MANDAI DESIGN Ceres Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Ceres
Assembly Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ceres and is the answer not in the manual?

Questions and answers

Related Manuals for MANDAI DESIGN Ceres

Summary of Contents for MANDAI DESIGN Ceres

  • Page 1 Ceres Assembly Instructions...
  • Page 2 Assembly video View our instructional video for assembly. You can scan the QR code below or visit our YouTube channel: https://youtube.com/@mandaidesign Use your smartphone camera to scan the QR code or visit our website directly at: www.mandai-design.com/pages/assembly-instructions CE.SEP.2024.01.EN...

  • Page 3: Modular Assembly

    Modular assembly Ceres is a versatile modular shelving system that offers our customers unlimited design possibilities. These assembly instructions cover the fundamental steps to assemble the wall uprights, along with all available components. Please note that the configuration you ordered may not include all the components shown here.

  • Page 4: Safety Tips

    Proper installation of the wall connection is crucial for ensuring the stability and safety of the shelf setup. Make sure the shelf is assembled on a level surface. The Ceres shelving system must be wall-mounted and cannot be used as a standalone unit. Any questions? Please don’t hesitate to contact us by phone...

  • Page 5: Plan Ahead

    Plan ahead Unpack all items and organize them to get a clear overview. Verify your measurements on-site and mark the position of the shelf using tape. Place an underlay beneath the shelf for protection. When planning the placement of your shelving system, consider nearby doorways and walkways. Ensure sufficient space is allocated for movement and functionality.

  • Page 6: Load Capacity

    Load capacity Depending on the intended use, we recommend the use of shelf support profiles. These ensure a consistent appearance, even when the shelves carry varying loads. For loads ranging from between 15 kg and up to a maximum of 30 kg per shelf, support profiles must always be used. Ensure that the total weight supported between two wall uprights does not exceed 200 kg.
  • Page 7 Accessories For your added convenience, we include additional screws with each order. You will find these indicated in the drawings with the corresponding number. The wall mounting anchor is suitable for both solid and drywall. Please note: The leveling adjustable foot is pre-assembled and attached to the upright frame. The AW20 screw bit is used both for wall mounting, display/chalk board and wooden components.
  • Page 8 Wall upright alignment 1. First, mark the beginning and end of the shelf on the wall. 2. Set up the first wall upright. If the floor is uneven, begin on the higher side. Ensure the adjustable foot is in its initial position to allow for height adjustments on the subsequent uprights. 3.
  • Page 9 Wall upright mounting 1. Properly insert the anchors into the drilled holes in the wall. 2. Attach the wall adapter with the appropriate screws to the inserted anchors, followed by attaching the wall upright into the wall adapter. Tighten the hex screw from above and below for the upper and lower attachment to the wall adapter.
  • Page 10 Wall upright extension 1. Repeat the steps for alignment and installation of the wall uprights as described before. 2. Adjust the leveling feet until they make contact with the floor. Ensure that the wall uprights are perfectly vertical, positioned at a uniform height, and have the correct horizontal spacing between them.
  • Page 11 Presentation box 1. Position the two brackets at the same height. 2. Place the presentation box on the brackets, ensuring the front edge is flush. Secure it from below with screws. 3. Position the glass shelf supports at the desired height. 4.
  • Page 12 Shelf board + Angled shelf board Shelf board: Screw the brackets to the underside of the shelf. The brackets must be flush with the front edge of the shelf. back flush front Note: Use only the outer holes in the bracket. The middle hole is reserved for the optional support profile.
  • Page 13 Display board, Chalk board, Pedestal + Storage box Display board / Chalk board: Screw the adapters to the back of the board according to the dimensions specified below. 200mm 86mm Pedestal + Storage box: After placing the storage box and the pedestal into the shelving system, adjust the furniture feet underneath until the optimal position is reached.
  • Page 14 Display board, Chalk board, + Display fittings 1-4. Hang the specific components on the wall upright. When using glass shelves, ensure that rubber suction cups are inserted into the holes of the brackets beforehand. 6. Position the front arm on the back bar. 1.
  • Page 15 Floating storage box Screw a retaining plate onto the lower spacer of the relevant wall upright through 3 fixing holes. Note: Depending on the position of the storage box in the shelf configuration, two versions of retaining plates are used. The one with 3 fixing holes on one side is used for the outer left or right position.
  • Page 16 Contact Mandai GmbH Straße der Deutschen Einheit 4b 04643 Geithain +49 (0) 34341 40 70 950 info@mandai-design.com www.mandai-design.com Social Media: www.facebook.com/mandaidesignde www.instagram.com/mandai_design_de www.pinterest.de/mandaidesign www.youtube.com/@mandaidesign © Mandai GmbH 09/2024...
