- Page 1 TNET-DEC-H211-DA 1G 4K60 AVoIP Decoder with Dante AV All Rights Reserved Version: TNET-DEC-H211-DA_2024V1.0...
-
Page 2: Fcc Statement
1G 4K60 AVoIP Decoder with Dante AV Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance. -
Page 3: Safety Precautions
1G 4K60 AVoIP Decoder with Dante AV SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ... -
Page 4: Table Of Contents
1G 4K60 AVoIP Decoder with Dante AV Table of Contents 1. Product Introduction ....................6 1.1 Key Features ..................... 6 1.2 Package List ...................... 7 1.3 Customer Service ....................7 2. Technical Specification ....................8 3. Panel Description ...................... 11 3.1 Front Panel ...................... - Page 5 1G 4K60 AVoIP Decoder with Dante AV 5.7.2 802.1x (Coming Soon) ................28 5.7.3 LDAP (Coming Soon) ................28 5.7.4 AES256 Encryption (Coming Soon) ............28 5.7.5 SSH (Coming Soon) ................28 5.8 Control ......................28 5.8.1 RS232 ....................28 5.8.2 IR ......................
-
Page 6: Product Introduction
1G 4K60 AVoIP Decoder with Dante AV 1. Product Introduction The T-Network Series represents a revolutionary line of AVoIP (Audio Video over IP) devices that redifine the user experience and enhance flexibility in audiovisual applications. Thoughtfully crafted in Scandinavia, this series features two encoder models and a single decoder model. -
Page 7: Package List
Note: Please contact your distributor immediately if any damage or defect in the components is found. 1.3 Customer Service TiGHT AV provide a limited warranty for the product within five years counting from date of purchase (The purchase invoice shall prevail). For more information see TiGHT AV general Warranty Statement at or just scan the QR-code below. -
Page 8: Technical Specification
1G 4K60 AVoIP Decoder with Dante AV 2. Technical Specification VIDEO HDMI 2.0b Digital Video Inputs Stream input via RJ45, Dante AV-A or TNET Video Stream Digital Video Output HDMI 2.0b Maximum resolution 4096x2160P 4:4:4 Scaling Up to 4096x2160P HDR10/HLG/HDR10+/Dolby Vision support HDCP Support HDCP 2.3/1.x Color Space support... - Page 9 1G 4K60 AVoIP Decoder with Dante AV Formats Dolby: Dolby AtmosTM, Dolby TrueHD, Dolby Digital PlusTM, Dolby Digital EX, Dolby Digital 5.1, Dolby Digital 2/0 Surround, Dolby Digital 2/0 DTS: DTS-HD Master AudioTM, DTS-HD, DTS-ES Discrete 6.1, DTS-ES Matrix 6.1, DTS Digital Surround 5.1 Analog Audio Format LPCM 2.0, 32kHz -192kH Dante Audio Format...
- Page 10 1G 4K60 AVoIP Decoder with Dante AV HDMI IN HDMI video input USB Devices 2x USB 1.1 Type-A and 2x USB 2.0 Type-A ports Power Optional Power Supply DC24V 1.25A power adapter or PoE++/PoE+ PoE+ (802.3at), PoE++ (802.3at) for PoE/PoE+ passthrough Max power 16.3W (no USB devices), 26.3W (max load USB devices) consumption...
-
Page 11: Panel Description
1G 4K60 AVoIP Decoder with Dante AV INDICATORS AND CONTROL Illuminates red when power off, POWER illuminates blue when power on. Illuminates green when there is a valid video signal; SIGNAL Illuminates yellow when streaming with no source image (No valid signal). -
Page 12: Rear Panel
1G 4K60 AVoIP Decoder with Dante AV default, the device name and IP address will be shown. If the user selects more than two pieces of information, the interface will present two rows at a time. ID Button: • When pressed: Turn on the display if configured to do so and if OSD is enabled show OSD information on top of video. - Page 13 1G 4K60 AVoIP Decoder with Dante AV LAN2: 1x RJ45 10/100/1000 Base-T, half/full duplex, auto-negotiation, VLAN • support, PoE/PoE+ passthrough. HDMI IN: 1x Local HDMI 2.0b input, 4K@60Hz 4:4:4, 18Gbps, HDCP 2.3/1.x, HDR10/HLG/HDR10+/Dolby Vision support. HDMI Out: 1x HDMI 2.0b output, 4K@60Hz 4:4:4, 18Gbps, HDCP 2.3/1.x, HDR10/HLG/HDR10+/Dolby Vision support.
-
Page 14: System Connection
1G 4K60 AVoIP Decoder with Dante AV System Connection 4.1 Usage Precaution • Ensure that all components and accessories are included prior to installation. • The installation should take place in a clean environment with appropriate temperature and humidity levels. Verify that all power switches, plugs, sockets, and power cords are properly •... -
Page 15: Operation Of Web-Ui
1G 4K60 AVoIP Decoder with Dante AV 5. Operation of Web-UI TNET series can be configurated and controlled via a web-based GUI. To access it, open a web browser and enter the unit's IP address. TNET devices are set to use DHCP by default, and the IP address can be located in the information displayed on the OLED screen. -
Page 16: Start Tab
1G 4K60 AVoIP Decoder with Dante AV 5.1 Start Tab This tab shows the unit information and settings for video, audio and Dante/AES67. 5.1.1 Information Lists the unit essential information including device name, model name, IP • address, MAC address, host name, unique serial number and firmware version. 5.1.2 Video Input Input sources signal status, HDCP status and version, resolution and color space •... -
Page 17: Video Output
1G 4K60 AVoIP Decoder with Dante AV Note: If you encounter poor performance in ULL mode, it is advisable to switch to Normal mode. This issue may be related to network conditions, as ULL mode demands a high-performance network, and using Normal mode could offer a remedy. 5.1.4 Video Output Output Selection: Stream, HDMI, No Stream Image. -
Page 18: Audio Settings
1G 4K60 AVoIP Decoder with Dante AV 5.1.5 Audio Settings HDMI Audio • Source Select: HDMI Output embedded audio source AFV/TNET Stream Audio/Dante/AES67 Stream Audio/Local HDMI. HDMI Audio Mute: Mutes HDMI output embedded audio. Analog Audio • Audio Direction: Analog audio direction setting, input or output selection. Signal Select: Balanced or unbalanced audio type selection. -
Page 19: Aes67
1G 4K60 AVoIP Decoder with Dante AV 5.1.6 AES67 • When enabling AES67 function, the unit must be rebooted for the changes to take effect. The unit will automatically restart upon confirming the settings. Note: Enabling AES67 will disable Dante functionality. 5.1.7 Dante Dante AV-A mode requires Audinate software’s for stream management, such as •... -
Page 20: Edid/Hdcp
1G 4K60 AVoIP Decoder with Dante AV • Supports Dante Audio RX subscription information query. • Supports Dante lock information query. Note: Enabling Dante will disable AES67 functionality. 5.2 EDID/HDCP 5.2.1 EDID • Configure EDID for Local HDMI and Decoder. Supports EDID Copy from HDMI output, Predefined EDID or User Defined EDID. -
Page 21: Hdcp
1G 4K60 AVoIP Decoder with Dante AV 5.2.2 HDCP Enable or disable Local HDMI input HDCP compatibility. This feature is particularly • beneficial for scenarios and applications involving Apple devices, where streaming content over the internet or recording is required. 5.3 Device 5.3.1 OLED Display •... -
Page 22: Power On Image
1G 4K60 AVoIP Decoder with Dante AV 5.3.2 Power On Image During power on sequence a user-defined image can be shown om display. Supports png and jpg formats. • Enable or disable Power On image. • Supports duration time setting: 15 – 300s. •... -
Page 23: Osd
1G 4K60 AVoIP Decoder with Dante AV 5.3.4 OSD The decoder is equipped with an On Screen Display (OSD) that offers customizable options. The OSD activates when the ID button on the front panel is pressed, WEB-UI control, or upon receiving an API command or can be set to always on. •... -
Page 24: File
1G 4K60 AVoIP Decoder with Dante AV 5.3.5 File Manage T-NET firmware and configuration files, as well as perform factory resets and reboot. Firmware Update: • Browse firmware file on your PC and press “Update”. T-NET devices uses one combined file for MCU and AST upgrades. A popup will show after pressing “Update”... -
Page 25: Date And Time
1G 4K60 AVoIP Decoder with Dante AV 5.3.7 Date and Time Unit date and time settings, if no NTP is used the unit will show the run time since latest system power on. • NTP Setting: Supports primary and secondary NTP server configuration. •... -
Page 26: Enc Green List
1G 4K60 AVoIP Decoder with Dante AV 5.4.1 ENC Green List The ENC Green List enhances security for USB routing by restricting connections from decoders' USB devices to only those encoders that have been authorized. Whenever an encoder that is not in the ENC Green List tries to connect it will be rejected. •... -
Page 27: Network
1G 4K60 AVoIP Decoder with Dante AV 5.6 Network 5.6.1 Network Configuration Device network configuration/information LAN1: • Network parameters Static or DHCP IP addressing IP Address Subnet Mask DNS 1 and DNS 2 Hostname: The unit allows for a customizable hostname for network identification, adhering to DNS naming conventions. -
Page 28: Security
1G 4K60 AVoIP Decoder with Dante AV Services Settings (Coming Soon) • 5.7 Security 5.7.1 Security Configuration (Coming Soon) Coming Soon 5.7.2 802.1x (Coming Soon) Coming Soon 5.7.3 LDAP (Coming Soon) Coming Soon 5.7.4 AES256 Encryption (Coming Soon) Coming Soon 5.7.5 SSH (Coming Soon) Coming Soon 5.8 Control... - Page 29 1G 4K60 AVoIP Decoder with Dante AV RS232 routing. Press Disconnect to disable the current passthrough routing. • Enabling passthrough is necessary for the unit to appear in the RS232 routing section of the T-COMM software. Note: Unit RS232 settings in section 5.6.1 are not applied in passthrough mode. •...
- Page 30 1G 4K60 AVoIP Decoder with Dante AV • T-Net units support IR reading from a remote control. To enable IR reading, connect the IR receiver to the IR IN port and direct the remote control towards it. The command will be displayed in the field for convenient copying. Up to 40 IR commands can be stored locally in a T-NET unit with custom naming.
-
Page 31: Trigger Commands
1G 4K60 AVoIP Decoder with Dante AV each activation. Repeat Delay: Determines the delay between repeated commands. Supports export and import of IR configuration file for easy commissioning in larger systems or for documentation purposes. 5.8.3 Trigger Commands Trigger commands are stored commands that can be triggered based on events in T- NET devices. -
Page 32: Log
1G 4K60 AVoIP Decoder with Dante AV 5.9 Log Units will maintain a command log that records all commands for reference and troubleshooting purposes. Additionally, they include a Debug Log that is beneficial for more in-depth troubleshooting at the manufacturer, dealer, or distributor level. Reset Log: Clears the Command Log. -
Page 33: Drawings And Dimensions
1G 4K60 AVoIP Decoder with Dante AV 8. Drawings and Dimensions 9. Environment and recycling information 9.1 Disposal of electric and electronic devices EC Directive 2012/19/EU This product is not to be treated as regular household waste but must be returned to a collection point for recycling electric and electronic devices. -
Page 34: Packaging Recycling Information
1G 4K60 AVoIP Decoder with Dante AV 9.2 Packaging recycling information Note: This manual is recycled as paper (mixed paper and card).
