MANDAI DESIGN Cetus Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

Cetus
Assembly Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cetus and is the answer not in the manual?

Questions and answers

Related Manuals for MANDAI DESIGN Cetus

Summary of Contents for MANDAI DESIGN Cetus

  • Page 1 Cetus Assembly Instructions...
  • Page 2 Assembly video View our instructional video for assembly. You can scan the QR code below or visit our YouTube channel: https://youtube.com/@mandaidesign Use your smartphone camera to scan the QR code or visit our website directly at: www.mandai-design.com/pages/assembly-instructions CT.DEC.2024.01.EN...

  • Page 3: Modular Assembly

    Modular assembly Cetus is a versatile modular shelving system that offers our customers unlimited design possibilities. These assembly instructions cover the fundamental steps to assemble the wall uprights, along with all available components. Please note that the configuration you ordered may not include all the components shown here.

  • Page 4: Safety Tips

    Proper installation of the wall connection is crucial for ensuring the stability and safety of the shelf setup. Make sure the shelf is assembled on a level surface. The Cetus shelving system must be wall-mounted and cannot be used as a free-standing unit. Any questions? Please don’t hesitate to contact us by phone...

  • Page 5: Plan Ahead

    Plan ahead Unpack all items and organize them to get a clear overview. Verify your measurements on-site and mark the position of the shelf using tape. Place an underlay beneath the shelf for protection. When planning the placement of your shelving system, consider nearby doorways and walkways. Ensure sufficient space is allocated for movement and functionality.

  • Page 6: Load Capacity

    Load capacity Depending on the intended use, we recommend the use of Shelf supports. These ensure a consistent appearance, even when the shelves carry varying loads. For loads per shelf ranging from between 15 kg and up to a maximum of 30 kg, Shelf support must always be used. For assembly details please refer to page number 13.
  • Page 7 Accessories For your added convenience, we include additional screws with each order. You will find these indicated in the drawings with the corresponding number. The wall mounting anchor is suitable for both solid and drywall. Please note: The leveling adjustable foot is pre-assembled and attached to the upright frame. The AW20 screw bit is used both for wall mounting, display board and wooden components.
  • Page 8 Wall upright alignment 1. First, mark the beginning and end of the shelf on the wall. 2. Set up the first wall upright. If the floor is uneven, begin on the higher side. Ensure the adjustable foot is in its initial position to allow for height adjustments on the subsequent uprights. 3.
  • Page 9 Wall upright mounting 1. Properly insert the anchors into the drilled holes in the wall. 2. Attach the wall adapter with the appropriate screws to the inserted anchors, followed by attaching the wall upright into the wall adapter. Tighten the hex screw from above and below for the upper and lower attachment to the wall adapter.
  • Page 10 Wall upright extension 1. Repeat the steps for alignment and installation of the wall uprights as described before. 2. Adjust the leveling feet until they make contact with the floor. Ensure that the wall uprights are perfectly vertical, positioned at a uniform height, and have the correct horizontal spacing between them.
  • Page 11 Presentation box 1. Position the two brackets at the same height. 2. Place the presentation box on the brackets ensuring the front edge is flush. Secure it from below with screws. 3. Position the glass shelf supports at the desired height. 4.
  • Page 12 Display board+ Angled shelf board Display board: Screw the adapters to the back of the board according to premarked position of screw holes specified below. Angled shelf board: Screw the brackets to the underside of the shelf. The brackets must be flush with the front edge of the shelf. back flush front...
  • Page 13 Shelf board Shelf Support: Secure it to the underside of the bracket prior to mounting the shelf board, using the central hole for attachment. Note: This component is required for shelf loads ranging from 15 kg to a maximum of 30 kg. Otherwise, its use is optional and primarily intended to maintain a uniform appearance, even when shelves support different loads.
  • Page 14 Display board + Display fittings 1 - 5. Hang the specific components on the wall upright. When using glass shelves, ensure that rubber suction cups are inserted into the holes of the brackets beforehand. 6. Position the front arm on the back bar. Note: Detailed views show a perspective from behind.
  • Page 15 Pedestal, Storage box + Organisation box Put 1 - 3 in position on the floor inbetween the wall uprights and adjust the furniture feet until the optimal position is reached. Ideally, this is when the lower edge of the storage box is level with the wall upright.
  • Page 16 Contact Mandai GmbH Straße der Deutschen Einheit 4b 04643 Geithain +49 (0) 34341 40 70 950 info@mandai-design.com www.mandai-design.com Social Media: www.facebook.com/mandaidesignde www.instagram.com/mandai_design_de www.pinterest.de/mandaidesign www.youtube.com/@mandaidesign © Mandai GmbH 12/2024...
