- Page 1 Instructions for Repainting X-Plus Flush mount Applicable models: XND-6081FZ, XND-8081FZ, XND-8081RF, XND-6081RF, XND-6081F...
-
Page 2: Table Of Contents
Contents Precautions ................Tools Needed ................. Names of Camera Parts ............Preparing to paint ..............How to paint ................Assembly................Completion ................English... -
Page 3: Precautions
Precautions This document provides general instructions on repainting Hanwha Vision's X-Plus Flush Mount Cameras. If you want to change their appearance, you should first understand the content of this document. Please note that Hanwha Vision is not responsible for any problems caused by repainting. -
Page 4: Tools Needed
Tools Needed Prepare the tools needed for your work, referring to the table and images below. Table of tools needed Tool name Image Tool name Image Phillips Paper screwdriver Protective Pen or pencil goggles Masking tape Cleaning cloth Protective Scissors gloves Star wrench Dust mask... -
Page 5: Names Of Camera Parts
Names of Camera Parts The names of each part of the camera are as shown below. Camera housing Camera top cover Transparent dome cover <Fig. 2. Names of Camera Parts> English... -
Page 6: Preparing To Paint
Preparing to paint Disassembly Disassembling the camera top cover With your 4mm star wrench (TORX), unscrew the four screws in the top cover by turning them counterclockwise so that you can remove the cover. <Fig. 3. Top cover disassembled> Disassembling the transparent dome cover With your Phillips (+) screwdriver, unscrew the three screws inside the cover by turning them counterclockwise so that you can remove the transparent dome cover. - Page 7 Preparing to paint Cautions Caution after disassembly Be careful not to let moisture or water come into contact with the PCB part after disassem- bly. Touching or shocking the lens module part may adversely affect the performance. Handle with care <Fig.
- Page 8 Preparing to paint Masking Mask the inner side of the dome cover using a masking tape so that paint does not intrude the inner surface. <Fig. 7. Top cover masked> If paint gets to the inner ceiling of the front cover, it may adversely affect the waterproof ca- pability of the cover.
-
Page 9: How To Paint
How to paint It is recommended to use a professional painting company with all the necessary equipment and tools. Paints most appropriate for the materials should be used for all painting applications. Paint can cause irritation to the skin or respiratory system because it contains harmful substances. - Page 10 How to paint Paint it once and wait until it is completely dried. Then, paint it once more (Two times recommended). <Fig. 10. First painting> After the surface is painted for the first time and dried, paint it again. <Fig. 11. Second painting> English...
- Page 11 Drying After finishing the painting, completely dry the surface for better paint adhesion. Use a drying chamber to dry it, or let it dry naturally. <Fig. 12. Drying chamber> When paint is completely dry, remove the masking tape attached to the skin cover. <Fig.
-
Page 12: Assembly
Assembly Assemble the transparent dome cover and then wipe off any fingerprints and dust inside the dome with a cleaning cloth. Any foreign substances remaining in there may affect the video quality. <Fig. 14. Dome cover cleaned> Use a star wrench (TORX) to join the top cover to the bottom. <Fig. -
Page 13: Completion
Completion The image of repainting complete. <Fig. 16. Repainting complete> English... - Page 14 Head Office 6, Pangyo-ro 319 beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 463-400 Rep. of KOREA Tel : +82.70.7147.8753 Fax : +82.31.8018.3740 www.hanwhavision.com Hanwha Vision America 500 Frank W. Burr Blvd. Suite 43 Teaneck, NJ 07666 Toll Free +1.877.213.1222 Direct +1.201.325.6920 Fax +1.201.373.0124 www.hanwhavisionamerica.com Hanwha Vision Europe Heriot House, Heriot Road, Chertsey, Surrey, KT16 9DT, United Kingdom...
