Tyco FireClass FC700 Series Fixing Instructions

FIRECLASS Fire detection system
PLX800 FireClass FC700 Series Loop Expansion Card
Part No. 557.202.842
1
2
4
Fig. 1: FireClass FC700 Series PLX800 loop expansion
slot card
1 – Loop A, B,C,D connector plugs
2 – Loop optical indicators
3 – Slot card optical indicators
4 – Reset button
5 – DIP switch
Introduction
The PLX800 slot card is used to connect addi-
tional loops to a FireClass FC700 Series panel.
When you configure the panel, you can config-
ure the loop pair A,B typically as a single loop A,
Fixing instructions Doc. version 1.0
PLX800
AL+
AL-
AR+
AR-
BL+
BL-
BR+
BR-
CL+
CL-
CR+
CR-
DL+
DL-
DR+
DR-
A Alarm
A Fault
B Alarm
B Fault
C Alarm
C Fault
D Alarm
D Fault
Status
3
Fault
Reset
1 D
5
XT1 LP A
XT2 LP B
XT3 LP C
XT4 LP D
LED10 HW VER
A AL
3 2 1 0
LED9
J1 BOOT
A FL
LED8
B AL
LED7
B FL
LED6
C AL
LED5
XP4 CPLD JTAG
C FL
LED4
D AL
LED3
D FL
LED2
STAT
LED1
FAULT
RT1 4OV ADJ
SW2
RST
Fig. 2: PLX800 terminals and jumpers
1 – J1 - Boot mode jumper
2 – XP2 - Debug port
and the loop pair C,D typically as a single loop C.
The PLX800 is suitable for use with the FC700
Series panels.
Cabling requirements
 Select all cables in accordance with local
standards.

Use cables with a maximum cross section of
2
2.5 mm .
PLX800 ASSY 125.685.114
PROFILE LOOP EXPANSION MODULE
1
XP2 DBG
TX 11
2
RX
GND
21
31
FU2
FU1
PLX800
XP1 INT NBUS
1 2
49 50
1/4
