Snow removal & rapid defrost (Fn 6)
Mode setting method
Master unit PCB DIP switch on : No.5
Select the mode using '▶', '◀' Button :
"Func" Push the '●' button
Select the Function using '▶', '◀' Button :
"Fn6" Push the '●' button
Select the Option using '▶', '◀' Button :
"oFF","oP1" ~ "oP3" Push the '●' button
Mode is set
Mode setting
setting
oFF
oP1
oP2
oP3 Snow removal mode. + Rapid defrost mode.
CAUTION
!
• Ask an authorized technician to setting a function.
• If do not use a function, set an off-mode.

Target pressure adjusting (Fn 8)

Mode setting method
Master unit PCB DIP switch on : No.5
Select the mode using '▶', '◀' Button :
"Func" Push the '●' button
Select the Function using '▶', '◀' Button :
"Fn8" Push the '●' button
Select the Option using '▶', '◀' Button :
"hEAt" , "cooL" Push the '●' button
Select the Option using '▶', '◀' Button :
"oFF","oP1" ~ "oP7" Push the '●' button
Target pressure is set
Setting
Mode Low Pressure (kPa)
oFF 804
oP1 699
oP2 739
oP3 843
oP4 908
oP5 961
oP6 1026
oP7 778
CAUTION
!
• Ask an authorized technician to setting a function.
• If do not use a function, set an off-mode.
• Change a power consumption or capacity.
Mode
Not setting
Snow removal mode
Rapid defrost mode
High Pressure (kPa)
2990
3121
2827
2696
2565
2435
2304
2990

Base Pan Heater setting

Mode setting method
Master unit PCB DIP switch on : No.5
Select the mode using '▶', '◀' Button :
"Func" Push the '●' button
Select the Function using '▶', '◀' Button :
"Fn23" Push the '●' button
Select the Option using '▶', '◀' Button :
"oFF","oP1","oP2" Push the '●' button
Base Pan Heater operation mode is set
CAUTION
!
• Ask an authorized technician to setting a function.
• If do not use a function, set an off-mode.
