At a Glance
Exterior Assembly
②
Interior Assembly
①
④
INSTALLATION
Installation generally takes less than 20 minutes. If you have any questions or concerns, visit support.eufy.com for assistance.
Keep the door open during installation. Do not close the door until the batteries are inserted.
What You Need
Prepare a standard Phillips screwdriver and 4 AA batteries before installation. The included screws are Phillips screws.
Keypad
Keyway
①
Serial Number & QR Code
• Use to add the Smart Lock C30 in the app.
Battery Compartment
SYNC Button:
• Press and hold for 2 seconds to pair the lock.
• Press and hold for 10 seconds to reset the lock.
②
Thumbturn
Screw Hole
③
⑤
Advertisement
Related Manuals for EUFY C30
Summary of Contents for EUFY C30
- Page 1 ④ ⑤ INSTALLATION Installation generally takes less than 20 minutes. If you have any questions or concerns, visit support.eufy.com for assistance. Keep the door open during installation. Do not close the door until the batteries are inserted. What You Need...
-
Page 2: What's In The Box
What's in the Box Step 2. Deadbolt Installation Set Latch Latch Screws Step 3. Exterior Assembly Exterior Assembly Step 4. Interior Assembly Installation Set Interior Assembly Interior Assembly Screws Mounting Plate Screws... -
Page 3: Step 1. Prepare The Door
Silicone Plug Screw Step 5. Strike Plate Installation Set Strike Plate Strike Plate Screws Step 1. Prepare the Door 1. Remove the existing lock and check your door. 2. Check if your door has holes like the one below. Standard US doors are already compatible. Backset 2⅜... - Page 4 Step 2. Install Deadbolt 1. Check your door to see if the deadbolt requires adjustment. 2-3/8 Backset 2⅜" / 60 mm If the backset is 70 mm, turn the faceplate 180° to extend the length. Latch Hole 2-3/4 2¾" / 70 mm 2.
- Page 5 Step 4. Install Interior Assembly 1. Detach the mounting plate from the interior assembly. 2. Run the wires through the mounting plate. 3. Secure the mounting plate with screws. Set the screws with your hands, then use a screwdriver to secure them.
- Page 6 4. Wire to the interior assembly. 5. Mount the interior assembly. Make sure both wires are tucked into the cabin on the back of the interior assembly. Make sure the deadbolt is retracted and the thumb turn knob is on the 'unlock' position, check if the deadbolt moves properly by turning the...
- Page 7 Insert and tighten the screw below the deadbolt first, and then tighten the two screws above. 6. Install 4 AA batteries with the correct polarity. Don't put on the cover until the system setup is done in the app. Step 5. (Optional) Install Strike Plate Make sure the depth of the latch hole on the door frame is deep enough (1 in / 25.4 mm), otherwise the calibration might fail during the setup.
-
Page 8: Setting Up The System
1. Download and install the eufy Security app, then sign up for an account. 2. Follow the in-app instructions to add the Smart Lock C30 to your device list. Please visit https://support.eufylife.com/s/ or scan the QR code for more information.
