ELEHEAR Beyond
OTC
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Beyond and is the answer not in the manual?

Questions and answers

Robert Delaney
June 9, 2025

How to turn on ELEHEAR beyond from the hearing it self

gordon hooper
May 31, 2025

Can the receivers eq be changed to reduce the highs

User image 683b6e00c31f8
Don William Richards
May 19, 2025

How to turn on and off mute

Summary of Contents for ELEHEAR Beyond

  • Page 1 ELEHEAR Beyond User Manual...
  • Page 2 WELCOME...
  • Page 3 Thank you for choosing ELEHEAR Beyond Hearing Aids to enhance your hearing experience and improve your quality of life. These hearing aids are individually fitted and fine-tuned to meet your specific hearing needs; therefore, they are not suitable for use by others.
  • Page 4: Table Of Contents

    CONTENTS INSTRUCTIONS FOR USE PRECAUTIONS FEEDBACK ACCESSORIES PRODUCT STRUCTURE OPERATION GUIDE MAINTENANCE AND CLEANING TROUBLESHOOTING GUIDE GENERAL WARNINGS TECHNICAL SPECIFICATIONS EXPLANATION OF GRAPHICAL SYMBOLS USED IN MEDICAL DEVICE LABELING FCC REQUIREMENT CYBERSECURITY PRODUCT WARRANTY...
  • Page 5: Instructions For Use

    INSTRUCTIONS FOR USE...
  • Page 6 PRINCIPLES OF HEARING AIDS ELEHEAR Beyond Hearing Aids utilize the microphone to capture environmental sounds, which are then converted into electrical signals. These signals are transmitted to a digital chip within the hearing aids, where they undergo advanced processing, including filtering and amplification.
  • Page 7 CONTRAINDICATIONS Individuals with acute external otitis, tympanitis, acute suppurative otitis media, chronic suppurative otitis media (in the stage of purulent infection), and those allergic to the materials of this product are not suitable for wearing. INDIVIDUALS UNDER THE AGE OF 18 SHOULD CONSULT A PHYSICIAN BEFORE USING THIS PRODUCT Individuals under the age of 18 require specialized care.
  • Page 8: Precautions

    PRECAUTIONS...
  • Page 9 PRECAUTIONS 1. Hearing conditions professionally examined and audiologically tested before, and hearing aids should be under the guidance of a doctor or a professional dispenser of hearing aids. 2. Pay attention to the moisture-proof, shock-proof, high-temperature-proof, light-proof, and drop-proof features of the products.
  • Page 10: Feedback

    FEEDBACK (ACOUSTIC FEEDBACK)
  • Page 11 New hearing aids users often experience an effect known as acoustic feedback, commonly referred to as "whistling." This occurs when amplified sound leaks out of the ear canal and is picked up by the hearing aids' microphone, creating a feedback loop. It is more likely to occur at higher volume settings.
  • Page 12: Accessories

    ACCESSORIES...
  • Page 13 Hearing Aid x2 Close/Open Domes (S / M / L / XL) x2 Tulip Domes x2 Wax Cap Tool x1...
  • Page 14 ELEHEAR Beyond User Manual Multi-function Tool Pen x1 User Manual x1 ELEHEAR Beyond Quick Start Guide USB Type-C to USB-A Cable x1 Quick Start Guide x1...
  • Page 15: Product Structure

    PRODUCT STRUCTURE...
  • Page 16 ELEHEAR BEYOND (FRONT) Microphone 1 Receiver Power & Switch Button On / off, volume up / down Microphone 2 Ear Dome Hearing Aid Indicator...
  • Page 17 ELEHEAR BEYOND (BACK) Receiver Wire Wax Cap Charging Contact Protector Remove the protectors from the hearing aids before use...
  • Page 18: Charging Case

    CHARGING CASE Hearing Aids Charging Indicator Charging Case Charging Indicator Reset Button Charging Port...
  • Page 19: Operation Guide

    OPERATION GUIDE...
  • Page 20 CHARGING PRIOR TO FIRST USE It is recommended to fully charge both the charging case and hearing aids for 2.5 hours before initial use.
  • Page 21 App before using the product. (1) Open the web browser on your phone and go to: https://elehear.com/pages/app-page to download the App. You can also use the QR code below. (2) Connect your hearing aids to your cell phone.
  • Page 22: Bluetooth Streaming

    BLUETOOTH STREAMING The ELEHEAR Beyond has Bluetooth® to connect with devices like Apple iOS or Android phones. When connected to a phone, it can play music and answer calls hands-free. (1) On your phone: · Turn on Bluetooth · Search for devices (2) Take out the hearing aids from the case, and it will start pairing with Bluetooth, making a "pairing"...
  • Page 23 Note: · Connect the hearing aids to the phone within 30 minutes after taking them out. After this time, the ELEHEAR Beyond Bluetooth won't be detectable. If this occurs, return them to the charging case and then take them out to reconnect.
  • Page 24 WEARING (1) Differentiate between the left and right hearing aids. The left ear device features a blue receiver, while the right ear device is equipped with a red receiver. Left: Blue Right: Red (2) Position the hearing aid on the corresponding ear. The hearing aid body should rest near the upper part of your ear.
  • Page 25 (3) Completely insert the ear (4) Refine the position of the dome into your ear canal. receiver wire to ensure a comfortable fit. Left: Blue Left: Blue Note: Initially, the ear domes might feel unusual or cause slight itchiness in your ear canal. If discomfort arises, replace the ear domes in other sizes which fits your ear better.
  • Page 26: Powering On/Off

    POWERING ON/OFF Press the volume up button for 3s Power On: The hearing aids will power on automatically when removed from the charging case. Alternatively, when powered off, press and hold the volume up button for 3 seconds. Power Off: Place the hearing aids into the charging case and close the lid securely.
  • Page 27: Volume Adjustment

    VOLUME ADJUSTMENT Volume up button makes sound louder Volume down button makes sound softer Short press the volume up button to raise the volume, short press once to raise the volume by one notch (20 notches in total), every time you raise the volume by one notch, the hearing aids will emit a "ding"...
  • Page 28: Restoring Factory Settings

    RESTORING FACTORY SETTINGS Reset Button To restore your hearing aids to factory settings, press and hold the reset button on the charging case for 7 seconds, at which time the white light will flash on and off after 5 seconds.
  • Page 29 CHARGING (1)Charging The Hearing Aids Place the hearing aids in the charging case and make sure the lid is tightly closed; the hearing aids will charge automatically. It takes 1.5 hours to fully charge the hearing aids. In the default setting (hearing aid mode), the battery life is up to 20 hours.
  • Page 30 (2)Charging The Charging Box Connect the charging box to the power outlet for full charging. This procedure can take up to 2.5 hours to fully charge the charging box of the hearing aids cartridge.
  • Page 31 (3)Battery status Hearing Aid Hearing Aid Indicator Status Battery Level Indicator All indicators off No battery 1 light on for 10 seconds Battery level < 30% 2 lights on for 10 seconds Battery level < 60% 3 lights on for 10 seconds Battery level ≥...
  • Page 32 Charging Case Charging Case Indicator Status Battery Level Indicator 1 light blinking for 5 seconds Battery level < 10% 1 light on for 10 seconds Battery level < 30% 2 lights on for 10 seconds Battery level < 60% 3 lights on for 10 seconds Battery level ≥...
  • Page 33 (4)Charging status Hearing Aid & Charging Case Hearing Aid Indicator Status Battery Level Indicator Active flashing mode Battery level < 30% 1 light always on, Battery level < 60% 2 lights on active flashing mode 2 lights always on, Battery level < 90% 1 light on active flashing mode 3 lights always on Battery level ≥...
  • Page 34 REPLACEMENT OF EAR DOMES To ensure the best sound, wear hearing aids properly with the right-sized ear dome. Try different sizes if it feels uncomfortable or the sound is not clear. (1) Hold one end of the receiver and gently remove the ear dome.
  • Page 35 (2) Take a new ear dome and place the receiver at the center of it. (3) Slide the ear dome onto the receiver outlet. The receiver and ear dome should fit snugly together.
  • Page 36 REPLACING WAX CAP (1) Remove the ear cap from the receiver. (2) The wax cap tool has two ends: one for removing the old wax cap and the other for putting on the new one.
  • Page 37 (3) Insert the empty end into the old wax cap on the hearing aids, take out and dispose of the old wax cap. (4) Use the other end and put the new wax cap into the receiver's end. Press it firmly, remove the tool, and dispose it.
  • Page 38: Maintenance And Cleaning

    MAINTENANCE AND CLEANING...
  • Page 39 CLEANING (1) Maintain the hearing aid's cleanliness and dryness is crucial. Prevent water and liquid from entering the hearing aids during daily use. (2) Clean the hearing aid's surface daily by wiping it with a dry cloth or paper towel. Use the provided cleaning brush to gently clean the receiver wire and microphone.
  • Page 42: Daily Cleaning

    DAILY CLEANING Wipe the surface of the hearing aids with a clean, dry, lint-free cloth or the provided cleaning brush. Never use cleaning solutions, solvents, or abrasive cleaners on the hearing aids. WEEKLY CLEANING Use a soft, slightly damp cloth or a specialized hearing aids cleaning wipe to clean the surfaces of the hearing aids and receivers.
  • Page 43: Troubleshooting Guide

    TROUBLESHOOTING GUIDE...
  • Page 44 HOWLING Reason: Loose ear domes Solution: Remove the ear domes and put them back on Reason: The ear domes are not the right size Solution: Replace ear domes with appropriate size Reason: Excessive earwax Solution: Clean your ears Reason: Hearing aids volume is too loud Solution: Turn down the volume or consult an audiologist Reason:...
  • Page 45 SILENT Reason: The device is switched off Solution: Power on Reason: No battery or low battery Solution: Timely charging Reason: The sound outlet of the receiver is blocked Solution: Clean the receiver sound outlet...
  • Page 46: Low Volume

    LOW VOLUME Reason: Due to the volume settings Solution: Adjust the volume in the settings Reason: Battery is low Solution: Charge the battery in time Reason: Ear domes are too loose Solution: Replace the ear domes Reason: Clogged ear domes Solution: Clean the ear domes Reason:...
  • Page 47 THE INDICATOR LIGHT IS NOT ON Reason: Hearing aids are not placed correctly Solution: Reposition so that the charging contacts make full contact Reason: The charging case is out of battery Solution: Charge the charging case BLUETOOTH CONNECTION FAILURE Reason: Bluetooth on the phone is off Solution: Turn on the Bluetooth...
  • Page 48: General Warnings

    GENERAL WARNINGS...
  • Page 49 • If you experience any adverse events while using the ELEHEAR Beyond hearing aids, such as skin irritation in the ear, injuries caused by the device (including cuts, scratches, or burns from an overheated...
  • Page 50 USE OF HEARING AIDS • Keep the volume low when using the hearing aids for the first time. • Professional fitting and adjustment are essential. ELEHEAR Beyond hearing aids should only be used under the guidance and supervision of a qualified hearing care professional. Improper fitting or use can lead to further hearing damage.
  • Page 51: Explosion Hazard

    • If hearing aids or any of their parts are swallowed, seek immediate medical attention. EXPLOSION HAZARD ELEHEAR Beyond hearing aids are safe for use in normal environments. However, they have not been tested or certified for use in potentially explosive atmospheres. Do not use hearing aids in environments with explosion hazards, such as mines, areas with high concentrations of oxygen, or locations where flammable anesthetics are handled.
  • Page 52: Environmental Awareness

    COCHLEAR IMPLANTS If you wear a cochlear implant (CI) in one ear and an ELEHEAR Beyond hearing aids in the other, maintain a minimum distance of 1cm between the two devices at all times. The magnetic fields generated by the CI components, including the sound processor, coil, and magnet, can permanently damage the speaker in the hearing aids.
  • Page 53 ACTIVE IMPLANTABLE DEVICES • ELEHEAR Beyond hearing aids have undergone rigorous testing and meet international standards for human exposure to electromagnetic emissions, including Specific Absorption Rate (SAR), induced electromagnetic power, and voltage. • The levels of these emissions are well below the internationally...
  • Page 54 X-RAYS, CT, MR, PET SCANS, ELECTROTHERAPY, AND SURGERY Hearing aids may be damaged due to strong electromagnetic fields exposure, remove your hearing aids before undergoing X-rays, CT, MR, PET scans, electrotherapy, surgery, or entering other environments with strong electromagnetic fields. HIGH TEMPERATURES AND CHEMICALS •...
  • Page 55: Connecting External Devices

    CONNECTING EXTERNAL DEVICES To ensure the safety of your hearing aids and charging accessories, follow the safety standards of GB 9706.1 : When charging your devices, use the approved power adapter and charging cable as described in the user guide, and ensure that the charging accessories are not placed near an induction cooking surface.
  • Page 56 USE IN AIRPLANES Your hearing aids contains Bluetooth functionality. When you are on an airplane, you must activate flight mode or turn off your hearing aids unless the flight crew allows. USE OF THIRD-PARTY ACCESSORIES Only use accessories, transducers, or cables supplied by the manufacturer.
  • Page 57: Environmental Protection

    INTERFERENCE Hearing aids have been thoroughly tested for interference in accordance with the most stringent international standards. However, hearing aids may be interfered with by other devices (e.g., some cell phones, civil band systems, store alarm systems, and other devices). If this happens, increase the distance between the hearing aids and the interfering device.
  • Page 58: Technical Specifications

    TECHNICAL SPECIFICATIONS...
  • Page 59 ELEHEAR Beyond Parameter Name Hearing Aid Values Full-on Gain 35dB (50dB SPL Input) Maximum Output 115dB SPL (90dB SPL Input) Total Harmonic 500Hz 100dBSPL <2% Distortion + Noise 500Hz 70dBSPL <2% Self-generated 20dB SPL Noise Level Limits Frequency Response 1500Hz...
  • Page 60: Technical Description

    TECHNICAL DESCRIPTION Electrical Safety Classification: Internally powered equipment Protection Against Electric Shock: Type B applied part Mode of Operation: Continuous operation Externally Connected Devices: Any external equipment connected to these hearing aids and powered from the mains supply must comply with GB 9706.1-2020 or equivalent safety standards Bluetooth Version: 5.3 Software Version: V1.0...
  • Page 61 2. Storage Conditions Products should be stored in a well-ventilated area free from corrosive gases and materials. The environment should meet the following conditions. a. Storage Temperature: -10°C to 40°C (14°F to 104°F) b. Relative Humidity: ≤ 80%, non-condensing c. Atmospheric Pressure: 86 kPa to 106 kPa 3.
  • Page 62: Explanation Of Graphical Symbols Used In Medical Device Labeling

    EXPLANATION OF GRAPHICAL SYMBOLS USED IN MEDICAL DEVICE LABELING...
  • Page 63 MEDICAL DEVICE IMAGES Points out a situation that could lead to serious, moderate, or minor injuries According to IEC 60601-1, the applied parts of this device are classified as type B Do not dispose of the device with general domestic waste (Read more in section 'Disposal information') Easily breakable Upwards...
  • Page 64: Fcc Requirement

    FCC REQUIREMENT...
  • Page 65 Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subjected to the following two conditions. (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 66 There is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures.
  • Page 67: Cybersecurity

    CYBERSECURITY...
  • Page 68 Operating Environment: Digital Signal Processor (DSP) chip Software Environment: Real-Time Operating System (RTOS) Security Software: Not applicable Security Software Updates: Not applicable Data and Device Interface: Commands for adjusting hearing aids parameters are transmitted via Bluetooth protocol. Data is stored in binary format User Access Control Mechanism User Authentication: The hearing aids can be discovered and paired...
  • Page 69: Product Warranty

    PRODUCT WARRANTY...
  • Page 70 • Damage from self-disassembly or part assembly • Damage from force majeure (flood, fire, earthquake, etc.) Note: Please refer to www.elehear.com for the latest user manual. Date of Manual Preparation: 22/11/2024 Need more help? EleCare Customer Support is here for you.
  • Page 71 Non-rechargeable batteries are not to be recharged. Do not force discharge, recharge, disassemble, heat above 45℃ or incinerate. Doing so may result in injury due to venting, leakage or explosion resulting in chemical burns. ©2024 Elehear INC. All rights reserved. Rev A 11/24...
  • Page 72 (888) 669-1099 ELEHEAR Inc. 708,Building 12, Shenzhen Bay Tech-Eco Park,Nanshan District Shenzhen Guangdong,China V 1.2...
