Nobels ODR-mini 2 Owner's Manual

ODR -mini
2
Natural OVERDRIVE
Owners Manual
English
Specifications
Power (DC):
9V~18V filtered & stabilised power supply
Power connector: 2.1 mm / negative center
Consumption: max. 12 mA
Input impedance: ca. 1 MΩ
Output impedance: ca. 2.2 kΩ
Max. input level: +6 dB
Controls:
Drive, Spectrum, Level, Bass Cut, („GitD" knobs)
Jacks: DC, Input 1/4" (6.3 mm), Output 1/4" (6.3 mm)
LED Indicator: 1x green LED: (On/Off)
Mounty-P:
4x integrated fold-out Mounting Plates
Dimensions (cm): 9.4 (L) / 4.8 (W) / 5.0 (H) unit
Weight (gr.): 215
Specifications are subject to change without notice!
* This pedal is optimized for 9V DC. Operation with power supply units of up to 18V
DC is possible. Sound results then will vary slightly.
** Hum will occur when using unstabilized power supplies!
Power supply specifications can be found on the bottom of the device.
Waste Electrical and Electronic Equipment labeling:
In the European Union, do not discard this product as unsorted municipal waste. Contact
your local authorities or send it back to the Nobels dealer or distributor.
More information:
www.nobels.com
20240819MSA
NOBELS_ODR_mini 2_OMAN_ENGLISH_GERMAN_2024-08-20_ CMYK.indd 1 NOBELS_ODR_mini 2_OMAN_ENGLISH_GERMAN_2024-08-20_ CMYK.indd 1
Welcome to the Nobels family! Thank you for choosing the new Nobels ODR-mini 2! The ODR-mini 2
is the smaller brother of the legendary ODR-1 overdrive. It delivers the same natural distortion and unique
sound that many studio guitarists around the world love and appreciate. It has a true bypass circuit, the
SPECTRUM control with a centre detent, a practical bass cut control and the fluorescent pointers of the
„GitD" (Glow in the Dark) knobs.
We hope you enjoy this pedal!
DRIVE Control:
With this control you can set
sounds from slight blues to
TM
full overdrive.
OUT Jack:
This output delivers a low
impedance output signal
best for the input of your
amplifier.
SPECTRUM Control:
This control changes the
amount of deep-mid and
treble frequencies at the
same time. Keeping the
mids almost untouched.
Turning left gives you the
warm mid-tones for a great
blues and rock sounds.
Turning the SPECTRUM
knob clockwise creates
harder sounds - ideal
for hardrock. In the 12
o'clock position (click), the
frequencies remain almost
untouched.
(optional)* **
DC Jack:
Jack for a regulated power supply unit.
Mounty-P:
4x fold-out mounting plates
Important notes
Avoid using this unit in extreme humidity, heat or dusty environment.
A filtered & stabilised power supply unit must be connected to the DC
socket for operation (DC 9V~18V / inside: minus).
Sound examples
1. SIMPLE BOOST
2. BLUESY TONE
3. WARM SOLO
4. ROCK RHYTHM
5. 70's DRIVE
Bass cut setting according to guitar and pickup type and taste
LEVEL Control:
Adjusts the volume.
BASS CUT Control:
Here you can cut the low frequencies
that can sometimes muddy up your
tone. When turned to the left, the full
pickup signal is allowed to pass. As
you turn it to the right, the lower bass
frequencies are attenuated.
IN Jack:
Inserting a plug activates the unit.
(Do not use a stereo cable!)
LED:
This LED shows the state of the
effect. LED on = Effect on.
Switch:
Switches the unit on/off
„TRUE BYPASS"
DRIVE SPECTRUM LEVEL
