MJX HYPER GO 14303 Manual

1:14 rc high speed car
Hide thumbs

Advertisement

Quick Links

Download this manual
14+
No.14303
1:14 RC HIGH SPEED CAR
USER MANUAL
V2.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the HYPER GO 14303 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MJX HYPER GO 14303

Summary of Contents for MJX HYPER GO 14303

  • Page 1 No.14303 1:14 RC HIGH SPEED CAR USER MANUAL V2.0...

  • Page 2: Warnings And Cautions

    The instruction sheet for this product is just for your reference. We reserve the right to make changes or adjustments on the product without prior notification. Please refer to the official information. Warning: Choking hazard! This product contains small parts. NOT suitable for children under 3 years. Contains electrical components and should be kept dry at all times.
  • Page 3 ●Be sure to read thoroughly ●Cutters, nippers and ●As the product contains the manual before you screwdrivers need careful small and sharp parts, begin. Fresh user should handling. assemble and store this seek advice from people product only in places having rich experience in out of the reach of children.
  • Page 4 FCC PART 15 B Notice: CAUTION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 5 电池使用注意事项 1. 遥控器使用2节1.5V“AA”号电池； 2. 安装或更换电池时请注意极性； 3. 充电电池只能在成人监护下充电； 4. 不可混用新旧或不同型号的电池； 5. 电池电量用尽后,应从模型内取出； 6. 将耗尽电量的电池交给专门的环保部门处理! 7. 接线端不应短路； 8. 非充电电池不可充电; 9. 充电电池充电前应从模型中取出; 10. 请不要将坏的电池、电池组分解或扔到火中、水里,以免发生意外; 11. 充电器的额定输入电压必须与当地的家用电压相符; 12. 在充电过程中,充电器和电池出现微温,属于正常现象; 13. 不可吞咽电池! 14. 将电池放在凉爽、干燥避光及小孩接触不到的地方! 15. 电池漏液而且滴到眼睛里,请马上用大量的清水清洗,然后到附近的医院就医。 Power Switch 开关 1. Turn on the power switch of the transmitter, the signal indicator light of transmitter flashes.
  • Page 6 R3B Receiver 接收器 VCC/FAN VCC/FAN 风扇 VCC/FAN VCC/FAN (VCC/FAN) Antenna (Please make sure it in vertical direction) 天线 Body (务必保持竖直状态) 车壳 (CH3) 电调 VCC/FAN: Power Interface (CH2) (VCC=5-6V) VCC/FAN: 供电接口(VCC=5-6V) Indicator Meanings situation 含义 指示灯状态 Stays on Signaled Steering 常亮 有信号...
  • Page 7 G3 Gryo 陀螺仪 Receiver 接收器 Steering servo 转向舵机 ①GAIN Spin the knob from the left to right, the gyro intervention gains value 0-100%. 旋钮从左到右调整陀螺仪介入增益值0-100%。 ②SET 设置 1. Reverse/Normal Switching 正反向切换 When the power on, long press the【SET】3 seconds, the LED from red to green or from the green to red, it means the switch is successful.
  • Page 8 c. Rotate the remote control direction rudder to turn the servo to the desired position in another direction and keep the current state, short press【SET】and the red and green LEDs will flash (about 2 seconds). When the LEDs will be on, the EPA setting is finished.
  • Page 9 E45P Brushless ESC 电调 Please Do Not forcible/reversely insert all sockets. 所有插座请勿强行反插。 Indicator 指示灯 Fan plug 风扇插座 Power switch 电源开关 Heat sink 散热片 Yellow wire A 黄线A White wire B 白线B Blue wire C 蓝线C Indicator light situation Meanings 指示灯状态 含义...
  • Page 10 Set the throttle range (Transmitter calibration) 设定油门行程（遥控器校准） When replacing the transmitter with a new one, it is recommended to reset the throttle range, otherwise the ESC may become inoperable or abnormal. 当更换新的遥控器时，建议重新设置油门行程，否则可能会导致ESC无法使用或异常。 ESC enters “the throttle range” state: ESC进入油门行程校准模式： 1. Turn on the transmitter, adjust the throttle trim to the middle position, and keep the status of“D/R”, “...
  • Page 11 2. Keep the throttle of the transmitter in the maximum forward position, press 【 SET 】 once, the red light of ESC flashes twice and then goes out, the motor“Di.Di” , indicating that the maximum forward position has been successfully stored; 保持遥控器油门处于最大前进位置，按一次...
  • Page 12 T3B Transmitter 遥控器 ①ST.TRIM (Steering servo trimmer) ST.TRIM（转向舵机微调） ②TH.TRIM（Throttle trimmer) TH.TRIM（油门中位微调） ③Power switch 电源开关 (OFF-70%TH-100%TH) ④Indicator light 指示灯 ⑤CH1： ST （Steering) CH1： ST （转向） ⑥CH2： TH （Throttle) CH2： TH （油门） ⑦Fn（CH3 Light control) Fn（CH3灯控） ①ST.TRIM (Steering servo trimmer 转向舵机微调) If the car cannot go straightly during driving, it can be adjusted through the ST.TRIM. 车辆行驶过程中如无法直线行驶，可通过此微调进行调整。...
  • Page 13 ③Power/Speed switch ④Indicator light 电源/速度档位开关 指示灯 Stays on Working well 常亮 正常 Flash quickly Frequency mating 快闪 对码状态 Low battery 100% Flash slowly of transmitter (关) (70% Throttle) (100% Throttle) 慢闪 遥控器电池电量低 (70%油门) (100%油门) ⑤CH1：ST (Steering 转向) Middle Turn left Turn right 中位...
  • Page 14 ⑦Fn (CH3 Light control 灯控) Short Press the “ ” button to turn on/off the light of high speed car. 短按“ ”按键时，控制高速车灯光开启或关闭。 Install the Transmitter’ s Battery 遥控器安装电池 Open the transmitter’s battery cover, insert 2 AA batteries according to the indicated positive and negative direction, close the battery cover.
  • Page 15 Install the dust-proof cover 安装防尘罩 1. Align the 3 holes of the cover with the bracket and install. 将防尘罩3个孔位对准防尘罩支架装入。 2. Insert the 3 shell buckles into the cover and lock. 将3个车壳扣插入锁紧防尘罩。 -14-...
  • Page 16 Install Car Shell 安装车壳 1. Aline the 4 holes of the car shell with holders, then install it. 将车壳4个孔位对准车壳支架装入。 2. Insert the 4 clips into the holes to lock the car body. 将4个车壳扣插入锁紧车壳。 -15-...
  • Page 17 14200 Front Swing Set 前摆臂组件 Screw 螺丝： Q1601 14210 HKB26125 HKB26125 2.6x12.5mm 2PCS Screws 沉头螺丝 14230 R168Z 14200 Bearing 轴承： R168Z 2PCS Ball bearing 滚珠轴承 14220 Q1601 R168Z Pivot balls 球头： Q1601 2PCS Q715 HKB26125 Steering pivot balls 球头 14201 Rear Swing Set 后摆臂组件 Screw 螺丝：...
  • Page 18 16420Y Metal Gears Diff Assembly 全金属齿轮差速箱 Screw 螺丝： Bearing 轴承： 16421 HKB2012 2x12mm 4PCS R1810 2PCS R1810 Screws Ball bearing 滚珠轴承 沉头螺丝 R1810 HKB2012 16420Y Front (前差速): 50000cs Silicone Oil 硅油 Rear (后差速)： Lubricating Oil 润滑油 16421 HKB2012 14500 Oil Filled Shock 油压避震 Add shock oil Shock absorbers adjuster 添加避震油...
  • Page 19 B284K & 16397 Motor Assembly 电机组件 Screw 螺丝： HTB3015 HTM3060 3x6mm 2PCS Screws 半圆头机丝螺丝 HTB3015 3x15mm 2PCS Screws 半圆头螺丝 M3030 3x3mm 1PCS 16397 Hexagon socket machine screw 内六角机丝螺丝 16395B B28454 B284K & 16397 14392 16393 M3030 HTM3060 14430 Steering Assembly 转向传动组件 Screw 螺丝：...
  • Page 20 14100L3 Front Bumper Assembly 前防撞组件 HTB2615 Screw 螺丝： HTB2615 2.6x15mm 4PCS Screws 半圆头螺丝 14102 14103 14100L3 14101L3 14110L3 Rear Bumper Assembly 后防撞组件 Screw 螺丝： HTB2660 HTB2660 2.6x6mm 2PCS Screws 14112 半圆头螺丝 14110L3 14111L3 -19-...
  • Page 21 High Speed Car Assemble 高速车总装 HTB2610 HTB2610 14180 14150 HTB2380 E45P 14160 14190 HTB2680 14400Y 16420Y (Lubricating Oil 16420Y 16420Y 润滑油) (50000cs (50000cs 1413Q Silicone Oil Silicone Oil HTB2610 HTB2610 B284K & B284K & 硅油) 硅油) 14270 16397 16397 HTB2380 HTB2380 Screw 螺丝：...
  • Page 22 -21-...
  • Page 23 -22-...
  • Page 24 -23-...
  • Page 25 High Speed Car Assemble 高速车总装 Iron shaft 铁轴： M20101 1PCS（4PCS） Wheel hex pins 六角套铁轴 16440 1PCS（4PCS） Wheel hex 六角套 Nut 螺母： 1PCS（4PCS） 16440 M4 Wheel lock nut M4螺母 M20101 1415A2 Body Standard 车身标配 Hardness: Soft. Better abrasion resistance. 硬度：软，更好的耐磨性。 1415A2 Hardness: Medium.
  • Page 26 Spare Parts 配件表 1430L3 14300 14310 14320 Body Chassis Center Brace Bar Center Shelf 车壳组件 底盘 中支撑杆 中搁架 14100L3 14110L3 14130 14140 Front Bumper Rear Bumper Chassis Parts Battery Clip Assembly Assembly 底盘配件 电池固定卡座 前防撞组件 后防撞组件 14150 14160 14161 14170 Front Support Front Upper Front Under...
  • Page 27 Spare Parts 配件表 14180 14290 14281L3 14190 Rear Shock Cover Body Rear Upper Body Pillars Tower Pillars Gearbox Covers 车壳支架 后避震架 防尘罩支架 后齿轮盖 14191 14210 14220 14230 Front Upper Front Lower Front Under Steering Block Suspension Arms Suspension Arms Gearbox Covers (Including Ball Head) (Including Ball Head) 转向座...
  • Page 28 Spare Parts 配件表 M1440 14701 14702 14430 F/R Reinforced Servo Saver Steering Servo Sheet Assembly Assembly 舵机 前后加强件 舵机离合摆臂 转向传动组件 14431 14270 14271 B284K Servo Upper Servo Under Steering Linkage Motor Assembly Fix Frame Fix Frame 转向拉杆 电机组件 (2PCS) 舵机上固定架 舵机下固定架...
  • Page 29 Spare Parts 配件表 16397 16420Y 14400Y 16401Y Metal Gears Diff Metal Gears Main Spur Gear Motor Fan Assembly Driving Set Assembly (Metal) 风扇 全金属齿轮差速箱 全金属主传动组件 传动主齿轮组件(金属) 16402Y 14403 E45P Drive Gear Centre Drive Brushless ESC Receiver (Metal) Shaft 无刷电子调速器 接收器 前锥齿(金属) 主轴...
  • Page 30 Spare Parts 配件表 16440 1415A2 1415B2 1415C Wheel Hex Tires（Rubber） Tires（TPR） Tires (Drift) 六角套 橡胶轮胎 TPR轮胎 漂移轮胎 (2PCS) (2PCS) (2PCS) B2S20 P2050 1430Z M4 Wheel Lock USB Charging Battery Dust proof cover Cable 电池 防尘罩 M4螺母 USB充电线 (8PCS) 1413Q BD30 M0522S Gryo Drive Shaft Bracket...
  • Page 31 Spare Parts 配件表 P810 P812 M001 Q1601 Hexagonal Steering Pivot Screwdriver Body Clips Wrench Balls 螺丝刀 车壳扣 (12PCS) 六角扳手 球头 (8PCS) Q1602 M2523 HTHM3029 M4018 Steering Pivot Screws Screws Rear Fixing Pin Balls 半圆头半牙螺丝 不锈钢紧定螺丝 后固定座插销 (4PCS) 球头 (8PCS) (12PCS) (12PCS) Q715 PH03...
  • Page 32 Screws 螺丝 Others 其他 HKM2580G 2.5x8mm 12PCS R1810 Bearing 轴承 8PCS HKB2012 2x12mm 12PCS R168Z Bearing 轴承 8PCS HTB2380 2.3x8mm 12PCS HTB2680 2.6x8mm 12PCS HTB2610 2.6x10mm 12PCS HTB2615 2.6x15mm 12PCS HKB2312 2.3x12mm 12PCS HKB2690 2.6x9mm 12PCS HKB26125 2.6x12.5mm 12PCS HKB2615 2.6x15mm 12PCS HTM4012...
  • Page 33 MADE IN CHINA Instructions must be retained since it contains important information.
