Overvoltage Alarm evaluated Engine running Related applications...

  • Page 349: Bos Source 2 L3L1 Undervoltage

    BOS Source 2 L3L1 Undervoltage Alarm Type Alarmlist message BOS Source 2 L3L1 Undervoltage Alarm evaluated Engine running Related applications Mains-Gen This alarm evaluates the Source 2 phase voltage in phases L3 and L1. The following setpoints are related to it: Source 2 Undervoltage (page 172) Description Source 2 <...

  • Page 350: Bos Source 2 Overfrequency

    BOS Source 2 Overfrequency Alarm Type Alarmlist message BOS Source 2 Overfrequency Alarm evaluated Engine running Related applications Mains-Gen This alarm is active when Source 2 frequency is above the setpoint Source 2 Description Overfrequency (page 177) for the period longer than Source 2 <> Frequency Delay (page 182).

  • Page 351: Modules

    CM2-4G-GPS CM-RS232-485 CM-RS232-485 is optional plug-in card to enable InteliATS2 50 the RS232 and RS485 communication. The CM-RS232-485 is a dual port module with RS232 and RS485 interfaces at independent COM channels. The RS232 is connected to COM1 and RS485 to COM2.
  • Page 352 Image 15.35 Pinout of RS232 line Image 15.36 Pinout of RS485 line Image 15.37 Jumpers description Note: Balancing resistors should both be closed at only one device in the whole RS485 network. Maximal distance of line is 10 m for RS232 line and 1200 m for RS485 line. Terminator 120 Ω...

  • Page 353: Firmware Upgrade

    Galvanic separation Firmware upgrade Download the newest FW of module from ComAp website (in form of PSI file or installation package) Install package to computer or open PSI to install it into InteliConfig Plug the module into the controller and power the controller on.
  • Page 354 Image 15.39 Cross-wired cable Technical data General Width × Height × Depth 73.8 × 50.3 × 21 Weight ~30 g Power supply 8-36 V DC Power consumption 1 W Peak power consumption 2 W Operating temperature -40 ˚C to +70 ˚C Storage temperature -40 ˚C to +80 ˚C Ethernet port 100 Mbit/s, full duplex...
  • Page 355 Firmware upgrade Download the newest FW of module from ComAp website (in form of PSI file or installation package) Install package to computer or open PSI to install it into InteliConfig Plug the module into the controller and power the controller on.
  • Page 356 4G module types If the anthenna is CELLULAR only and has 1 cable (OT1A4GXXMCX), it is connected to the 4G-MAIN connector. If the anthenna is CELLULAR only and has 2 cables, cables are connected to the 4G-MAIN or 4G-DIV connectors (does not matter which cable to which connector). If the anthenna is a combination of CELLULAR/GPS and has 2 cables (OT1A4GGPSCX), then cable "4G/LTE"...
  • Page 357 Bd17>, Bd28) 800 (Bd18, Bd19, Bd20) 850 (Bd5) / 900 (Bd8) / AWS (Bd4) / 1800 (Bd3) / 1900 (Bd2) / 2100 (Bd1) / 2600MHz (Bd7) Antenna interface 2x SMA female (Main and Diversity) SIM card settings SIM card must be adjusted as follows: SMS service enabled Packet data (Internet access) enabled (when required for the selected mode of operation) PIN code security disabled...
  • Page 358 Image 15.42 Screen of AirGate Modem Status Code Description Module successfully initialized and connected to the cellular network Unsuccessful restore to the factory settings Modem configuration error SIM not inserted or locked by PIN. E SIM Use another device (e.g. mobile phone) to disable the option for SIM to be locked by PIN It is not possible to set manually chosen network mode 2G/3G/4G/Automatic It is not possible to register into cellular network.

  • Page 359: Extension Modules

    AirGate is not set in the controller Firmware upgrade Download the newest FW of module from ComAp website (in form of PSI file or installation package) Install package to computer or open PSI to install it into InteliConfig Plug the module into the controller and power the controller on.
  • Page 360 Image 15.43 EM-BIO8-EFCP interface IMPORTANT: Any manipulation with plug-in module shall be done with disconnected power supply to controller. Image 15.44 Overview of EM-BIO8-EFCP EM-BIO8-EFCP technical data Power supply Power supply range 8-36 VDC 40 mA / 8 VDC 27 mA / 12 VDC Power consumption 22 mA / 24 VDC 19 mA / 36 VDC...
  • Page 361 Firmware upgrade Download the newest FW of module from ComAp website (in form of PSI file or installation package) Install package to computer or open PSI to install it into InteliConfig Plug the module into the controller and power the controller on.
