Meco OMAHA 3000 Series Instructions For Assembling And Installing page 6

SERIES 3000 HEAVY DUTY, SERIES 4000 STANDARD HEAVY DUTY AND
Upright
SD Pin (HK-29)
3/8
Carriage Bolt
(HK-47)
Arm
Bolt on Lip
(supplied only when arms are
ordered with lips)
3/8 Flat Washer (HK-47)
3/8 Nut
(HK-47)
The load must be supported by enough
arms to prevent load deflection. Deflection
may cause damage to the load being
stored as well as the arms (figure A1). To
detect deflection, place the load over two
wooden blocks (to represent cantilever
arms) as shown in figure A2. If deflection
is not present it is acceptable to use a
two arm system as long as this does not
create an overload condition. If the load
shows deflection use three blocks as
shown in figure A3 or four blocks as in
figure A4.
IMPORTANT: The load should overhang
the end arms by one-half the distance from
upright centerline to upright centerline.
Failure to observe this measure may
cause an overload condition on the arms.
INSTRUCTIONS FOR ASSEMBLING MECO OMAHA
SERIES 5000 EXTRA HEAVY DUTY CANTILEVER RACKS
SD Keeper
(HK-29)
ARM TO UPRIGHT CONNECTION
Lift up
Figure A1
Improperly Loaded
(Not enough arms to prevent load deflection.)
Load - 2 Arms
/
1
4
Upright
Centerline
Load - 3 Arms
/
/
1
1
6 3
Load - 4 Arms
/
/
1
1
4
8
Adhering to these guidelines will
ensure that each arm supports an
equal amount of the load's weight.
After attaching the
arm to the upright, lift
up on the tip of the
arm to seat the arm
bracket against the
upright.
/ /
1 1
2 4
Upright
Centerline
/
1
3
/ /
1
1
4 4
Page 6 of 7
Figure A2
Figure A3
/
1
6
Figure A4
/
1
8
JANUARY 2025
