COBRA GARDEN TRACTOR

OWNER'S MANUAL

MODEL: LTX92HR2L (T92H)

LTX102HR2L (T102H)

WARNING!

When using the machine the safety rules must be followed. For your own safety and bystanders please read these instructions before

operating the machine. Please keep the instructions safe for later use.

Cobra Garden Machinery

Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK

Revised November 2024

www.cobragarden.co.uk

Table of Contents

Need help?

Do you have a question about the LTX92HR2L and is the answer not in the manual?

Questions and answers

Summary of Contents for Cobra LTX92HR2L

Page 1 COBRA GARDEN TRACTOR OWNER’S MANUAL MODEL: LTX92HR2L (T92H) LTX102HR2L (T102H) WARNING! When using the machine the safety rules must be followed. For your own safety and bystanders please read these instructions before operating the machine. Please keep the instructions safe for later use.
Page 2 IMPORTANT The lawnmower must always be used with utmost caution. So that safety precautions and operating instructions are always readily on hand, labels have been affixed to the machine showing pictographs illustrating the main operating precautions. The labels, according to applicable safety standards, are considered an integral part of the machine, the user is therefore responsible for replacing them in the event they become detached or illegible.
Page 3: General Safety Regulations
1. SAFETY 1.1 HOW TO READ THE MANUAL Some paragraphs in the manual containing important information regarding safety and operation are emphasised in the following ways. NOTE IMPORTANT These give details or further information on what has already been said, in the aim to prevent damage to the machine. Non-observance will result in the risk of injury to oneself or others Non-observance will result in the risk of serious injury or death to oneself or others Positions refer such as “front”, “back”, “left”...
Page 4: Operation
B) PREPARATION While mowing, always wear sturdy footwear and long trousers. Do not operate the equipment barefoot or wearing open sandals. Thoroughly inspect the area where the equipment is to be used and remove all objects which can be ejected from the machine, such as twigs, branches, stones, and other debris. DANGER! Petrol is highly flammable: –...
Page 5: Maintenance And Storage
Before leaving the driving seat: - disengage the blades and lower the attachments; – go into neutral and apply the parking brake; – stop the engine and remove the ignition key. Disengage the blades, stop the engine and remove the ignition key: –...
Page 6 Fig1...
Page 7 Fig 2...
Page 8 Fig 2 Item 21 Fixing Kit...
Page 9 Fig 3 Fig 4...
Page 10 Fig 5 Fig 6...
Page 11 Fig 7 Fig 8...
Page 12 Fig 9 Fig 10...
Page 13 Fig 11 Fig 12...
Page 14 Fig 13...
Page 15 Fig 14 Fig 15...
Page 16 Fig 16 Fig 17...
Page 17 Fig 18 Fig 19 Fig 20...
Page 18 Fig 21...
Page 19: Specifications
Specifications LTX92HR2L LTX102HR2L MODEL T92H-L5 T102H-L5 Engine LC2P73F LC2P73F Power 12.5kW 12.5kW Displacement 586cc 586cc Power Engine speed 2800rpm 2800rpm Fuel tank capacity 8.5L 8.5L Battery capacity DC12V/18Ah DC12V/18Ah Minimum turning 45cm 45cm radius Cutting width 927mm 1024mm Reverse mowing...
Page 20: Identification Of Components
2. IDENTIFICATION OF COMPONENTS The main components of the machine as following: 3.1 UNPACKING (see Fig 1) When unpacking the machine, take care to gather all individual parts and fittings, and do not damage the 1. Bumper cutting deck when taking the machine off the pallet. 2.
Page 21 3.3 FITTING THE SEAT (see fig 4) 3.10 FITTING ALARM SWITCH PRESSURE - Use the Bolt(1) and Nut(2) to fix the seat on the PLATE (see Fig 11) machine.(Use the hex wrench in accessories tools) - Fit the Plate(1) on the Rear plate by 1 bolt(3). 3.4 ASSEMBLING THE GRASS CATCHER 3.11 FITTING ANTISCALP WHEELS (see Fig 12) (see Fig 5)
Page 22: Controls And Instruments
4.5 Brake Pedal (Fig. 13.5) 4.CONTROLS AND INSTRUMENTS The brake pedal is located on the left front side of the board. The brake pedal can be used for sudden stops or 4.1 THROTTLE LEVER (Fig. 13.1) setting the parking brake. This regulates the engine revs, The positions are NOTE: When the machine is moving, keep your foot off indicated on a label showing the following symbols:...
Page 23 - Adjust the cutting height and speed considering the conditions of the lawn (the height, density and 4.15 CLEANING THE TRACTOR dampness of the grass). To maintain collection in After each mowing session, clean the outside of the thicker or longer grass moderate speed and only machine, empty the grass catcher and shake it to remove cut a third of the grass length.
Page 24 4.16 STORAGE AND INACTIVITY FOR LONG IMPORTANT Drive down slopes with your foot off the PERIODS drive pedal to use the braking effect of the hydraulic If you intend not to use the machine for a long transmission when the transmission is not engaged. period (more than 1 month), disconnect the battery cables and follow the instructions in the engine instruction manual.
Page 25: Maintenance
5. MAINTENANCE 5.1 SAFETY RECOMMENDATIONS 1) See the engine manual for the full list and - Before cleaning or doing maintenance work, frequency. take out the ignition key and read the relevant 2) At the first signs of any malfunction, contact instructions.
Page 26 5.3 MAINTENANCE- REPLACEMENTS 5.2.3 REPLACING THE WHEELS (FIG16 17) Stop the machine on flat ground and put a block under a load-bearing part of the frame on the side that the wheel is to be changed. The wheels are held by a snap ring which can be eased off with a screwdriver.
Page 27 6. TROUBLESHOOTING AND FAULT CODE Problem Possible cause(s) Remedy Electronic circuit board blocked Turn the ignition key to «STOP» position and due to: look for the cause of the problem: – flat battery – recharge the battery With the key on –...
Page 28 Problem Possible cause(s) Remedy – the height of cut lever is lowered too – lower the deck slowly The engine switches off quickly. -in long lush grass set the cutting height – you are not ready to engage the cutting when the cutting higher –...
Page 29 7. DISPLAY CONTENT AND FAULT CODE (Where fitted) 7.1 DISPLAY ITEM IMAGE CONTENT Cobra logo DRIVE selected Parking brake engaged REVERSE selected. Running time and fault code.(see the fault code content sheet) Charging or low power indicator Battery capacity indicator...
Page 30 Fault detected Tractors lights are on Operator present on the seat Grass bag collector is lifted up Cutting blades are engaged Indicates reverse mowing is operating Grass bag full indicator...
Page 31: Fault Codes
7.2 SWITCH LOGIC AND POSITIONS ITEM Switch position NO Switch Name Switch attribute Gear switch Neutral: Disconnect Forward/backward: Close Reverse Backward: disconnect switch Neutral/Forward: Closed K9 / K11 Seat switch Person on seat: disconnect Vacancy: closed Grass bag Grass bag fitted: disconnect switch No grass bag: closed Parking switch...
Page 32: Warranty
If your dealer did not collect registration information from you, please take a few minutes and register your purchase with Cobra. You can register by completing and mailing the registration card that should be in the box or by going online to: www.cobragarden.co.uk...
Page 33: Ec Declaration Of Conformity
In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity Product Ride-on lawnmower for mowing garden lawns Machine Type: LTX92HR2L (T92H) LTX102HR2L (T102H) Rated power 12.5kW at 2,600 min Measured sound power level: 98.9 dB(A) K...
