Related Manuals for Intellijel Stereo I/O 1U
Summary of Contents for Intellijel Stereo I/O 1U
- Page 1 Stereo I/O 1U Complete Audio I/O for Intellijel Cases & Modules Manual (English) Revision: 2024.12.12...
-
Page 2: Table Of Contents
Example B.1: Balanced Stereo I/O with 104HP Palette............. 10 Example B.2: Unbalanced Mono I/O with 62HP Palette............11 Connecting Stereo I/O 1U to Stereo Line In / Line Out Jacks 1U............ 11 Connecting Stereo I/O 1U to XY I/O 1U................... 12 TECHNICAL SPECIFICATIONS...................... -
Page 3: Compliance
(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by Intellijel Designs, Inc. could void the user’s authority to operate the equipment. Any digital equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Installation
Before You Start Intellijel Eurorack modules are designed to be used with a Eurorack-compatible case and power supply. We recommend you use Intellijel cases and power supplies. Before installing a new module in your case, you must ensure your power supply has a free power header and sufficient available capacity to power the module:... -
Page 5: Installing Your Module
Eurorack case. Ensure the red stripe on the cable lines up with the -12V pins on the bus board. On Intellijel power supplies the pins are labelled “-12V” with thick white stripe. Sometimes the connectors are shrouded, ensuring the cable can only be oriented in one direction. - Page 6 After you have confirmed all the connections, you can reconnect the power cable and turn on your modular system. You should immediately check that all your modules have powered on and are functioning correctly. If you notice any anomalies, turn your system off right away and check your cabling again for mistakes. Stereo I/O 1U Manual...
-
Page 7: Overview
- Stereo I/O 1U has got you covered. The main features of this module include: ● Main output to balanced stereo line level with volume control (for line mixers, FX, speakers etc.) -
Page 8: Front Panel
Left Position = Cue Out only, Right Position = Module Out only. HEADPHONE LEVEL Attenuator for HEADPHONE OUTPUT MODULE OUT SWITCH: Sets module output. Left Position = CUE OUT [D] + MAIN OUT Right Position - MAIN OUT only. MAIN OUTPUT LEVEL Attenuator for module output. Stereo I/O 1U Manual... -
Page 9: Back Panel
BACK PANEL Stereo I/O 1U connects to compatible Intellijel Cases & Modules via connectors on the rear side of the module: UNBAL-IN: Unbalanced 3-pin input connector. This takes line level input from connected cases or modules and routes to EXT INPUT on the front of the module. -
Page 10: Connection Examples
CONNECTION EXAMPLES To give you an idea of how Stereo I/O 1U interfaces with compatible modules & cases, here are some common examples. Connecting Stereo I/O 1U to the Audio Jacks on your 7U Case If you have a 2nd-Gen Audio Jacks board installed in your Intellijel 7U Performance Case, it is possible to connect Stereo I/O 1U to the ¼”... -
Page 11: Example A.2: Unbalanced Stereo I/O
Connecting Stereo I/O 1U to the Audio Jacks on a Palette Case If you have an Intellijel Palette Case, you can connect Stereo I/O 1U directly to the ¼” audio jacks on the top of the Palette (1x pair on the Palette 62, and 2x pairs on the Palette 104). You also have the option to use the 3-pin (unbalanced) or 6-pin (balanced) connectors. -
Page 12: Example B.2: Unbalanced Mono I/O With 62Hp Palette
Connecting Stereo I/O 1U to Stereo Line In / Line Out Jacks 1U If you're using a third-party case with available 1U space, you can connect Stereo I/O 1U to Stereo Line In Jacks 1U and Stereo Line Out Jacks 1U for external connections, using the 6-pin (balanced) connectors. -
Page 13: Connecting Stereo I/O 1U To Xy I/O 1U
Connecting Stereo I/O 1U to XY I/O 1U XY I/O 1U has smaller ⅛” TRS jack sockets which can be linked to Stereo I/O 1U instead of the larger ¼” options already mentioned. This is useful for smaller systems, or connecting to devices with ⅛”... -
Page 14: Technical Specifications
Maximum Depth 42 mm Current Draw 48mA @ +12V 29mA @ -12V Compatible Intellijel Modules & Cases Intellijel Case / Module Input > Stereo I/O Stereo I/O > Output 104HP / 84HP x 7U Performance Case 2 CH Balanced Dual ¼” TRS 2 CH Balanced Dual ¼”...
