- Page 1 CAMERA BRACKET SBP-300NM...
-
Page 2: Product Overview
Product Overview This product is a bracket for installing TNB-6030 on monitor. Hanwha Techwin cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. The Eco mark represents Hanwha Techwin’s devotion to creating environmentally friendly products, and indicates that the product satisfies the EU RoHS Directive. -
Page 3: Installation Precautions
Installation Precautions Follow all cautions in the TNB-6030. Follow all cautions in the 3M™ Dual Lock™ SJ3551CF. When using 3M™ Primer 94, be sure to follow all cautions for the product. Refer to the following URL for precautions. 3M™ Dual Lock™ SJ3551CF : https://www.3m.com/3M/en_US/company-us/SDS-search/results/?gsaAction=msdsSRA&ms dsLocale=en_US&co=ptn&q=SJ3551CF, 3M™... - Page 4 Table Of Contents Product Overview ..................Installation ....................
- Page 5 Package Appearance Item Name Quantity BRACKET COVER SAFETY WIRE English_5...
- Page 6 Appearance Item Name Quantity 3M™ Dual Lock™ SJ3551CF SCREW 3M™ Tape Primer 94 INSTALL BRACKET Quick Guide SBP-300NM...
-
Page 7: Installation
Installation 1. Assemble the lens part to the center hook part of the bracket. BRACKET Lens part English_7... - Page 8 Installation 2. After assembling the lens part to the bracket, assemble connect the cover. COVER BRACKET...
- Page 9 3. Loosen the screws by just 1mm so that the screws are not removed from the Vesa Mount, connect the safety wires, and tighten the screws again. English_9...
- Page 10 Installation 4. Apply Tape Primer 94 to the location where you want to install the camera and attach the Dual Lock™. To use Primer 94, crush at center of ampule. Wear protective gloves to use the Primer 94. Take the contents out of the package and apply the Primer 94 to the desired area. Follow the instructions and precautions on the package.
- Page 11 5. After attaching the Dual Lock™ to the monitor, leave it for a certain period of time (more than 24 hours) so that the adhesive is fully bonded to the surface, and then tightly connect it with the Dual Lock™ of the camera part. English_11...
- Page 12 Installation 6. If there are screw holes in the object to be installed, you can install it using screws.
- Page 13 7. When installing on the TNB-6030 body using the Dual Lock™, attach two Dual Lock™ to the center of the body and to the location of the monitor where you want to install, in the same manner as when you attach the Dual Lock™ to the monitor. Leave it for a certain period of time (more than 24 hours) after attaching the Dual Lock™.
- Page 14 Ú Example installation...
- Page 15 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwha-security.com Hanwha Techwin America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free : +1.877.213.1222 Direct : +1.201.325.6920 Fax : +1.201.373.0124 www.hanwhasecurity.com Hanwha Techwin Europe...
