Item #1000 000 000
Model #XXXXXXX
USE AND CARE GUIDE
PANTRY
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Cabinet. We strive to continually create quality
products designed to enhance your home. Visit us online to SEE our full line of products available for your home improvement needs. Thank you for
choosing Hampton Bay!
INTERNAL USE
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY PANTRY
Summary of Contents for HAMPTON BAY PANTRY
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this Cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to SEE our full line of products available for your home improvement needs. Thank you for...
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Pre-Assembly ..............5 Safety Information ............2 PACKAGE CONTENTS ..............5 CALIFORNIA RESIDENTS ............2 Cabinet Assembly ............6 MINNESOTA RESIDENTS ............2 Cabinet Assembly (Continued) ........8 Before Putting in Use ..........13 Warranty ................. 2 Care and Cleaning ............ -
Page 3: Introduction To Clickready Technology
Introduction to CLICKREADY Technology Powered by This cabinet uses PERMANENT Ready to Assemble (RTA) technology that CANNOT be disassembled. You must carefully review instructions and ensure proper alignment during assembly. All connectors and dowels must line up when assembling cabinet. Quantity of connectors/dowels depends on the cabinet type and size. -
Page 4: Pre-Assembly
Assemble the cabinet on a soft surface such as carpet or the cardboard container of this product. PEOPLE REQUIRED BASE CABINETS with a width greater than or equal to 27" , CORNER WALL CABINET, LAZY SUSAN CABINET, PANTRY, OVEN CABINET require two people to assemble. -
Page 5: Pre-Assembly
Top and Bottom Panels BASE CABINET Face Frame and Doors Side Panel Back panel Bottom Panel Shelf Toe Kick * 96 in. Tall pantry has 4 shelves, lower pantries have 3 shelves. HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. INTERNAL USE... -
Page 6: Cabinet Assembly
Cabinet Assembly Attaching the side panels into the face frame Start by placing the face frame (A) flat on a smooth surface that will not scratch or damage the face of the cabinet, such as a towel or piece of cardboard (1) from the packaging. NOTE Identification: Face frame /Side panels of BASE CABINET are longer than Face frame /Side panels of TOP CABINET. -
Page 7: Sliding Panel
Cabinet Assembly Attaching the bottom and top panel The top and bottom The bottom panel (I) NOTE : Identification panels (E) of TOP of BASE CABINET has CABINET are identical - 1 male connector and have: - 1 female connector 2 male connectors. -
Page 8: Cabinet Assembly (Continued)
Cabinet Assembly (Continued) Attaching the back panel to the bottom/top panels Back panel (H) of NOTE Back panel (C) of : Identification BASE CABINET has TOP CABINET has 1 groove and 2 groove and longer. shorter. TOP CABINET Flex outwards 2 side panels (B) slightly then place mating groove on the back panel (C) to the top and bottom panel (E) as shown. - Page 9 Cabinet Assembly (Continued) Attaching the side panels to bottom panel. Install the two side panels (B/G) to the back panel (C/H) by: aligning the wooden dowels & female connectors on the back panel (C/H) to the holes & male connectors on side panels (B/G). IMPORTANT : Use your hands to grab the 2 side panels (B/G) inward at all locations with connectors to ensure they lock together with (C/H) tightly.
-
Page 10: Connection Check
Cabinet Assembly (Continued) Check before installing IMPORTANT: - Before putting in to use, use a rubber mallet and wodden pad to tap all locations with connectors to ensure they lock together tightly. - The wooden pad helps avoid damaging the product. CONNECTION CHECK □... - Page 11 Install 8 metal plates (GG) into the underside of the TOP CABINET and secure with 2 screws (BB) for each metal plate (DO NOT TIGHTEN THE SCREWS AT THIS STEP) IMPORTANT To lift the Pantry up, at least 2 people are required. TOP CABINET NOTE: Metal brackets GG and screws BB are packed inside the BASE CABINET package ...
- Page 12 Cabinet Assembly (Continued) Installing the shelves 00000 TOP CABINET BASE CABINET Insert the shelf pins with pre-drilled holes on each side panel. Tilt the shelf (D) to fit inside the face frame and snap over the shelf pins (AA). ...
-
Page 13: Before Putting In Use
Before Putting in Use Move product IMPORTANT: To avoid damaging the product when moving: ▪ DO NOT slide the product on the floor to avoid product damaged ▪ Needs at least 2 people to lift the product, move it to another location and then put it down. Lift the product, move it to another location and then put it down ... -
Page 14: Care And Cleaning
Care and Cleaning □ For normal spills, a damp cloth is sufficient. Dry the surface immediately. □ Doors can be cleaned with most general-purpose household cleaners. □ Do not use caustic agents and/or abrasive scrubbers, or oven cleaners. □ Cabinets can be cleaned with a damp sponge or cloth using soapy water, or most general-purpose household cleaners. Do not use any abrasive cleaner or scrubbers. - Page 15 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use. INTERNAL USE...
