- Page 1 User Manual VC-C101U-ETH USB-C to HDMI2.0 converter with USB and Ethernet All Rights Reserved Version: VC-C101U-ETH_2021V1.0...
- Page 2 USB-C to HDMI2.0 converter with USB and Ethernet Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 USB-C to HDMI2.0 converter with USB and Ethernet SAFETY PRECAUTIONS To ensure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material ⚫...
-
Page 4: Table Of Contents
USB-C to HDMI2.0 converter with USB and Ethernet Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Packing List ....................... 2 1.3 Customer Service ....................2 2. Specification ....................... 3 3. Panel Description ......................4 3.1 Front Panel ......................4 3.2 Rear Panel ...................... -
Page 5: Product Introduction
USB-C to HDMI2.0 converter with USB and Ethernet 1. Product Introduction Thanks for choosing the VC-C101U-ETH USB-C to HDMI converter. This converter is designed to convert 4K@60Hz 4:4:4(max) DisplayPort alt mode signal over USB-C video input to 4K@60Hz 4:4:4(max) HDMI 2.0 video output. For the USB-C input interface, it also supports USB 3.1 Gen2 data transfer, Gigabit LAN and 60W fast-... -
Page 6: Packing List
USB-C to HDMI2.0 converter with USB and Ethernet 1.2 Packing List 1x VC-C101U-ETH ⚫ 2x Mounting Ears with 4 Screws ⚫ 4x Plastic Cushions ⚫ 1x Power Adapter (DC 24V/5A) ⚫ 1x User Manual ⚫ 1.3 Customer Service We provide limited warranty for the product within five years counting from date of purchase (The purchase invoice shall prevail). -
Page 7: Specification
USB-C to HDMI2.0 converter with USB and Ethernet 2. Specification Video Input Input (1) USB Input Connector (1) USB-C Input Resolution Up to 4K@60Hz 4:4:4 USB Standard USB3.1 Gen2 Video Output Output (1) HDMI Output Connector (1) Female type-A HDMI HDMI Output Resolution Up to 4K@60Hz 4:4:4 HDMI Standard... -
Page 8: Panel Description
USB-C to HDMI2.0 converter with USB and Ethernet 3. Panel Description 3.1 Front Panel ① Power LED: The LED illuminates green when power is applied. ② CHARGING: The LED illuminates green when USB-C is charging an external device. 3.2 Rear Panel ①... -
Page 9: System Connection
USB-C to HDMI2.0 converter with USB and Ethernet 4. System Connection The following diagram illustrates typical input and output connections that can be utilized with the VC-C101U-ETH:... -
Page 10: Panel Drawing
USB-C to HDMI2.0 converter with USB and Ethernet 5. Panel Drawing...
