Playab le d is c s
This unit is compatible to play the following discs.
Disc
Logo
DVD-VIDEO
DVD+RW
DVD+R
DVD+R Double Layer
DVD-RW
(VIDEO mode, Finalized)
is a trademark of DVD Format/Logo Licensing Corporation.
Reg ion c od e s
The number inside the globe refers to region of the world.
This unit can play DVDs that are labeled for ALL regions or for Region 1.
Re c ordab le di s c s
This unit can record to the following disc types.
IThis unit formats discs with DVD+VR mode.
IDVD-R/DVD+R discs can only be recorded to once. DVD+RW/DVD-RW discs can be recorded to and erased
many times.
IDiscs that have been tested and are proven to be compatible with this recorder:
VERBATIM DVD+R 8x, VERBATIM DVD+RW 4x
VERBATIM DVD-R 8x, VERBATIM DVD-RW 2x, MAXELL DVD-R 16x, JVC DVD-RW 4x
IWe strongly recommend for good recording quality:
TDK DVD+R 4x/8x/16x, SONY DVD+R 4x/8x/16x, MAXELL DVD+R 4x/8x/16x, SONY DVD+RW 4x,
MAXELL DVD-R 8x/16x, MAXELL DVD-RW 4x
Logo
Attributes
8cm/12cm, single-sided, single layer disc
Approx. max. recording time (SLP mode):
DVD+RW
360 minutes (4.7GB) (for 12cm)
108 minutes (1.4GB) (for 8cm)
DVD+R
DVD Recorder
MSR90D6
Disc
Logo
DVD-R
(VIDEO mode, Finalized)
CD-DA (AUDIO CD)
CD-RW
(CD-DA FORMAT, MP3 files)
CD-R
(CD-DA FORMAT, MP3 files)
Video CD
Logo
Attributes
8cm/12cm, single-sided, single layer disc
DVD-RW
Approx. max. recording time (SLP mode):
360 minutes (4.7GB) (for 12cm)
108 minutes (1.4GB) (for 8cm)
DVD-R
1
Antenna
Antenna
Cable
Cable
(Back of TV)
(Back of TV)
TV signal
TV signal
(Cable box or
(Cable box or
Satellite box)
Satellite box)
or
or
2
2
Connect
Connect
RF cable (not supplied)
RF cable (not supplied)
IN
IN
1
1
RF cable (supplied)
RF cable (supplied)
OUT
OUT
Connect
Connect
ANTENNA
ANTENNA
I Both A/V and RF cables must be connected to the TV for operation.
I See front page of the Owner's Manual for the connection with the RF modulator.
2
Watching on TV
2
– 1
Press [STANDBY-ON
]
to turn the unit on.
1. Switch the input selector on your TV to an
appropriate external input channel
(usually near channel 0).
2. Press a button on the TV's original remote control
(see the table below) to select an external input
channel until the DVD recorder's picture appears.
Initial Setup
2
– 2
Set up the following items when turning on the unit for the first time.
Initial Setup
Initial Setup
English
Channel Preset
Français
Español
Press [OK] to Channel Preset.
Using [K/ L], select your desired
language and press [OK].
Then the unit will start getting available channels in your area.
Initial Setup
Initial Setup
Clock Setting
Press [OK] to Clock Setting.
Press [OK] again.
Connections
Remote Control
VIDEO
VIDEO
AUDIO IN
AUDIO IN
4
4
3
3
Connect
Connect
Connect
Connect
Video
Video
Audio
Audio
cable
cable
cable
cable
(supplied)
(supplied)
(supplied)
(supplied)
COMPONENT
COMPONENT
VIDEO IN
VIDEO IN
VIDEO OUTPUT
VIDEO OUTPUT
VIDEO OUT
VIDEO OUT
S-VIDEO
S-VIDEO
Y
Y
IN
IN
OUT
OUT
DIGITAL AUDIO OUTPUT
DIGITAL AUDIO OUTPUT
PCM / BITSTREAM
PCM / BITSTREAM
L
L
L
L
P
P
B
B
/C
/C
B
B
R
R
R
R
P
P
/C
/C
COAXIAL
COAXIAL
AUDIO IN
AUDIO IN
R
R
R
R
AUDIO OUT
AUDIO OUT
(E1)
(E1)
(Back of this unit)
(Back of this unit)
Input Mode Names for Common TV Brands
Admiral
AUX
Panasonic
Curtis Mathis
LINE1, LINE2, 00, 90,
RCA
91, 92, 93
GE
INPUT, TV/VCR, 00, 90,
Samsung
91, 92, 93
Hitachi
Sanyo
INPUT, AUX
JVC
Sharp
VIDEO, VIDEO1, VIDEO2,
VIDEO3
Kenwood
Sony
AUX
LXI-Series
Toshiba
00
Magnavox
Zenith
AUX CHANNEL
Auto Presetting Now
Initial Setup
---- / -- / ---- ( ---- )
JAN / 01 / 2006 ( SUN )
-- : ----
12: 00 AM
Using [K/ L], enter the date
(month / day / year).
Press
to move the cursor.
[{ / B]
Press [OK]. TV Program will automatically
appear. (usually near channel 0)
Follow to the back side of this sheet.
Setup
TV/VIDEO
INPUT, TV/VCR, 00, 90,
91, 92, 93
TV/VIDEO
VIDEO
00
VIDEO1, VIDEO2, VIDEO3
TV/GAME
00
CH 1
