Ordering key
Type
Nominal voltage
N 115 V AC, 60 Hz
P 230 V AC, 50 Hz
Nominal force
1 1 500 N
2 2 300 N
Screw
A ACME screw
3 digit Stroke and 3 digit Retracted length (mm)
Stroke Retracted length
Base
1)
102 380
153 415
204 415
305 465
457 668
610 821
Ingress protection
A Standard (IP 65)
Attachment diameter (Front and rear)
A Standard (hole: Ø13,1 mm)
X Customized
2)
Attachment orientation (Front and rear)
A Standard (0°)
B 30°
C 60°
D 90°
E 120°
F 150°
X Customized
2)
Option 1
0 None
L Limit switch (only for load version 2 300 N)
Option 2
0 None
P Potentiometer
Customization
Base: the Retracted length without "Limit switch", without "Potentiometer"
1)
Only available on request. Contact Ewellix for more information.
2)
6
C A H B – 3 0 –
with Limit switch with Potentiometer
L P
+ 60 + 38
+ 25 + 38
+ 25 + 38
+ 127 + 38
+ 76 + 38
+ 76 + 38
A – – A
CA H B - 3 x s e r i e s
0 – 0 0 0
