1
注：此页为技术说明，非印刷内容
刀模线：
A
内折线：
展开尺寸图：
B
C
装订效果图：
D
技术要求：
1、材质：105g 铜板纸
未经倍思奇
书面许可，
2、展开尺寸：A4，如图所示折叠成型为A5，16P
不得复制部
3、颜色：单色
分或全部内
4、印刷：印刷图档见后续页，双面印刷
容。违者本
5、装订方式:：骑马钉
公司保留追
究法律责任
的权利。
符号标识
版本变更
标记 处数
##
设 计
关键尺寸
.XXX
绘 图
编号
##
审 批
参考尺寸
(X.XX)
除去所有利边, 尖点，毛刺
1
ECO#
发行时间
P M
Zoey
2024/04/11
日期
Lily
2024/04/11
日期
2
297mm
封
封
底
面
ERMTL4-
名
Manual(单英)-JY
称
图
号
材
料
规
格
2
3
210mm
860-02781-00
PLM号
投影法
第 一 角 投 影 法
版 本
重量G
00
共17页
倍思奇创新科技
（深圳）股份有限公司
3
4
A
B
C
D
E
比例
1:1
第1页
F
4
Advertisement
Table of Contents
Related Manuals for ErgoAV ERMTL4
Summary of Contents for ErgoAV ERMTL4
- Page 1 面 技术要求： 1、材质：105g 铜板纸 未经倍思奇 书面许可， 2、展开尺寸：A4，如图所示折叠成型为A5，16P 不得复制部 3、颜色：单色 分或全部内 4、印刷：印刷图档见后续页，双面印刷 容。违者本 5、装订方式:：骑马钉 公司保留追 究法律责任 860-02781-00 PLM号 ERMTL4- 的权利。 名 投影法 第 一 角 投 影 法 Manual(单英)-JY 称 符号标识 图 版本变更 ECO# 标记 处数 发行时间 号 版 本 重量G 比例...
- Page 2 ERMTL4 Thank you for choosing ErgoAV! At ErgoAV, our goal is to add value to your AV experience by providing the highest quality products and services in the industry. We offer a 5-year warranty. If you have any questions or concerns, please contact us.
-
Page 3: Important Safety Information
BEFORE GETTING STARTED, LET'S MAKE SURE THIS MOUNT IS COMPATIBLE Compatible VESA Patterns: Max: 100 x 100mm 300 x 300mm 500 x 400mm 23.6″ 200 x 100mm 400 x 200mm 600 x 400mm 600mm Max: 200 x 200mm 400 x 300mm 15.7″... - Page 4 L TV Bracket Wall Plate Template R TV Bracket Bolt End Cap 8″ Wall Plate Wrench 16″ Wall Plate Allen Key...
-
Page 5: Installation
INSTALLATION Supplied Parts and Hardware for Step 1 Not all hardware included in this package will be used. R TV Bracket L TV Bracket M4/M5 M6/M8 L2.5mm L10mm L22mm Washer Washer Spacer Spacer Spacer M8 x 15mm TV Bolt M4 x 12mm M4 x 30mm TV Bolt TV Bolt... - Page 6 STEP 1 Attach the TV Brackets to Your TV 1-1 Select TV Bolts The correct bolt diameter will thread smoothly into your TV. The depth of the top and bottom holes may differ. 1-2 Position the TV Brackets Arrow Up...
- Page 7 1-3 Secure the TV Brackets For Flat-Back TV, go to Option A on this page. For Bump, Curved TV, Recessed Holes and Cables, go to Option B on next page. WARNING: • DO NOT turn the bolt past the bottom of the hole. •...
- Page 8 Washer B1 | B2 to them to choose the right spacer combination. Spacer F1 | F2 | F3 Note: There are many possible spacer combinations that can be used. (877) 419-7832 Mon-Fri 8am - 8pm (CST) support@ergoav.com...
- Page 9 Supplied Parts and Hardware for Step 2 M6 x 12mm End cap 8″ Wall Plate 16″ Wall Plate Wall Plate Template Bolt CAUTION! This anchor is for concrete and concrete block walls 7/16″ (11mm) ST 5/16 x 2 3/4″ ONLY. DO NOT use them in Wrench Lag Screw Wall Anchor...
- Page 10 Option B: Recommended for 16" / 24" wood studs spacing or TV mount holes spacing ≥200mm Note: Fully tighten the nuts 2-2 Mount the Wall Plate on the Wall For mounting on wood stud walls, go to Option A on page 09 to 10. For mounting on concrete and concrete block walls, go to Option B on page 11 to 12.
- Page 11 Find Studs and Mark Holes 1 6 ″ ( 4 0 6 m 2 4 ″ ( 6 1 0 m 10 0% 10 0% M a r k C e n t e r Mark 4 Hole Positions Drill 4 Holes Note: Be sure to use the specified drill bit.
- Page 12 Option B For Concrete and Concrete Block Wall Installation 35mm 1 3/8″ 2 3/8″ ≥ 8″ (203mm) 35mm 60mm 60mm 1 3/8″ 1 3/8″ 35mm 35mm Tools Needed (Not Included) 3/8″ (10mm) 1/2″ (13mm) Electric Drill Pencil Tape Measure Hammer Level Concrete Drill Bit Socket Wrench...
- Page 13 Tap Wall Anchors In Secure the Wall Plate HEAVY! You may need assistance with this step. 1/2″ (13mm) STEP 3 Verify Wall Plate is Firmly Mounted Pull Down Pull Down...
- Page 14 STEP 4 Hang the TV on the Wall Plate HEAVY! You may need assistance with this step. Pull Down then Release to Lock...
-
Page 15: Level Adjustment
Supplied Parts and Hardware for Step 5 3/16″ (5mm) Allen Key STEP 5 Level Adjustment Note: Please DO NOT overtighten Level or overloosen the bolt To level the TV, turn the bolt on the L TV bracket clockwise to raise or counter-clockwise to lower the left side of the TV. - Page 16 STEP 7 How to Remove the TV HEAVY! You may need assistance with this step. Pull Down to Unlock Note: Disconnect all cables before removing the TV.
-
Page 17: Speaker Stands
At ErgoAV, our goal is to provide the high-quality audio video solutions and product support that you need. If you have any questions, concerns, or feedback, please let us know! Speaker Stands TV Mounts Computer Monitor Mounts ErgoAV 9501 Louisiana Ave N, #200, Brooklyn Park, MN 55445 (877) 419-7832 Mon-Fri 8am - 8pm (CST) support@ergoav.com...
