Living Spaces DTRANCRTTE Assembly Instruction

CAUTION: PLEASE READ ALL INSTRUCTION BEFORE STARTING THE ASSEMBLY OF THIS PRODUCT. THESE ARE HEAVY.
IN ORDER TO PREVENT PERSONAL INJURY AND ENSURE THAT THIS PRODUCT IS NOT DAMAGED DURING THE
ASSEMBLY PROCESS. IT IS STRONGLY RECOMMENDED THAT YOU ENLIST THE ASSISTANCE OF ONE OR MORE
PEOPLE.
CUIDADO: FAVOR DE LEER TODAS LAS INSTRUCCIONES MANTES DE ENSAMBLAR SU PRODUCTTO. ESTAS PIEZAS SON PESADAS.
PARA PREVENIR HERIDAS PERSONALES Y ASEGURAR QUE SU PRODUCTOI NO SEA DAN ADO MIENTRAS ES
ANSAMBLADO, SE RECOMIENDA LA ASISTENCIA DE UNA O MAUS PERSONAS.
WARNING.....PROTECTIVE GLIDE IS PLACED UNDER LEGS OF FURNITURE TO RESIST SCRATCHES TO FLOOR
SURFACE. SOME FLOOR SURFACES CAN BE EXTRA SENSITIVE TO MARKING. IF YOU ARE NOT SURE CONSULT WITH
YOUR DEALER.
AVERTISSEMENT...LES PIEDS DES MEUBLES SONT MUNIS DE PAINTS DESTINÉS À PROTÉGER LE PLANCHER.
CENTAINS REVÊTEMENTS DE SOL PEUVENT ÊTRE TRÈS FRAGILES. EN CAS DE DOUTE, CONSULTER LA MARCHAND.
NO. Parts list
A
B
C
D
Please note:
Do not fully tighten the bolts before make
sure that all bolts get in postion.
STEP 1
Assembly Instruction
RANCHO ROUND TABLE
DTRANCRTTE SKU#249695
DTRANCRTBE SKU#249693
TABLE TOP
RANCHO-695-693-A
MOUNTING BAR
RANCHO-695-693-B
TABLE LEG
RANCHO-695-693-C
FOOT BASE
RANCHO-695-693-D
Q'TY NO.
1
1
1
2
1
1
3
B
Hardware List
Ø 5/16" x 63mm Bolt (RANCHO-695-693-1a)
Ø 5/16" Spring washer (RANCHO-695-693-1b)
Ø 5/16" Flat washer (RANCHO-695-693-1c)
Ø 5/16" x 38mm Bolt (RANCHO-695-693-2a)
Ø 5/16" Spring washer (RANCHO-695-693-2b)
Ø 5/16" Flat washer (RANCHO-695-693-2c)
Allen wrench (4mm) (RANCHO-695-693-3)
3
2
C
Assembly Completed
MADE IN VIETNAM
Q'TY
4
8
1
