Item #1012002058
Model #04866
Basic Model # AI-04866 -Rev1-07152024
USE AND CARE GUIDE
TORTE LED 46 INCH CEILING FAN FOR INDOOR USE
Questions, problems, missing parts?
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this celing fan. We strive to continually
create guality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for HAMPTON BAY TORTE 04866
Summary of Contents for HAMPTON BAY TORTE 04866
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this celing fan. We strive to continually create guality products designed to enhance your home. Visit us online to see our full line of products available for your home...
- Page 2 Table of Contents...
- Page 3 To reduce the risk of re, electric shock or injury to persons, do not use replacement parts that have not been recommended by the manufacturer (e.g. Parts made at home using a 3D printer). Use only with light kits marked 'Suitable for use in damp locations'.
- Page 4 or, at our option, gives 0.24 15.64 1982 6.5 kg 9.3 kg 46 in. 1.982' 0.34 30.11 2993 (14.3 lb) (20.46 lb) (1.16 m) 0.45 53.94 4086...
- Page 5 Remote control cradle hardware pack (ST3.5*13mm screw -2pcs, 1 set ST3.0*18mm screw-2pcs, #6/32*13mm screw-2pcs, anchor -2pcs) 15+1 spare 1 set...
- Page 6 1.5V Fan motor assembly Bottom ywheel (preassembled) Remote control Remote control cradle Coupling 1.5V Up ywheel (preassembled)
- Page 7 UL Listed fuse electrical...
- Page 8 fan motor assembly coupling set screws (II).
- Page 9 Hanging the fan motor assembly to the mounting bracket (KK) (HH) Manual reverse switch (NN) is located under the coupling cover (G). Please refer to page 17 for the details of reverse function. NN (manual reverse switch)
-
Page 10: Installing The Receiver
Installing the receiver Wires coming from the downrod and the wires coming from the power source need to be positioned on the same side when inserting the receiver through the mounting bracket. - Page 11 Connect the white (neutral) wire from the ceiling to the white wire marked "AC IN N" from the receiver (L). Connect the black (hot) wire from the ceiling to the black wire marked " AC IN L " from the receiver (L). hanger...
-
Page 13: Installing The Blades
Installing the blades Pay attention to the words “THIS SIDE UP” on the blade (A). Align the two holes from the blade (A) to the up flywheel (H) on the fan motor assembly (I). Secure the blade with the two blade screws (BB) provided. Align the three holes from the blade (A) to the bottom flywheel (J) on the fan motor assembly (I). - Page 14 CAUTION: To reduce the risk of electric shock, disconnect the electrical supply circuit to the fan before installing the light kit. the switch box (MM)
- Page 15 SYNCING THE RECEIVER AND THE REMOTE CONTROL Install two 1.5V batteries (O) into the remote control. To prevent damage to the remote control, remove the batteries if not used for long periods of time. Restore power to the ceiling fan and test for proper operation. WARNING: Do not short-circuit, disassemble, heat up, connect improperly, or dispose of used batteries in fire.
- Page 16 REMOTE CONTROL OPERATING INSTRUCTIONS : Press and release this button to turn the fan and light on/off. Fan & Light ALL ON/OFF LEDs signal light The fan has memory function. It will resume NOTE: the speed and light setting on the ceiling fan prior Fan ON/OFF to the power being turned off.
-
Page 17: Reverse Function
REVERSE FUNCTION Summer SUMMER MODE Winter WINTER MODE... - Page 18 Mounting the remote wall cradle The remote wall cradle is designed to allow you to NOTE: access an existing switch. The remote wall cradle can be mounted on the wall or to the face plate of a standard Toggle switch face plate toggle switch or a paddle switch.
- Page 21 1.5V Remote control cradle hardware pack (ST3.5*13mm screw -2pcs, ST3.0*18mm screw-2pcs, #6/32*13mm screw-2pcs, anchor -2pcs) Coupling Up ywheel (preassembled) Fan motor assembly Bottom ywheel (preassembled) Remote control Remote control cradle 1.5V...
- Page 22 HAMPTON BAY CF346KR-01 Document #:340643311101...
