EINHELL GC-GP 6050 ECO PLUS Operating Instructions Manual page 13

pervised, children are not allo-
wed to clean the equipment and
carry out user-level maintenance
work.
2. Layout and items supplied
2.1 Layout
1. Filling level indicator
2. Suction connection
3. Water fi ller screw
4. Pressure connection
5. Carry handle
6. Power switch
7. Water drain screw
8. Connection adapter approx. 33.3 mm
(R1 male thread)
2.2 Items supplied
Please check that the article is complete as
specifi ed in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
•
Open the packaging and take out the equip-
ment with care.
•
Remove the packaging material and any
packaging and/or transportation braces (if
available).
•
Check to see if all items are supplied.
•
Inspect the equipment and accessories for
transport damage.
•
If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suff ocating!
•
Garden pump
•
Connection adapter approx. 33.3 mm
(R1 male thread)
•
Original operating instructions
Anl_GC_GP_6050_ECO_Plus_SPK13.indb 13 Anl_GC_GP_6050_ECO_Plus_SPK13.indb 13
GB
3. Proper use
Applications:
•
Irrigation and watering of green areas, vege-
table beds and gardens.
•
Operation of lawn sprinklers.
•
Drawing of water (with pre-filter) from ponds,
streams, rain barrels, rainwater cisterns and
wells.
•
For supplying service water
Transport media:
•
For the pumping of clear water (fresh water),
rainwater or light suds/service water.
•
The maximum temperature of the fluid must
not exceed +35°C if the equipment is opera-
ted permanently.
•
Do not use the equipment to pump inflamma-
ble, gassing or explosive fluids.
•
The pumping of aggressive liquids (acids, al-
kalis, silo seepage etc.) as well as liquids with
abrasive substances (sand) must likewise be
avoided.
•
This equipment is not designed to pump drin-
king water.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Please note that our equipment has not been de-
signed for use in commercial, trade or industrial
applications. Our warranty will be voided if the
machine is used in commercial, trade or industrial
businesses or for equivalent purposes.
4. Technical data
Mains connection ................... 230-240 V ~ 50 Hz
Power consumption .................................. 600 W
Max. pumping rate ..................................5000 l/h
Delivery head max. ..................................... 40 m
Delivery pressure max. ..............0.40 MPa (4 bar)
Suction height max. ....................................... 8 m
Pressure connection ..... approx. 33.3 mm (R1IG)
Suction connection ... approx. 42 mm (R1 ¼ AG)
Water temperature max. ............................. 35°C
Sound power level .......................... 75.75 dB (A)
Uncertainty .............................................. 1.55 dB
- 13 -
07.10.2024 09:29:08 07.10.2024 09:29:08
