Durabrand DCT1303R Owner's Manual

0EMN02195
ANTENNA/CABLE CONNECTIONS
CAUTION: TO PREVENT ELECTRIC
SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY
INSERT.
Before plugging the UHF/VHF Rod
Antenna into the ANT(enna). IN jack, check
that the pin is not bent. If it is bent, straight-
en the pin as illustrated, then plug the pin
into the ANT(enna). IN jack.
(Rod Antenna is included in 13 inch model
only)
Bent pin
Cable Plug
(Needs to be straightened) (Straight pin)

CLOSED CAPTION

This TV can receive C1 and C2 of Caption and Text.
Caption Mode
(1) Characters can be displayed on the TV screen when the received broadcast signal contains the
Caption Signals.
(2) Paint-on mode: Displays input characters on the screen immediately.
Pop-on mode: Once characters are stored in memory, it is displayed all at once.
Roll-up mode: Displays the characters continuously by scrolling (max. 4 lines)
Note: If the CAPTION C1 or C2 is selected but the caption signal is not included, characters will
not be displayed.
Text Mode
(1) Displays the text on the screen by scrolling (max. 7 lines)
(2) If the received broadcast signal does not contain the caption or text signal, no change will
occur.
Printed in Malaysia
L6315CR/ L6415CR * * * * *
VHF
Antenna
(Not supplied)
UHF
Antenna
(Not supplied)
VHF/UHF Combiner
(Not supplied)
VHF/UHF
Combination Antenna
(Not supplied)
Owner's
Manual
FEATURES
G
Tinted, Bright Black Matrix Picture Tube
G
181 Channel Selection- All VHF/UHF channels plus up to 125 cable channels.
G
PLL Frequency Synthesized Tuning- The latest PLL frequency synthesized electronic tun-
ing system provides free and easy channel selection, and lets you tune directly to any channel
using the channel number buttons (0~9 and +100-key) on the remote control.
G
On-Screen Function Display.
G
Full-Function Remote Control
G
Sleep Timer
G
Closed Caption Decoder- You may view specially labeled (cc) TV programs, movies, news,
prerecorded tapes, etc. with either a dialogue caption or text display added to the program.
G
Auto Shut Off Function- If there is no air signal input from the antenna terminal and no
operation for 15 minutes, the TV will turn itself off automatically.
G
V-CHIP- Enables parents to prevent their children from watching inappropriate material on TV.
PRECAUTION
G
Place your TV in a room with adequate ventilation.
G
Keep your TV set away from sources of direct heat, such as heat registers or direct sunlight.
G
Do not place your TV on soft surfaces, such as rugs or blankets.
G
Leave enough room for air to circulate around the bottom, top and back of the set.
NOTE: CHANNEL SET UP MUST BE COMPLETED BEFORE THE SET WILL FUNC-
TION PROPERLY. SEE INSIDE FOR PROCEDURE.
The serial number of this product may be found on the back of the TV. No others have the same
serial number as yours. You should record the number and other vital information here and retain
this book as a permanent record of your purchase to aid identification in case of theft.
Date of Purchase
Dealer Purchase from
Dealer Address
This Owner's Manual is made of recycled paper.
UHF/VHF Rod
Antenna
(Supplied with 13
inch model only)
CATV Box
or Satellite Box
(Not supplied)
OUT
ANT.IN
ANT. IN
OR
OR
Note to CATV system installer:
This reminder is provided to call the CATV system installer's attention to Article 820-40 of
the NEC that provides guidelines for proper grounding and, in particular, specifies that the
cable ground shall be connected to the grounding system of the building as close to the point
of cable entry as practical.
Notes:
(1) When your TV receives a special effects playback signal (i.e., Search, Slow, Still) from a
VCR's video output channel (CH3 or CH4), your TV may not display the correct caption or
text.
(2) Captions and texts may not match the TV voice exactly.
(3) Interference may cause the closed caption system not to function properly.
(4) The caption or text characters will not be displayed while the menu display or function's dis-
play is shown.
(5) If you see this screen:
If your TV displays a black box on the screen, this means that your TV is set to TEXT mode. To
clear screen, select CAPTION C1, C2 or CAPTION [OFF].
COLOR TELEVISION
DCT1303R
DCT1903R
Dealer Phone No.
Model No.
Serial No.
*
Some cable TV systems use scram-
bled signals and require a special con-
verter to receive these channels.
Consult your local cable company.
*
IN
From Cable System
or Satellite Antenna
75-ohm
Coaxial Cable
75-ohm
Coaxial Cable
From Cable System
(13 inch)
(19 inch)
