netta OL-BKY29-A011F User Instruction

Local air conditioner
Hide thumbs
Table of Contents

Advertisement

Quick Links

LOCAL AIR
CONDITIONER
POWER
1114W
TIMER
24-HOUR
BTU
10,000
WEIGHT
24.5KG
---------------------------------------------------------------------------------------------------
EN
EN USER INSTRUCTION & OPERATION MANUAL
ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL
USUARIO
DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG
FR MANUEL D'UTILISATION ET D'UTILISATION
IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OL-BKY29-A011F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for netta OL-BKY29-A011F

Summary of Contents for netta OL-BKY29-A011F

  • Page 1 LOCAL AIR CONDITIONER POWER 1114W TIMER 24-HOUR 10,000 WEIGHT 24.5KG --------------------------------------------------------------------------------------------------- EN USER INSTRUCTION & OPERATION MANUAL ES MANUAL DE INSTRUCCIONES Y OPERACIONES PARA EL USUARIO DE BENUTZERANLEITUNG & BETRIEBSANLEITUNG FR MANUEL D'UTILISATION ET D'UTILISATION IT ISTRUZIONI PER L'USO E MANUALE OPERATIVO...
  • Page 2 Thank you for purchasing this NETTA product. Please read the user manual carefully before operating this appliance. We will update our instruction manuals if necessary. For the most up-to-date user manual, please visit our official website: www.nettadirect.com. You can download a copy of up to date user manuals at any time in electronic format.

  • Page 3: Before You Begin

    Before You Begin Regular Check-Ups Intended Use Ensure the power cable and This appliance is intended to be used plug are not damaged before by expert or trained users in shops, in plugging into a socket. light industry and on farms, or for commercial use by lay persons.

  • Page 4: For Your Safety

    For Your Safety • If the supply cord is damaged, it must be replaced by the manufacturer. • Always operate the unit from a power source of equal voltage, frequency and rating as indicated on the product identification plate. • Always use a power outlet that is grounded.
  • Page 5 • Do not clean the appliance with any chemicals. • Ensure the unit is far away from fire, inflammable, or explosive objects. • The unit shall be installed in accordance with national wiring regulations. • Do not piece or burn, even after use. •...
  • Page 6 Work Procedure Work shall be undertaken under a controlled procedure so as to minimize the risk of a flammable gas or vapor being present while the work is being performed. General Work Area All maintenance staff and others working in the local area shall be instructed on the nature of work being carried out.
  • Page 7 during which flammable refrigerant can possibly be released to the surrounding space. Prior to work taking place, the area around the equipment is to be surveyed to make sure that there are no flammable hazards or ignition risks. “No Smoking” signs shall be displayed. Ventilated Area Ensure that the area is in the open or that it is adequately ventilated before breaking into the system or conducting any hot work.
  • Page 8 Checks to Electrical Devices Repair and maintenance to electrical components shall include initial safety checks and component inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be connected to the circuit until it is satisfactorily dealt with. If the fault cannot be corrected immediately but it is necessary to continue operation, an adequate temporary solution shall be used.

  • Page 9: Assembling The Product

    Assembling the Product 1. Control Panel 2. Air Vent with Adjustable Louver 3. Handle Air Inlet with Air Filter 5. Caster 6. Drainage Hole 7. Air Exhaust. Note: The appearance is only for reference. Please see the real product for detailed information. Unpacking Unpack the carton and take the appliance and accessories out.
  • Page 10 Choose Your Location • If tipped more than 45 degrees, allow the unit to sit upright for at least 24 hours before starting up. • Place the unit on a firm, level surface in an area with at least 50cm of free space around it to allow proper air circulation.
  • Page 11 4. Close your window to secure the kit in place. It needs to hold the window kit firmly in place – secure the window kit with duct tape if required. It is recommended that the gap between the adapter and the sides of the window should be sealed off for maximum efficiency.

  • Page 12: Operating The Product

    Operating the Product Control Panel and Display POWER Press to switch the machine on or off. Press to switch the operation mode MODE between fan, cooling, and dehumidifier. Press to switch the fan speed between SPEED HIGH and LOW. Decreasing the desired temperature or DOWN timer setting.

  • Page 13: Control Panel

    Control Panel 1. High Fan Speed 2. Low Fan Speed 3. Timer 4. Dehumidifier Mode 5. Cooling Mode 6. Fan Mode 7. Sleep Mode 8. Lock 9. Display Window 10. Wi-Fi Function...

  • Page 14: Remote Control

    Remote Control...
  • Page 15 Settings Start Up and Shutdown • Press ‘POWER’ to turn the unit on. • The unit runs on ‘FAN’ as the default setting. • Press the ‘MODE’ button to select the desired operation mode. • Press ‘POWER’ again to turn off the power. Operation Mode •...
  • Page 16 Drying Your Room • Press the ‘MODE’ button on the control panel until the LED of ‘DRY’ lights up or press ‘Dry’ on the remote control. The user should connect the hose to the drain outlet at the bottom of the unit.

  • Page 17: Automatic Defrost

    Automatic Defrost • At low room temperatures, frost may build-up in the evaporator during operation. The unit will automatically start defrosting and the ‘POWER’ LED will start blinking. The defrost control sequence is as follows: • A. When the unit operates in ‘COOL’ mode, the ambient temperature sensor will sense when the evaporator coil temperature is below -1°C.
  • Page 18 Switch off the unit before ⚫ operating. Remove the plug of the water ⚫ outlet opening and keep it in safe area. Remove the rubber sealing plug. Securely and properly connect ⚫ the drain hose and make sure it is not kinked and is clear of obstruction.

  • Page 19: Cleaning, Maintenance And Storage

    Cleaning, Maintenance and Storage Cleaning The Air Filter • The air filter should be cleaned every 2 weeks. • Dust collects on the filter and restricts the airflow. The restricted airflow reduces the efficiency of the system and, if it becomes blocked, can damage the unit.

  • Page 20: Troubleshooting

    Cleaning Up Refrigerant 1. Gas/Vapour is heavier than air. It may accumulate in confined spaces, particularly at or below ground level. 2. Eliminate every possible source of ignition. 3. Use appropriate personal protection equipment (PPE). 4. Evacuate unnecessary personnel and ventilate the area. 5.
  • Page 21 ✓ Check the air filter for ➢ Clean the air filter as dirt. necessary. ✓ Check if the air duct is ➢ To clear the obstacle. blocked. ✓ Check if the room door ➢ Keep the door and The unit or window is open.

  • Page 22: Long Term Storage

    Long-Term Storage If you will not be using the unit for an extended period of time (more than a few weeks), it is best to clean the unit and dry it completely. Please store the unit as follows: 1. Unplug the unit and remove the exhaust hose and window kit. Store these with the unit.

  • Page 23: Spare Parts And Repairs

    You can also find this code on the back of this User Manual. For our Repair Service, please contact our customer support with email on support@nettadirect.com they will provide with more details of repair service with NETTA. Disposal of Product IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
  • Page 24 Copyrights NETTA and its logo including images and contents in this manual and website is copyrighted. All intellectual property rights belong to NETTA owner CONSUMABLE DIRECT LIMITED. ANY UNAUTHORISED USE, MODIFICATION or DISTRIBUTION of the NETTA logo, website image, and its contents (from website, manuals) will violate worldwide copyright, trademark, and associated laws.
