Summary of Contents for Response QV3882
- Page 1 4K Dash Camera with GPS QV3882 Instruction Manual...
-
Page 2: Table Of Contents
CONTENTS Before First Use .................. 2 Safety ....................3 Box Contents ..................3 Product Diagram ................. 4 In Vehicle Installation ................8 Functions ..................... 9 Troubleshooting ................. 12 Specifications ..................15 Warranty Information ................. 16 BEFORE FIRST USE • Prior to using your product, please read all the safety and operating instructions thoroughly. -
Page 3: Safety
• Do not dispose of in fire. Check with local authorities on the disposal of lithium battery products BOX CONTENTS 1 x Dash Camera 4K Dash Camera with GPS QV3882 Instruction Manual 1x 12v Power Adapter 1 x User Manual... -
Page 4: Product Diagram
PRODUCT DIAGRAM Feature Description 3M Adhesive Adhesive mount to attach to windscreen Mount Rear Camera Port AV Port for rear camera - Not Available Power Interface USB-C Port for power supply Monitor 3" HD IPS Display Lens Align towards windscreen Speaker For audio Playback Micro SD Slot... - Page 5 Feature Description Menu Button Function 1: Menu Functions In the power-on state, short press the [M button] to enter the menu function setting table, the Function 2: ADAS Setting Function In the AI interface, short press [M button] to enter ADAS menu setting •...
- Page 6 Power button Function 1: Switching function In the off state, long press [Power button] can turn on the power of the machine, the machine automatically start to work. Long press [Power Button] and hold it for 3 seconds in power-on state, the unit will automatically save the video file and user settings and shut down.
- Page 7 Menu button Function 1: Menu Functions In the power-on state, short press the [M button] to enter the menu function setting table, the Function 2: ADAS Setting Function In the AI interface, short press [M button] to enter ADAS menu setting •...
-
Page 8: In Vehicle Installation
IN VEHICLE INSTALLATION 1. Insert MicroSD Card Insert a suitable MicroSD card (Class 10) in to the dash camera, taking care that the gold contacts are facing towards the LCD screen side. Push the memory card until it clicks into place. NOTE: Use the edge of a small object to push the memory card in place if required.Take care that card has ‘clicked’... -
Page 9: Functions
FUNCTIONS Video Insert the TF card to access the external power on, the machine will automatically record, the video indicator light will flash, the screen recording status will show red font, from 00:00:00, press [Confirm] to stop recording. Video Playback In the power-on state, short press the [Power off button] to enter the video playback mode. - Page 10 Power charging The charging icon is displayed on the top right of the screen when plugged into an external power source, indicating that the battery is being charged, and the charging icon will keep flashing while the machine is in operation. Timer Screen Off Can automatically turn off the display, so that the product works at very low power consumption;...
- Page 11 Keypad Setting machine key tones On/ off sound Language Machine default language can be set English/Traditional Settings Chinese/Simplified Chinese/Japanese/ Portuguese/Russian/ Italian/French/German/ Spanish Light source Default is 50HZ 50HZ/ 60HZ frequency Formatting Formatting the TF card Confirmation/ Cancellation Default Restore system default settings Confirmation/ setting Cancellation...
-
Page 12: Troubleshooting
TROUBLESHOOTING Problem Solution Storage Unable to take Check if the Micro SD card has sufficient space and is locked. photos or videos When recording, it Due to the huge amount of high-definition video data, please will automatically use a high-speed Micro SD card compatible with SDHC. It is stop recommended to use a Class10 or higher high-speed card;... - Page 13 Problem Solution Power My dash camera Either the battery has gone flat, there is no power to the dash shuts down by itself camera and the Auto Power Off period has been triggered or after a while Parking Mode has been turned on and no vehicle movement has been detected for 5 minutes.
- Page 14 Problem Solution Other I have turned on The dash camera will start a recording whenever motion is ‘Parking Mode’ and detected. To turn off Parking Mode firstly shutdown the dash now can’t stop the camera recording and remove the SD card, this will avoid recording being activated accidentally.
-
Page 15: Specifications
SPECIFICATIONS 140° Video Resolution 3840 x 2160 @ 30FPS 2160 x 1440 @ 30FPS 1920 x 1080 @ 30FPS Channels G-Sensor True True – Speed and Location Storage Micro SD 128GB Max Screen 3.0” IPS Connection USB Type-C Battery Super Capacitor Dimensions 90 (W) x 54 (H) x 35mm (D) Weight... -
Page 16: Warranty Information
WARRANTY INFORMATION Our product is guaranteed to be free from manufacturing defects for a period of 12 Months. If your product becomes defective during this period, Electus Distribution will repair, replace, or refund where a product is faulty; or not fit for intended purpose. This warranty will not cover modified product;...
