PowerManager – MANUAL | 1
ORDER-CODES:
KPM-100
DATASHEET KPM-100
KentixONE Operating mode
SiteManager Operation
Stand-alone operation
Further information on the operating mode
Overview
The Kentix PowerManager is the management unit for Kentix SmartPDU components and energy
consumption meters with an RS-485 interface. The PowerManager is network-compatible and is
supplied with voltage via Power over Ethernet (PoE).
© Kentix GmbH. This file was automatically generated on 2025-02-16 21:19:06. Please visit
docs.kentix.com
for the
latest documentation.

Advertisement

loading
Need help?

Need help?

Do you have a question about the PowerManager KPM-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Kentix PowerManager KPM-100

  • Page 1 Further information on the operating mode Overview The Kentix PowerManager is the management unit for Kentix SmartPDU components and energy consumption meters with an RS-485 interface. The PowerManager is network-compatible and is supplied with voltage via Power over Ethernet (PoE).
  • Page 2: Safety Instructions

    Kentix accepts no liability for damage to the equipment or components resulting from incorrect installation. No liability is accepted for incorrectly programmed units. Kentix shall not be liable in the event of malfunctions, damage to property or other damage. Use of the products, transport and storage Protect the device during transport, storage and operation from Protect moisture, dirt and damage.
  • Page 3 Applying an external power supply may destroy the module. The power supply of the AcessManager is exclusively via PoE. © Kentix GmbH. This file was automatically generated on 2025-02-16 21:19:06. Please visit docs.kentix.com for the latest documentation.
  • Page 4 (+) 24VDC (power supply RFID reader) (-) GND (power supply RFID reader) BUS-B (communication line to RFID reader) BUS-A (communication line to RFID reader) © Kentix GmbH. This file was automatically generated on 2025-02-16 21:19:06. Please visit docs.kentix.com for the latest documentation.
  • Page 5: Factory Settings

    The factory IP addresses at a glance: SiteManager and AlarmManager 192.168.100.222 MultiSensor 192.168.100.223 AccessManager 192.168.100.224 PowerManager 192.168.100.225 SmartPDU 192.168.100.226 Factory IP addresses, subnet mask: 255.255.255.0 © Kentix GmbH. This file was automatically generated on 2025-02-16 21:19:06. Please visit docs.kentix.com for the latest documentation.
  • Page 6: Reset To Factory Settings

    Before you start the configuration, make sure that the software is up to date on all network-enabled Kentix devices. The version status must be the same on all devices. You can download the latest software here: KentixONE © Kentix GmbH. This file was automatically generated on 2025-02-16 21:19:06. Please visit docs.kentix.com for the latest documentation.
