Tools Required

7/16" Nut Driver
Adjustable Wrench
S crewdriver (Phillips)
Magnetic Compass
E lectric Drill and B it
Optional Accessories
Typical installation kits (sold separately) include:
• Mast base mounting hardware
• R G 6 coaxial cable(s) with F connectors
• Grounding hardware, grounding wire, wire clips, etc.
• 6" plumbing level
(not included)
Steps for Installation
In the following pages, you'll find step-by-step instructions for:
1 Determining Coordinates for Aiming Antenna ........ page 4
2 Finding S uitable Antenna S ite ............................. page 5
3 Installing E ZALIGN™ Mast...................................page 6
4 Assembling/Adjusting Antenna on Ground..............page 7
5 Attaching Antenna to Mast ...................................page 7
6 R outing R G 6 Cable(s) .........................................page 8
7 Grounding Cable and Antenna ..............................page 8
8 Attaching LNB to Antenna....................................page 9
9 Aiming and Fine-tuning Antenna...........................page 9
Information Also Included:
Troubleshooting Check List for Initial Installation.........page 11
Loss of S ignal/R ain Fade............................................page 12
Installation with Long Cable R un ................................page 12
