MJX HYPER GO User Manual

1:10 rc high speed car
Hide thumbs Also See for HYPER GO:

Advertisement

Quick Links

Download this manual
14+
No.10208
1:10 RC HIGH SPEED CAR
USER MANUAL
V1.2

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYPER GO and is the answer not in the manual?

Questions and answers

Related Manuals for MJX HYPER GO

Summary of Contents for MJX HYPER GO

  • Page 1 No.10208 1:10 RC HIGH SPEED CAR USER MANUAL V1.2...

  • Page 2: Warnings And Cautions

    The instruction sheet for this product is just for your reference. We reserve the right to make changes or adjustments on the product without prior notification. Please refer to the official information. Warning: Choking hazard! This product contains small parts. NOT suitable for children under 3 years. Contains electrical components and should be kept dry at all times.
  • Page 3 ●Be sure to read thoroughly ●Cutters, nippers and ●As the product contains the manual before you screwdrivers need careful small and sharp parts, begin. Fresh user should handling. assemble and store this seek advice from people product only in places having rich experience in out of the reach of children.
  • Page 4 FCC PART 15 B Notice: CAUTION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 电池使用注意事项 1. 遥控器使用2节1.5V“AA”号电池； 2. 安装或更换电池时请注意极性； 3. 充电电池只能在成人监护下充电； 4. 不可混用新旧或不同型号的电池； 5. 电池电量用尽后,应从模型内取出； 6. 将耗尽电量的电池交给专门的环保部门处理! 7. 接线端不应短路； 8. 非充电电池不可充电; 9. 充电电池充电前应从模型中取出; 10. 请不要将坏的电池、电池组分解或扔到火中、水里,以免发生意外; 11. 充电器的额定输入电压必须与当地的家用电压相符; 12. 在充电过程中,充电器和电池出现微温,属于正常现象。 13. 不可吞咽电池! 14. 将电池放在凉爽、干燥避光及小孩接触不到的地方! 15. 电池漏液而且滴到眼睛里,请马上用大量的清水清洗,然后到附近的医院就医。 微功率短距离设备相关规定要求如下： （一）符合“微功率短距离无线电发射设备目录和技术要求”的具体条款和使用场景，采用的天线 类型和性能，控制、调整及开关等使用方法； （二）不得擅自改变使用场景或使用条件、扩大发射频率范围、加大发射功率（包括额外加装射频 功率放大器），不得擅自更改发射天线； （三）不得对其他合法的无线电台（站）产生有害干扰，也不得提出免受有害干扰保护； （四）应当承受辐射射频能量的工业、科学及医疗（ISM）应用设备的干扰或其他合法的无线电台 （站）干扰； （五）如对其他合法的无线电台（站）产生有害干扰时，应立即停止使用，并采取措施消除干扰后 方可继续使用；...
  • Page 6 Power Switch 开关 1. Turn on the power switch of the transmitter, the signal indicator light of transmitter flashes. 2. Press the power button of high speed car, which is on the side of the ESC; the indicator light of high speed car flashes. 3.
  • Page 7 R30 Receiver 接收器 VCC/FAN VCC/FAN 风扇 VCC/FAN VCC/FAN (VCC/FAN) Antenna (Please make sure it in vertical Front bumper direction) 前防撞架 天线 (务必保持竖直状态) Rear bumper 后防撞架 VCC/FAN: Power Interface (VCC=5-6V) 电调 VCC/FAN: 供电接口(VCC=5-6V) Indicator Meanings situation 含义 指示灯状态 Stays on Signaled 常亮...
  • Page 8 ESC 电调 Indicator 指示灯 Fan plug 风扇插座 Blue wire 蓝线 风扇 White wire 白线 Yellow wire 黄线 Power switch 电源开关 Indicator light situation Meanings 指示灯状态 含义 Stays on Signaled 常亮 有信号 a. No signal Flash quickly 无信号 快闪 b. Pull the trigger 扣动扳机...
  • Page 9 T3B Transmitter 遥控器 ①ST.TRIM (Steering servo trimmer) ST.TRIM（转向舵机微调） ②TH.TRIM（Throttle trimmer) TH.TRIM（油门中位微调） ③Power switch 电源开关 (OFF-70%TH-100%TH) ④Indicator light 指示灯 ⑤CH1： ST （Steering) CH1： ST （转向） ⑥CH2： TH （Throttle) CH2： TH （油门） ⑦Fn（CH3 Light control) Fn（CH3灯控） ①ST.TRIM (Steering servo trimmer 转向舵机微调) If the car cannot go straightly during driving, it can be adjusted through the ST.TRIM. 车辆行驶过程中如无法直线行驶，可通过此微调进行调整。...
  • Page 10 ③Power/Speed switch ④Indicator light 电源/速度档位开关 指示灯 Stays on Working well 常亮 正常 Flash quickly Frequency mating 快闪 对码状态 Low battery 100% Flash slowly of transmitter (关) (70% Throttle) (100% Throttle) 慢闪 遥控器电池电量低 (70%油门) (100%油门) ⑤CH1：ST (Steering 转向) Middle Turn left Turn right 中位...
  • Page 11 ⑦Fn (CH3 Light control 灯控) Short Press the “ ” button to turn on/off the light of high speed car. 短按“ ”按键时，控制高速车灯光开启或关闭。 Install the Transmitter’ s Battery 遥控器安装电池 Open the transmitter’s battery cover, insert 2 AA batteries according to the indicated positive and negative direction, close the battery cover.
  • Page 12 Install the Battery 安装电池 ①Tighten the battery with the fixing tape; 将固定带绑紧电池； ②Connect the receiver plug to the battery. 将接收器插头连接电池。 Install Car Shell 安装车壳 1. Insert the body into the front mount ① and press the latch vertically down to the rear mount ②. 将车壳插入前固定件①，锁扣垂直下压到后固定件②。...
  • Page 13 Front Bumper Assembly 前防撞组件 Screw 螺丝： HTM3010 3x10mm 6PCS Screws 螺丝 HTM3010 HTM3010 10100 Rear Bumper Assembly 后防撞组件 Screw 螺丝： HTM3010 3x10mm 4PCS Screws 螺丝 HTM3010 HTM3010 10110 HTM3010 Front Swing Set 前摆臂组件 HTM3016 Screw 螺丝： 10230A HTHM30135 HTM3016 3x16mm 1PCS Screws 螺丝...
  • Page 14 Rear Swing Set 后摆臂组件 Screw 螺丝： HTM3016 HTM3016 3x16mm 1PCS 10240 Screws 螺丝 HTHM3040 HTHM3040 3x40mm 1PCS Screws 螺丝 R168Z R168Z 10250 10260 1PCS R168Z 2PCS Bearing 法兰螺母 轴承 Front/Rear Sway Bar 前/后防倾杆 Screw 螺丝： M3030 3x3mm 2PCS(4PCS) Screws 内六角机丝螺丝 M3030 M3030 Front 前...
  • Page 15 Motor Assembly 电机组件 Screw 螺丝： HTM3016 HTM3016 3x16mm 6PCS Screws 螺丝 HTM3010 3x10mm 2PCS Screws 螺丝 HWM4030 4x3mm 1PCS Screws 内六角机丝螺丝 10397 When using a 4S (14.8V) battery to drive the car, make sure that both fans are connected to the receiver and operating properly.
  • Page 16 Steering Assembly 转向传动组件 Screw 螺丝： HTM3014 3x14mm 2PCS Screws 螺丝 HTM3020 3x20mm 2PCS Screws 螺丝 4PCS Nut 法兰螺母 R168Z R168Z 4PCS Bearing 轴承 R168Z HTM3014 10240 R168Z R168Z 10432 10240 T65348 HTM3020 10430 -15-...
  • Page 17 Center Differential 中央差速器 Screw 螺丝： HKM3012 3x12mm 4PCS BRG10154 2PCS Bearing Screws 螺丝 轴承 HKM3012 BRG10154 BRG10154 10420C HKM3012 Front/Rear Differential 前/后差速器 Screw 螺丝： HTM3016 3x16mm 4PCS HTM3016 Screws 螺丝 BRG10154 BRG10154 2PCS Bearing 轴承 10420 BRG10154 -16-...
  • Page 18 Front Gearbox 前齿轮箱 Screw 螺丝： HTM3012 10192 10420 HTM3012 3x12mm 2PCS Screws 螺丝 HKM3080 3x8mm 1PCS Screws 螺丝 HKM3080 10402 HTM3012 10192 Rear Gearbox 后齿轮箱 Screw 螺丝： HTM3012 10192 10420 HTM3012 3x12mm 2PCS Screws 螺丝 10402R HTM3012 10192 Servo Assembly 舵机组件 Screw 螺丝：...
  • Page 19 High Speed Car Assemble 高速车总装 10131 10403 HTM3014 10420C S3580R 10150 10300 M3080 1031R HTM3014 M3080 HKM3080 10130 1031F M3080 M3080 HKM3080 Screw 螺丝： HTM3014 3x14mm 6PCS Screws 螺丝 M3080 3x8mm 6PCS Screws 螺丝 HKM3080 3x8mm 11PCS Screws 螺丝 -18-...
  • Page 20 High Speed Car Assemble 高速车总装 HTM3010 HTM3014 HTM3014 HTM3014 10191 HTM3012 10190 10320 10160 HTM3014 Screw 螺丝： HTM3014 3x14mm 18PCS Screws 螺丝 HTM3012 3x12mm 2PCS Screws 螺丝 HTM3010 3x10mm 1PCS Screws 螺丝 -19-...
  • Page 21 -20-...
  • Page 22 -21-...
  • Page 23 -22-...
  • Page 24 -23-...
  • Page 25 High Speed Car Assemble 高速车总装 Nut 螺母： 1PCS（4PCS） M4 Wheel lock nut M4螺母 10440 10440 1015A -24-...
  • Page 26 Spare Parts 配件表 1030A 10100 10110 10120 Front Bumper Wheelie Bar Body Rear Bumper Assembly Assembly 车壳组件 后防撞 抬头轮 前防撞组件 10130 10131 10150 10300 Chassis Parts Motor Shelf Servo Mount Chassis 底盘配件 电机安装座 舵机支架 底盘 10310 1031F 1031R 10160 Front Upper Center Brace Bar Front Stiffener Rear Stiffener...
  • Page 27 Spare Parts 配件表 10190 10191 10270 10280 Rear Upper Front Shock Rear Shock Vise Jaw Tower Tower Gearbox Covers 波箱盖 后齿轮盖 前避震架 后避震架 10200 10220 10230A 10230B Front Lower Steering Block Steering Block Suspension Arms 拉杆 转向座 转向座 前下摆臂 10240 10250 10260 10501...
  • Page 28 Spare Parts 配件表 10121 10320 Z3060 M10400 Front/Rear F/R Lower Swing F/R Reinforced Receiver Box Sway Bar Arm Fixed Shaft Sheet 接收盒 前/后防倾杆 下摆臂固定轴 前后加强件 S3580R 10702 10430 10432 Steering Servo Servo Swingarm Connecting Rod Assembly 舵机 舵机摆臂 转向连杆 转向传动组件 B3970A 10392 10393...
  • Page 29 Spare Parts 配件表 10397 10420C 10420 10192 Center Front/Rear Gearbox ESC Fan Differential Differential Housings 电调风扇 中央差速器 前/后差速器 差速器外壳 10402 10402R 10403 E100A Front Drive Rear Drive Centre Drive Brushless ESC Teeth Teeth Shaft 无刷电子调速器 前伞齿 后伞齿 主轴 10510 10500 Oil Filled Shock Oil Filled Shock Receiver...
  • Page 30 Spare Parts 配件表 10410 10440 1015A Metal F/R CVD M4 Wheel Lock Wheel Hex Wheel Assembly Shafts (2 Sets) 六角套 车轮组件 (2PCS) 轮胎转动组件 M4螺母 (8PCS) BD2217 P812 T70367 T65348 Hexagonal Battery Base Bushing Bushing Wrench 电池固定带 轴套 轴套 (2PCS) (8PCS) (8PCS) 六角扳手...
  • Page 31 Screws 螺丝 Others 其他 M3030 3x3mm 12PCS BRG10154 Bearing 轴承 8PCS M3080 3x8mm 12PCS R168Z Bearing 轴承 8PCS HTM3010 3x10mm 12PCS 3mm Nut 螺母 8PCS HTM3012 3x12mm 12PCS 4mm Nut 螺母 8PCS HTM3014 3x14mm 12PCS HTM3016 3x16mm 12PCS HTM3060 3x6mm 12PCS HKM3012 3x12mm...
  • Page 32 Download ESC APP SNAIL ESC International User Chinese User Only 中国内地用户 Android MADE IN CHINA Instructions must be retained since it contains important information.
