Wisenet SBV-158G Quick Start Manual

Mount-bracket

MOUNT-BRACKET

Package

MOUNT-BRACKET

SCREW-SPECIAL

Product Overview

This product is an adaptor used to install Vandal Dome camera which is one of our WN3

series (the same model as SNV-5084 / 6084 / 7084 / 6084R / 7084R) in the electric gang

box or on the wall.

SBV-158G

Please make sure to install on an area which is strong enough to support more than 4 times of

the total weight of this product and the camera. Depending on some installation conditions,

this product can be connected to 0.75" NPT which is a screw peak processed pipe.

Install the mount bracket on a desired position.

ANCHOR

PT01-002071A
