eufy Security Video Smart Lock E330 (T8531) USER GUIDE
eufy Security Video Smart Lock E330 with Chime (E8531) USER
GUIDE
ABOUT THE PRODUCT
AT A GLANCE
WHAT'S IN THE BOX
CHARGING THE BATTERY
INSTALLING VIDEO SMART LOCK
OPENING AND CLOSING THE LOCK CYLINDER COVER
USING DOORBELL CHIME (OPTIONAL)
SETTING UP THE SYSTEM
ABOUT THE PRODUCT
This guide applies to both T8531 (eufy Security Video Smart Lock E330) and E8531 (eufy Security Video Smart Lock E330 with
Chime).
Video Smart Lock E330 comes with 8 GB of built-in local storage. The chime can extend the storage by recording video clips
on a microSD card (not included) while acting as a digital indoor chime. To buy a chime, visit eufy.com.
AT A GLANCE
Video Smart Lock
Model: T8531
①
②
③
④
⑤
⑥
⑦
⑧
⑨
Ensure Tight Seal
Fingerprint Scanner
• Use to lock and unlock the door.
Battery Indicator
• Turns red when the battery is low.
Camera Lens
Ambient Light Sensor
• Detects the amount of light in the area.
Keypad
Status Light and Lock / Unlock Button
• Blue: Door Unlocked
• Orange: Door Locked
• Red: Abnormal State
Lock Cylinder
Doorbell Button
• The light automatically turns on when someone
approaches the door.
USB-C Port
• Charges the lock in emergency situations. To stop lock
⑩
tampering, this port is solely for charging purposes and
can not transfer any data.
Speaker
10
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EUFY E330
Summary of Contents for EUFY E330
- Page 1 Chime). Video Smart Lock E330 comes with 8 GB of built-in local storage. The chime can extend the storage by recording video clips on a microSD card (not included) while acting as a digital indoor chime. To buy a chime, visit eufy.com.
-
Page 2: What's In The Box
① ② QR Code • Scan to add Video Smart Lock in the app. Battery Compartment Setup Button ③ • Press for 2 seconds to put Video Smart Lock in paring mode. • Press for 10 seconds to reset Video Smart Lock. ④... - Page 3 Step 4 Interior Assembly Screws Silicone Plug Interior Assembly Screws Rechargeable Battery Step 5 Strike Plate Strike Screws...
-
Page 4: Charging The Battery
6-8 Hours INSTALLING VIDEO SMART LOCK Installation generally takes less than 30 minutes. If you have any questions or concerns, visit support.eufy.com for assistance. What You Need (Not Provided) Prepare a standard Phillips screwdriver before installation. The included screws are Phillips screws. -
Page 5: Step 1. Prepare The Door
1⅜ in - 2¹¹/₆₄ in 35 mm - 55 mm Be advised that Video Smart Lock E330 is not compatible with storm doors and may not be suitable for the standard entry doors behind them, as the storm door may block the camera. - Page 6 ❶ ❷ Diagram A ❸ ❹ If the latch hole is round, contact eufy Support to receive a round drive-in faceplate, then replace the existing one. Diagram B If the latch hole is rectangular, install the deadbolt with the...
- Page 7 Step 3. Install Exterior Keypad 1. Measure the diameter of the cross bore. • If 54 mm, install the keypad. • If 38 mm, remove the spacer then install the keypad. Cross Bore Diameter 1 ½ in / 38 mm 2.
-
Page 8: Step 4. Install Interior Assembly
Step 4. Install Interior Assembly 1. Detach the mounting plate and battery cover from the interior assembly. 2. Run the cables through the slot on the mounting plate. Make sure the silicone pad is against the door. - Page 9 3. Align the mounting plate with the threaded screw receptacles of the exterior keypad. Tightly fasten the screws in place. Set the screws with your hands, then use a screwdriver to secure them. 4. Plug the power cable (large connector) and then the radar cable (small connector) into the sockets on the back of the interior assembly.
- Page 10 5. Insert the T-shaped tailpiece of the exterior keypad into the T-shaped tailpiece receiver of the interior assembly. Make sure both wires are tucked into the cavity on the back of the interior assembly. Make sure the deadbolt is Use a long screwdriver to fasten retracted and the thumbturn the interior assembly screws.
- Page 11 6. Insert the rechargeable battery into the battery compartment.zz ❷ ❶ Step 5. Install Strike Plate Latch Hole Depth 25.4mm/1 in Ensure the depth of the strike hole in the door frame is at least 1 in (25.4 mm), otherwise calibration may fail during setup, and the lock may not function as expected.
- Page 12 To open the cover, gently pull on the bottom of the cover and rotate it counterclockwise. To close the cover, turn it clockwise and slide it back into place. USING DOORBELL CHIME (OPTIONAL) The doorbell chime is exclusively available with the purchase of the E8531 model (eufy Security Video Smart Lock E330 with Chime).
-
Page 13: How The System Works
At a Glance Model: T8023 ① ② SYNC Button Speaker ③ microSD Card Slot • Insert a microSD card to store recordings. Use at ⑤ ④ least a Class 10 microSD card with a maximum of 128 GB. Status LED ⑥... -
Page 14: Setting Up The System
2. Plug the doorbell chime into a wall outlet at your desired location. LED Indicator Status Flashing Green Connecting to Wi-Fi Solid Blue Connected to Wi-Fi Solid Green Connection Failed SETTING UP THE SYSTEM 1. Download and install the eufy Security app, then sign up for an account. - Page 15 Lock to your device list. • One doorbell chime can link up to four devices. • Make sure your Video Smart Lock battery is charged, or it may fail to be added to the eufy Security app. Doorbell Chime (if available) Video Smart Lock 3.
