Pressalit TMA 3 Operation And Maintenance Manual

Arm support
Hide thumbs Also See for TMA 3:

Advertisement

Quick Links

Download this manual
R1192
R1193
R1194
R1195
TMA 3
Arm support
en
– Operation and maintenance manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the TMA 3 and is the answer not in the manual?

Questions and answers

Related Manuals for Pressalit TMA 3

Summary of Contents for Pressalit TMA 3

  • Page 1 R1192 R1193 R1194 R1195 TMA 3 Arm support – Operation and maintenance manual...
  • Page 2 English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 Pressalit's Environmental and Quality Management Systems are certified...
  • Page 3 R1195 (AU) R1193 (AU) R1194 (AU) max 75 kg 165 lbs max 75 kg 165 lbs 150 kg 330 lbs YYYY-MM-DD RZZZZYYYXXX-X xxx kg xxx kg xxx lbs xxx lbs Pressalit A/S, Pressalitvej 1 DK-8680 Ry +45 8788 8777 pressalit.com...
  • Page 4 ( 6 . 1 ) 1 5 5 ( 2 3 . 6 6 0 0 (8.66) 1 7 0 ( 6 . 6 5 8 0 ( 2 2 . 8 3 Max P Max I R1193 40 V 0.1 A R1194...

  • Page 5: Table Of Contents

    Disposal and recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14 Mounting instruction A mounting instruction is included with the product . It can also be downloaded from pressalit .com . WARNING Test the load-bearing capacity of the floor before installation . Floor- standing WC ceramic appliances must be securely fixed to the floor with screws .

  • Page 6: Symbols Used In This Manual

    Symbols used in this manual The following symbols are used in this manual as well as the associated documentation supplied with the product . WARNING WARNING indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury . CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury .

  • Page 7: General Safety

    • The information in this manual is based on correct fitting of the product in accordance with our mounting instruction. • Pressalit cannot be held liable if the product is used in any way which differs from that described in the guide.

  • Page 8: Intended Use

    NOTICE Any serious incident that has occurred in relation to the product should be reported to Pressalit and the health authorities . A serious incident is defined as an incident that leads to the death of a patient, user, or any other person, or causes a temporary or permanent deterioration in the person’s health .

  • Page 9: Operating Instructions

    Operating instructions The two arm supports can be folded up and down individually . Fold them both up when not in use . Take care to avoid injury to hands when in the vicinity of closing moveable parts . Nurse call button The support arm models R1193 and R1194 are equipped with a nurse call button on either left or right arm .

  • Page 10: Maintenance

    Maintenance It is recommended that maintenance inspection is done once a year . Maintenance inspection Tighten the screws if necessary . ① Do not use hinges other than the original ones . CAUTION • Do not use the product if it is broken or damaged . •...

  • Page 11: Cleaning

    The product is to be cleaned with hot water or a mild soapy cleaning agent . To see which cleaning products have been tested and approved by Pressalit for the specific product, please visit Pressalit .com and refer to the product’s item number . Pressalit recommends cleaning the product after installation .

  • Page 12: Product Label

    IPXX I:XXA xxx lbs xxx kg YY-MM-DD xxx lbs 2 min 18 min Pressalit A/S, Pressalitvej 1, DK-8680 Ry +45 8788 8788, pressalit.com Consult manual for use Medical device Maximum user weight Date of manufacture Article number IP class Product weight...
  • Page 13 • Regulation (EU) 2017/745 (5 April 2017) on medical devices • Council Directive 2006/42/EC (of 17 May 2006) on machinery • Council Directive 2011/65/EC (of 8 June 2011) on RoHS A declaration of conformity can be found at pressalit com.

  • Page 14: Technical Data

    Technical data Materials Aluminium Polyurethane IP class IPX6 Operating temperature -30°C – +80°C (-22°F - 176°F) Disposal and recycling The unit contains reusable materials . There are no known hazards or risks associated with disposal of the product . All components can be discarded after having been cleaned and disinfected .
  • Page 15 Pressalitvej 1 8680 Ry Denmark Tel. : +45 8788 8788 Fax : +45 8788 8789 E-mail : pressalit@pressalit.com pressalit.com Visit our website to find your local dealer and get further information about Pressalit and our solutions for bathrooms and kitchens.

This manual is also suitable for:

R1192R1193R1194R1195
