Summary of Contents for DeWalt DWE4100

  • Page 1 DWE4100 DWE4151...
  • Page 2 English (original instructions) Copyright D Copyright D WALT WALT...
  • Page 3 Fig. A Fig. B1 Fig. B2...
  • Page 4 Fig. C Fig. D Fig. E1 Fig. E2 Fig. G Fig. F...

  • Page 5: Technical Data

    English SMALL ANGLE GRINDER DWE4100, DWE4151 Congratulations! An estimation of the level of exposure to vibration and/ or noise should also take into account the times when the You have chosen a D WALT tool. Years of experience, thorough tool is switched off or when it is running but not actually...

  • Page 6: General Power Tool Safety Warnings

    English DANGER: Indicates an imminently hazardous e ) When operating a power tool outdoors, use an situation which, if not avoided, will result in death or extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock. serious injury.

  • Page 7: Additional Specific Safety Rules

    English d ) Store idle power tools out of the reach of children not match the mounting hardware of the power tool will and do not allow persons unfamiliar with the power run out of balance, vibrate excessively and may cause loss tool or these instructions to operate the power tool.

  • Page 8: Kickback And Related Warnings

    English q ) Do not use Type 11 (flaring cup) wheels on this tool. selected wheel. Wheels for which the power tool was not Using inappropriate accessories can result in injury. designed cannot be adequately guarded and are unsafe. r ) Always use side handle. Tighten the handle securely. b ) The grinding surface of centre depressed wheels must be mounted below the plane of the guard lip.

  • Page 9: Additional Safety Instructions For Wire Brushing Operations

    English Mains Plug Replacement e ) Support panels or any oversized workpiece to minimize the risk of wheel pinching and kickback. (U.K. & Ireland Only) Large workpieces tend to sag under their own weight. If a new mains plug needs to be fitted: Supports must be placed under the workpiece near the line •...

  • Page 10: Intended Use

    A Type 1/41/Type A (cut-off) wheel guard The DWE4100 and DWE4151 heavy-duty angle grinders have must be used for any wheel where surface grinding is forbidden.
  • Page 11 English wheel breakage and wheel contact. See the Accessory retained and reinstalled to use the One‑Touch guard. Noting the position of these parts before disassembly will Chart for more information. aid in reassembly. 1. Place the tool on a table, guard up. 1.

  • Page 12: Prior To Operation

    English Mounting Wire Cup Brushes and Wire Wheels WARNING: (Fig. A) • Ensure all materials to be ground or cut are secured in place. WARNING: Failure to properly seat the flange/ clamp nut/ • Secure and support the workpiece. Use clamps or a vise to hold wheel could result in serious injury (or damage to the tool and support the workpiece to a stable platform.
  • Page 13 English Precautions To Take When Working on a Painted circuit breaker, accidental unplugging, or power failure. If the slider switch is locked on when the power is connected, Workpiece the tool will start unexpectedly. 1. Sanding or wire brushing of lead based paint is NOT To start the tool, slide the ON/OFF slider switch ...

  • Page 14: Maintenance

    English Rough Grinding NOTICE: Edge grinding/cutting with a Type 27 wheel must be limited to shallow cutting and notching—less never use a cutting disc for roughing. than 13 mm in depth when the wheel is new. Reduce the Always use the guard Type B. depth of cutting/notching equal to the reduction of the The best roughing results are achieved when setting the wheel radius as it wears down.

  • Page 15: Accessory Chart

    English Protecting the Environment Accessory Chart Max. Min. Peripheral Threaded hole [mm] [mm] Rotation speed length [min. [m/s] [mm] Products/batteries are recyclable, but if marked with the 22,23 11,800 crossed-out bin, they must not be disposed of with normal household waste. 22,23 11,800 Run the batteries down completely and separate them, and...
  • Page 16 English Additional information for guards and Accessories ≤10 mm When using segmented diamond wheels, use only diamond wheels with a peripheral gap not greater than 10 mm and negative rake angle. DO NOT USE segmented diamond wheels with a peripheral gap greater than 10 mm and/or a positive rake angle.
  • Page 17 English DWE4100, DWE4151 Accessory and Guard Applications Application Accessory Type Accessory guard Assembly for Reference Surface Wheel Type 27 Grinding Type B (Grinding) Wheel Type 41 (1A) (metal) Type A (Closed cut off) Wheel Type 42 (27A) (metal) Type A (Closed cut off)
  • Page 18 Rubber backing pad and sanding clamp nut (included with rubber backing pad) available at additional cost from your local D WALT dealer or authorised D WALT service centre. guidelines for guards and Accessories for DWE4100, DWE4151 non‑approved Wheels for Type 11 / T11 DWE4100, DWE4151...
  • Page 20 Australia / New Zealand Tel: Aust 1800 338 002 www.dewalt.com.au Tel: NZ 0800 339 258 www.dewalt.co.nz support@dewalt.au support@dewalt.co.nz Belgique et Luxembourg Tel: NL 32 15 47 37 63 www.dewalt.be België en Luxemburg Tel: FR 32 15 47 37 64 support@dewalt.be support@dewalt.be.fr Danmark Tel: 70 20 15 10 www.dewalt.dk support@dewalt.dk Deutschland Tel: 06126-21-0 www.dewalt.de support@dewalt.de Ελλάς...
