Durabrand DCT1904R Owner's Manual

DURABRAND
WAL-MART warrants this product to be free from manufacturing defects, in material and
workmanship under normal use and conditions for a designated period from date of original
purchase in Canada. For a WARRANTY period of
12 MONTHS
Should service be necessary under this warranty for any reason due to manufacturing
defect during the warranty period, Wal-Mart Canada will repair or replace (at its discretion)
the defective merchandise at no charge.
THIS UNIT CAN BE REPAIRED AND OR REPLACED BY WAL-MART CANADA SERVICE
NOTE: This warranty is void if the product is:
(a) Damaged through negligence, misuse, abuse, or accident.
(b) Used in a commercial application or rentals.
(c) Modified or repaired by anyone other than Wal-Mart Canada.
(d) Damage caused by improper connection to other equipment.
(e) If the original proof of purchase cannot be supplied.
NOTE: This warranty does not cover:
(a) Damage to the tape or tape cartridge (if applicable).
(b) Cleaning of video heads (if applicable).
(c) Damage occurred or costs incurred in the shipping of the product to Wal-Mart
Canada.
(d) Ordinary adjustments to the product which can be performed by customer as out-
lined in the owner's manual.
(e) Signal reception problems caused by external antenna, cable systems or interference.
(f) Incompatibility due to the change in TV/CATV broadcast systems after the product
was sold.
THIS WARRANTY IS NON-TRANSFERABLE AND APPLIES ONLY TO THE ORIGNAL PUR-
CHASER AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT, ANY
APPLICABLE IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY,
ARE LIMITED IN DURATION TO A PERIOD OF THE EXPRESSED WARRANTY AS PROVIDED
HEREIN BEGINNING WITH THE DATE OF ORIGINAL PURCHASE AT RETAIL AND NO
WARRANTIES, WHETHER EXPRESSED OR IMPLIED, SHALL APPLY TO THIS PRODUCT
THEREAFTER.
UNDER NO CIRCUMSTANCES SHALL WAL-MART CANADA BE LIABLE FOR ANY LOSS,
DIRECT, INDIRECT, INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGE ARISING OUT OF,
OR IN CONNECTION WITH THE USE OF THIS PRODUCT.
WAL-MART CANADA Inc.
0EMN02474
ANTENNA/CABLE CONNECTIONS
Bent pin
Cable Plug
(Needs to be straightened) (Straight pin)
Before plugging the UHF/VHF
Rod Antenna (Not supplied) into
the ANT(enna). IN jack, check
that the pin is not bent. If it is
bent, straighten the pin as illus-
trated, then plug the pin into the
ANT(enna). IN jack.
VHF/UHF
Combination Antenna
(Not supplied)

CLOSED CAPTION

This TV can receive C1 and C2 of Caption and Text.
CAPTION MODE
1) Closed Caption Characters can be displayed on the TV screen only when the received
broadcast signal contains Caption Signals.
2) Paint-on mode: Displays input characters on the screen immediately.
Pop-on mode: Once characters are stored in memory, they are displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)
Note: If the CAPTION C1 or C2 is selected but a Closed Caption signal is not included,
characters will not be displayed.
TEXT MODE
1) Displays the text on the screen by scrolling (max. 7 lines)
2) If the received broadcast signal does not contain the caption or text signal, no change will
occur.
Limited
WARRANTY
1940 Argentia Road
Mississauga, Ontario
L5N 1P9
Canada
UHF/VHF Rod
Antenna
(Not supplied)
VHF
Antenna
(Not supplied)
UHF
Antenna
(Not supplied)
OR
VHF/UHF Combiner
(Not supplied)
Owner's
Manual
FEATURES
●
Tinted, Bright Black Matrix Picture Tube
●
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
●
PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic tun-
ing system provides free and easy channel selection, and lets you tune directly to any channel
using the channel number buttons (0~9 and +100-key) on the remote control.
●
On-Screen Function Display
●
Full-Function Remote Control
●
Sleep Timer
●
Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.
●
Auto Shut Off Function- If there is no signal input from the antenna terminal and no opera-
tion for 15 minutes, the TV will turn itself off automatically.
●
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.
PRECAUTION
●
Place your TV in a room with adequate ventilation.
●
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
●
Do not place your TV on soft surfaces, such as rugs or blankets.
●
Leave enough room for air to circulate around the bottom, top and back of the set.
The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.
Date of Purchase
Dealer Purchase from
Dealer Address
Printed in Malaysia
L2307CH * * * * *
* Some cable TV systems use scrambled
signals and require a special converter
to receive these channels. Consult your
local cable company.
*
CATV Box
or Satellite Box
(Not supplied)
OUT IN
ANT.IN
75-ohm
Coaxial Cable
ANT. IN
OR
Notes:
1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a VCR's
video output channel (CH3 or CH4), your TV may not display the correct caption or text.
2) Captions and texts may not match the TV voice exactly.
3) Interference may cause the closed caption system not to function properly.
4) The caption or text characters will not be displayed while the menu display or function's dis-
play is shown.
5) If you see this screen :
If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].
19 INCH
COLOR TELEVISION
DCT1904R
Dealer Phone No.
Model No.
Serial No.
CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
MISE EN GARDE:
POUR ÉVITER LES CHOCS ÉLECTRIQUES,
INTRODUIRE LA LAME LA PLUS LARGE DE
LA FICHE DANS LA BORNE CORRESPON-
DANTE DE LA PRISE ET POUSSER
JUSQU'AU FOND.
FCC WARNING- This equipment may
From Cable System
generate or use radio frequency energy.
or Satellite Antenna
75-ohm
Changes or modifications to this equip-
Coaxial Cable
ment may cause harmful interference
unless the modifications are expressly
approved in the instruction manual.
From Cable System
The user could lose the authority to
operate this equipment if an unautho-
rized change or modification is made.
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to
Article 820-40 of the NEC that provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be connected to the ground-
ing system of the building as close to the point of cable entry as practical.
