CATEGORY MAX 2 LINES INSTALLATION, OPERATION AND MAINTENANCE MANUAL Heading 1 CAHB-3x series max 2 lines Linear actuator CAHB-30A CAHB-31N Subheading max 2 lines Feature 1 max 2 lines Feature 2 max 2 lines Feature 3 Feature 4...
CA H B - 3 x s e r i e s Contents 1. General information ............3 1.1 Information in this manual ..........3 1.2 Manufacturer information ..........3 1.3 Declaration of incorporation .........4 2. Technical data ..............5 2.1 Operating conditions.............5 2.2 Operating voltages and limits ........5 2.3 Approximate weight of the actuator ......5 3.
CA H B - 3 x s e r i e s 1. General information DANGER 1.1 Information in this manual Indicates a dangerous situation, which will lead to death or serious personal injury, if the precautionary measures are This manual provides important information on how to work ignored.
CA H B - 3 x s e r i e s 1.3 Declaration of incorporation CN99-Declaration-EHSQ-5420 Declaration of Incorporation (CAHB3X) According to Annex IIB of Directive on machinery 2006/42/EC The products listed below, are partly completed machineries intended to be assembled with other machine, unit or system.
CA H B - 3 x s e r i e s 2. Technical data 2.2 Operating NOTE The technical data (dimensions, weight, output, connection val- voltages and limits ues etc.) are given in the attached drawings and data sheets 5.
Page 6
CA H B - 3 x s e r i e s Ordering key C A H B – 3 0 – A – – A 0 – 0 0 0 Type Nominal voltage 115 V AC, 60 Hz 230 V AC, 50 Hz Nominal force 1 500 N 2 300 N...
Page 7
CA H B - 3 x s e r i e s Ordering key C A H B – 3 1 – – N – – A 0 – 0 0 0 Type Nominal voltage 115 V AC 230 V AC Nominal force 2 300 N 4 500 N...
CA H B - 3 x s e r i e s 3. Structure and function 3.1 Overview and structure Figure 1 CAHB-30/31 with limit switch option 1. Front attachment 2. Extension tube 3. Guiding tube 4. Gearbox 5. Rear cover 6.
CA H B - 3 x s e r i e s 3.3.2 Thermal protection 3.2 Brief description The thermal switch built into the motor will turn off the power The actuator has been designed and built exclusively for its to the motor if it overheats.
CA H B - 3 x s e r i e s 4. Installation and operation Please read the following safety information carefully. Ensure Correct & issues schematics: that all persons who will connect, install, or use the actua- Figure 4 tors are in possession of the necessary information and have access to this installation manual.
Page 11
CA H B - 3 x s e r i e s • Correctly connect the wires (see figure 1 and figure 2, • If the clutch continuously slips, it may result in overheating item 10) of the power supply and control unit cable ac- and damage to the actuator.
CA H B - 3 x s e r i e s 4.1 Installation Connect the attachments (see figure 8, item 1 and 2) to the Linear actuator is attached to two elements via the hinge appropriate elements of the application with the pins/fixing heads (i.e., actuator attachments).
CA H B - 3 x s e r i e s 4.2 Wiring Green wires must be connected to the PE wire to prevent electric shock. Figure 9 Connecting diagram Wire connection for power (see figure 1 and 2, item 10, page 8) Wire no.
CA H B - 3 x s e r i e s 5. Reference documents Supporting documents are available for download on ewellix.com on the CAHB3 product page under Publications or if you scan the below QR code. Linear actuator CAHB series Click to open...
