Summary of Contents for netta MPPHA-08CRN7-QB6
- Page 1 8000BTU AIR CONDITIONER 8000 WEIGHT 22KG TIMER 24 HOURS WARRANTY 365 DAYS ------------------------------------------------------------------------------------------------- EN USER INSTRUCTION & OPERATION MANUAL...
- Page 2 Thank you for purchasing this NETTA product. Please read the user manual carefully before operating this appliance. We will update our instruction manuals if necessary. For the most up-to-date user manual, please visit our official website: www.nettadirect.com. You can download a copy of up-to-date user manuals at any time in electronic format.
-
Page 3: Safety And Warnings
Safety and Warnings Regular Check-Ups Intended Use Ensure the power cable and NETTA Design is for domestic and plug are not damaged before indoor use only. This product is not plugging into a socket. intended for use by people who have... - Page 4 General Warnings • This unit has wheels to facilitate moving. Make sure not to use the wheels on thick carpet or to roll over objects, as these could cause tipping. • Do not operate the unit if it has been dropped or damaged. •...
- Page 5 General Warnings • Contact an authorised service technician or our customer service team for repair or maintenance of this unit. • Do not cover or obstruct the inlet or outlet grilles. • Do not use this product for functions other that those described in this instruction manual.
- Page 6 General Warnings • Please follow the instruction carefully to handle, install, clean and service the air conditioner to avoid damage or hazards. Flammable refrigerant is used within this air conditioner. When maintaining or disposing of the air conditioner, the refrigerant shall be recovered properly and not discharged into the air directly.
-
Page 8: Assembling The Product
Assembling the Product Note: All illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The unit can be controlled by the unit control panel or with the remote controller. This manual does not include remote controller operations. Please see the remote controller instruction manual packed with the unit for these details. - Page 9 Choosing The Right Location Make sure you install your unit on an even surface to minimise noise and vibration. The unit must be installed near a grounded plug and the collection tray drain (found on the back of the unit) must be accessible. The unit should be located at least 30cm (12 inch) from the nearest wall to ensure proper air...
- Page 10 Tools Needed Medium Philips Screwdriver, Tape Measure/Ruler, Knife/Scissors, Saw (optional, to shorten window adaptor). Accessories Note: Items with (*) are only on some models. Window Installation Kit Step One: Preparing the Exhaust Hose Assembly. Press the exhaust hose (or extended exhaust hose) into the window slider adaptor (or wall exhaust adaptor) and unit adaptor.
- Page 12 Step Two: Install the Exhaust Hose Assembly to the Unit. Push the Exhaust Hose into the air outlet opening of the unit along the arrow direction. Step Three: Preparing the Adjustable Window Slider 1. Choose the window sliders according to the size of your window. Sometimes, it needs to be cut short to meet the window size.
- Page 13 Installation Once the Exhaust Hose assembly and Adjustable Window Slider are prepared, choose from one of the following two installation methods. Type 1: Hung Window or Sliding Window Installation...
- Page 14 Type 2: Wall Installations (for some models). 1. Cut as 125mm (4.9 inch) hole into the wall for the Wall Exhaust Adaptor B. 2. Secure the Wall Exhaust Adaptor B to the wall using the four anchors and screws provided in the kit. 3.
-
Page 15: Operating The Product
Operating the Product Control Panel Features Note: The following control panels are for explanation purposes only. The control panel of the unit you purchased may be slightly different according to the models. Your machine may not contain some indicators or buttons. Mode Button Selects the appropriate mode. - Page 16 LED Display Shows the set temperature while on cool or auto mode. While on DRY or FAN modes, it shows the room temperature. Error Codes: E0 – EEPROM Error E1 – Room Temperature Sensor Error E2 – Evaporator Temperature Sensor Error E3 –...
- Page 17 Fan Operation – Press the ‘MODE’ button until the ‘FAN’ indicator light comes on. Press the ‘FAN SPEED’ button on the remote controller to choose the fan speed. The temperature cannot be adjusted. Auto Operation (On Some Models) – When you set the air conditioner in ‘AUTO’...
- Page 18 Wireless Operation (On Some Models) – Used to initiate wireless (Wi- Fi) connection mode. If using the wireless function for the first time, press the ‘POWER’ button for 3 seconds to initiate the wireless connection mode. The LED DISPLAY shows ‘AP’ to indicate you can set the wireless connection.
- Page 19 Preparation Please ensure your mobile device is connected to Wi-Fi/Wireless router. Also ensure that the Wi-Fi/Wireless router is connected to the internet before doing user registration and network configuration. Ensure your mobile device is connected to the Wi-Fi/Wireless network which you want to use. You should also forget other irrelevant Wi- Fi/Wireless networks in case it influences your configuration process.
- Page 20 2. Enter your email address and password, and then click ‘register’. Network Configuration It is necessary to forget any other networks and make sure the Android or iOS device is only connected to the Wi-Fi/Wireless network you want to add. Make sure the Android and iOS device Wi- Fi/Wireless function works well and can be connected back to your original Wi-...
- Page 21 Network Configuration by Bluetooth Scan Note: Make sure the Bluetooth of your mobile device is on and working.
- Page 22 Network Configuration by Select Appliance Type If the Bluetooth network configuration fails, please select the appliance type (Portable AC). Follow the above steps under ‘wireless operation’. When the display shows ‘AP’, press ‘next’ on the app. Note: Steps 3 and 4 are only applicable to Android systems. iOS does not need these two steps.
- Page 23 Note: When finishing network configuration, the app will display success cue words on screen. Due to different internet environments, it is possible that the device status will still display ‘offline’. If this occurs, please pull down on the screen to refresh the device list on the app. Alternatively, you can turn off the power of the unit and turn it back on.
- Page 24 How To Use The App Note: Not all of the app functions are available on the air conditioner. Schedule The user can set a weekly timer to turn the AC on/off.
- Page 25 Sleep The user can customise their own comfortable sleep by setting a target temperature. Share Device The air conditioner can be controlled by multiple users at the same time.
- Page 26 App Declaration The app may not support the latest software versions of Android and iOS systems. Not all Android and iOS systems are compatible with the app. We will not be responsible for any issue as a result of incompatibility. The camera on the mobile device needs to be 5 million pixels or above to ensure the QR code can be scanned properly.
- Page 27 Water Drainage – During dehumidifying modes, remove the drain plug from the back of the unit, install the drain connector. For models without a drain connector, just attach the drain hose to the hole. Place the open end of the hose directly over the drain area. Note: Make sure the hose is secure so there are no leaks.
-
Page 28: Cleaning, Maintenance And Storage
Cleaning, Maintenance and Storage • Always unplug the unit before cleaning or servicing. • DO NOT use flammable liquids or chemicals to clean the unit. • DO NOT wash the unit under running water. • DO NOT operate the machine if the power supply was damaged during cleaning. -
Page 29: Troubleshooting
Troubleshooting Problem Possible Causes Solution The Water Collection P1 Protection Code Tray is full. Turn off the unit, drain the water and Unit does not turn restart the unit In ‘COOL’ mode: room on when pressing ON/OFF button temperature is lower than Reset the temperature the set temperature. -
Page 30: Spare Parts And Repairs
You can also find this code on the back of this User Manual. For our Repair Service, please contact our customer support with email on support@nettadirect.com they will provide with more details of repair service with NETTA. Disposal of Product IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC. - Page 31 Copyrights NETTA and its logo including images and contents in this manual and website is copyrighted. All intellectual property rights belong to NETTA owner CONSUMABLE DIRECT LIMITED. ANY UNAUTHORISED USE, MODIFICATION or DISTRIBUTION of the NETTA logo, website image, and its contents (from website, manuals) will violate worldwide copyright, trademark and associated laws.
