TNET-ENC-H101-DA
1G 4K60 AVoIP Encoder with Dante AV
All Rights Reserved
Version: TNET-ENC-H101-DA_2024V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TNET-ENC-H101-DA and is the answer not in the manual?

Questions and answers

Related Manuals for TiGHT AV TNET-ENC-H101-DA

Summary of Contents for TiGHT AV TNET-ENC-H101-DA

  • Page 1 TNET-ENC-H101-DA 1G 4K60 AVoIP Encoder with Dante AV All Rights Reserved Version: TNET-ENC-H101-DA_2024V1.0...

  • Page 2: Fcc Statement

    1G 4K60 AVoIP Encoder with Dante AV Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.

  • Page 3: Safety Precautions

    1G 4K60 AVoIP Encoder with Dante AV SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...

  • Page 4: Table Of Contents

    1G 4K60 AVoIP Encoder with Dante AV Table of Contents 1. Product Introduction ....................6 1.1 Key Features ..................... 6 1.2 Package List ...................... 7 1.3 Customer Service ....................7 2. Technical Specification ....................8 3. Panel Description ...................... 11 3.1 Front Panel ......................
  • Page 5 1G 4K60 AVoIP Encoder with Dante AV 5.5.2 802.1x (Coming Soon) ................24 5.5.3 LDAP (Coming Soon) ................24 5.5.4 AES256 Encryption (Coming Soon) ............24 5.5.5 SSH (Coming Soon) ................25 5.6 Control ......................25 5.6.1 RS232 ....................25 5.6.2 IR ......................

  • Page 6: Product Introduction

    1G 4K60 AVoIP Encoder with Dante AV 1. Product Introduction The T-Network Series represents a revolutionary line of AVoIP (Audio Video over IP) devices that redefine the user experience and enhance flexibility in audiovisual applications. Thoughtfully crafted in Scandinavia, this series features two encoder models and a single decoder model.

  • Page 7: Package List

    Note: Please contact your distributor immediately if any damage or defect in the components is found. 1.3 Customer Service TiGHT AV provide a limited warranty for the product within five years counting from date of purchase (The purchase invoice shall prevail). For more information see TiGHT AV general Warranty Statement at or just scan the QR-code below.

  • Page 8: Technical Specification

    1G 4K60 AVoIP Encoder with Dante AV 2. Technical Specification VIDEO Digital Video Inputs HDMI 2.0b Streaming video via RJ45, Dante AV-A or TNET Video Stream Digital Video Output Local HDMI 2.0 output Maximum resolution 4096x2160P 4:4:4 HDR10/HLG/HDR10+/Dolby Vision support HDCP Support HDCP 2.3/1.x Color Space support...
  • Page 9 1G 4K60 AVoIP Encoder with Dante AV Analog Audio Format LPCM 2.0, 32kHz -192kHz Dante Audio Format LPCM 2.0, 32kHz -192kHz Dante Audio Sample 44.1, 48, 88.2, 96 kHz Rate ANALOG AUDIO PERFORMANCE Frequency Response 20Hz - 20kHz, ±0.5dB S/N Ratio >90 dB 20 Hz -20 kHz (@0dB gain) A-weighted THD +N <...
  • Page 10 1G 4K60 AVoIP Encoder with Dante AV PoE+ (802.3at), PoE++ (802.3at) for PoE/PoE+ passthrough Max power consumption 15.4W(Max) Standby Power 5.4W Consumption ENVIRONMENTAL Operating Temperature -5°C ~ +55°C Storage Temperature -20°C ~ +70°C Humidity 10 - 90% RH (non-condensing) 26.5 BTU/hr (Typical) Heat Dissipation 48.7 BTU/hr (Max) Fan (User Configurable)

  • Page 11: Panel Description

    1G 4K60 AVoIP Encoder with Dante AV Illuminates yellow when streaming with no source image (No valid signal). Illuminates green when the corresponding source is HDMI selected. ID-Button Multi-purpose button, refer to manual RESET Factory reset WEB UI, Open API via Ethernet or RS-232, Dante Control Controller, DDM, Dante Director, Front panel 3.

  • Page 12: Rear Panel

    1G 4K60 AVoIP Encoder with Dante AV IR IN: 3-pin terminal block for IR receiver sensor. Reset: • Factory reset button: Short Press: Reboot unit. 3s press: Factory reset keeping IP settings. 10s press: Factory reset including IP settings (default is DHCP). 3.2 Rear Panel DC24V: 1x Power connector, 24V6.5A power adapter (Sold separately).

  • Page 13: System Connection

    1G 4K60 AVoIP Encoder with Dante AV Dante TX • Audio IN/OUT selection by GUI/API. • Balanced/unbalanced selection by GUI/API. RS232/IR Out RS232: 3-pin terminal block, RTG line sequence. • IR OUT: 2-pin terminal block for IR emitter. • 4. System Connection 4.1 Usage Precaution Ensure that all components and accessories are included prior to installation.

  • Page 14: Web-Ui Operation

    1G 4K60 AVoIP Encoder with Dante AV 5. Web-UI Operation TNET series can be configurated and controlled via a web-based GUI. To access it, open a web browser and enter the unit's IP address. TNET devices are set to use DHCP by default, and the IP address can be located in the information displayed on the OLED screen.

  • Page 15: Start Tab

    1G 4K60 AVoIP Encoder with Dante AV 5.1 Start Tab This tab shows the unit information and settings for video, audio and Dante/AES67. 5.1.1 Information Lists the unit essential information including device name, model name, IP • address, MAC address, host name, unique serial number and firmware version. 5.1.2 Video Input HDMI Status: Show the source status, HDCP status and version.

  • Page 16: Stream Preview

    1G 4K60 AVoIP Encoder with Dante AV 5.1.4 Stream Preview A MJPEG sub-stream displaying the currently selected active source, which can be used as a preview video in multiple applications. Enable Button: Enable or disable MJPEG preview sub-stream. • • Resolution: 1280x720(default)/960x540/640x460.

  • Page 17: Aes67

    1G 4K60 AVoIP Encoder with Dante AV • Analog Audio Audio Direction: Analog audio direction setting, input or output selection. Signal Select: Balanced or unbalanced audio type selection. Analog Output: Analog output audio selection, supports HDMI/Dante/AES67 Volume Control: Analog audio volume setting. Output Delay: Analog audio output delay, support range 0 –...

  • Page 18: Dante

    1G 4K60 AVoIP Encoder with Dante AV 5.1.7 Dante T-NET devices are equipped with Dante AV-A capabilities, offering two operational modes: Dante AV-A for both video and audio, or audio-only functionality. • Dante AV-A mode requires Audinate software’s for stream management, such as Dante Controller, Dante Director or DDM.

  • Page 19: Edid/Hdcp

    1G 4K60 AVoIP Encoder with Dante AV 5.2 EDID/HDCP 5.2.1 EDID • Configure EDID for HDMI input. Supports EDID Copy from Decoder, Predefined EDID or User Defined EDID. • Copy Output EDID: Read and copy EDID from any decoder in system. Predefined EDID List: •...

  • Page 20: Device

    1G 4K60 AVoIP Encoder with Dante AV Enable or disable HDMI input HDCP compatibility. This feature is particularly • beneficial for scenarios and applications involving Apple devices, where streaming content over the internet or recording is required. 5.3 Device 5.3.1 OLED Display T-NET units feature a 2 line OLED display for easy access to information, installation and troubleshooting Front panel OLED screen display information setting.

  • Page 21: No Source Image (Coming Soon)

    1G 4K60 AVoIP Encoder with Dante AV 5.3.2 No Source Image (Coming Soon) No Source Image will be streamed out whenever encoder can’t detect a valid input source. This image can offer valuable troubleshooting insights, guidance on utilizing an application, or serve as straightforward digital signage. Supports png/jpg/gif image formats.

  • Page 22: Fan Control

    1G 4K60 AVoIP Encoder with Dante AV • Factory Reset: Resets device but still keeping IP settings. • Full Factory Reset: resets device including IP settings • Configuration: Export device settings to a JSON file. Import device settings from a previously saved JSON file. 5.3.4 Fan Control Fan Control •...

  • Page 23: Usb Host

    1G 4K60 AVoIP Encoder with Dante AV 5.3.6 USB Host T-NET encoders supports delivering USB data to a USB host device connecting USB devices located on decoders across the network by functioning as a 7-port virtual USB 2.0 hub. Encoders are capable of connecting up to a maximum of 7 USB 2.0 devices from any of the decoders on the network, along with an unlimited number of keyboard and mouse devices.

  • Page 24: Snmp (Coming Soon)

    1G 4K60 AVoIP Encoder with Dante AV Discovery: Enable or disable Multicast mDNS discovery Discovery Packet Send Interval: Set the interval for mDNS packets to be sent. IGMP: Unit can be set to use IGMP v2 (default) or IGMP v3. •...

  • Page 25: Ssh (Coming Soon)

    1G 4K60 AVoIP Encoder with Dante AV 5.5.5 SSH (Coming Soon) Coming Soon 5.6 Control 5.6.1 RS232 T-NET units features a comprehesive RS232 control platform for controlling legacy third-party devices that don’t support IP control. • IP to RS232 Tunneling: Send commands over IP to extract on local RS232 port of a T-NET unit.
  • Page 26 1G 4K60 AVoIP Encoder with Dante AV • User-defined Commands: Stored commands for easy access from WEB UI or API to control third-party device connected to RS232 port. Up to 5 commands to be stored locally in a T-NET unit with custom naming.
  • Page 27 1G 4K60 AVoIP Encoder with Dante AV The command will be displayed in the field for convenient copying. • Up to 40 IR commands can be stored locally in a T-NET unit with custom naming. Commands can be triggered in WEB UI or by API command. Pronto Format Supports export and import of User-defined Commands file for easy commissioning in larger systems.

  • Page 28: Trigger Commands

    1G 4K60 AVoIP Encoder with Dante AV 5.6.3 Trigger Commands Trigger commands are stored commands that can be triggered based on events in T- NET devices. Commands can be set out using various protocols, TCP, UDP, RS232 and IR to fit any application In more straightforward scenarios, they can also eliminate the necessity for an independent control system by utilizing automation.

  • Page 29: Api Commands (Coming Soon)

    1G 4K60 AVoIP Encoder with Dante AV Reset Log: Clears the Command Log. • Enable Debug Logging: Initiates the debug log to capture events and allows for • saving as a file that can be exported using the “Export File” button. 6.

  • Page 30: Drawings And Dimensions

    1G 4K60 AVoIP Encoder with Dante AV 8. Drawings and Dimensions 9. Environment and recycling information 9.1 Disposal of electric and electronic devices EC Directive 2012/19/EU This product is not to be treated as regular household waste but must be returned to a collection point for recycling electric and electronic devices.

  • Page 31: Packaging Recycling Information

    1G 4K60 AVoIP Encoder with Dante AV 9.2 Packaging recycling information Note: This manual is recycled as paper (mixed paper and card).
