- Page 1 DEHUMIDIFIER Owner’s Manual SKU：ZX-DH-22-AZ-HM / ZX-DH-35-AZ-HM / ZX-DH-50-AZ-HM IMPORTANT NOTE: Before using your appliance, please read this manual carefully and keep it for future reference.
- Page 2 CONGRATULATIONS Dear Customer: Welcome to our family. Thank you for purchasing one of our products. Our goal is to provide you with superior service. If there is anything missing from or wrong with your order, or if you have any questions about using our Dehumidifier, PLEASE contact us. Email: support@homyd.com Our team is available 24/7 to address your questions, comments, and concerns.
-
Page 3: Table Of Contents
CONTENTS Safety manual for R32 refrigerant model 01-06 Safety precautions 07-09 Get to know your product Get to know your product 10-14 Get to know your features 15-17 Dump the collected water Dump the collected water 18-21 Care and Maintenance 22-23 Technical Parameters Troubleshooting... -
Page 4: Safety Manual For R32 Refrigerant Model
Safety manual for R32 refrigerant model North America Products IMPORTANT NOTE: Read this manual CAUTION: carefully before installing or operating Risk of fire your new appliance unit. Make sure flammable materials to save this manual for future reference. Explanation of symbols displayed on the unit CAUTION This symbol shows that the operation manual should be read carefully. - Page 5 WARNING： -Servicing shall only be performed as recommended by the -Do not use means to accelerate the defrosting process or to clean, equipment manufacturer. Maintenance and repair requiring the other than those recommended by the manufacturer. assistance of other skilled personnel shall be carried out under the -The appliance shall be stored in a room without continuously supervision of the person competent in the use of flammable operating ignition sources (for example: open flames, an operating...
- Page 6 1)Checks to the area 7)ventilated area Prior to beginning work on systems containing flammable Ensure that the area is in the open or that it is adequately ventilated refrigerants, safety checks are necessary to ensure that the risk of before breaking into the system or conducting any hot work. A ignition is minimised.
- Page 7 7.Sealed electrical components shall be replaced. 10.Detection of flammable refrigerants 1)During repairs to sealed components, all electrical supplies shall Under no circumstances shall potential sources of ignition be be disconnected from the equipment being worked upon prior to used in the searching for or detection of refrigerant leaks. A any removal of sealed covers, etc.
- Page 8 The refrigerant charge shall be recovered into the correct recovery cylinders if venting is not allowed by local and national codes. For appliances containing flammable refrigerants, the system shall be purged with oxygen-free n flammable refrigerants. This process might Compressed air or oxygen shall not be used for purging refrigerant systems. For appliances containing flammable refrigerants, refrigerants purging shall be achieved by breaking the vacuum in the system with oxygen-free nitrogen and continuing to fill until the working pressure is achieved, then venting to atmosphere, and finally pulling down to a vacuum (optional for A2L).
- Page 9 15.Recovery When removing refrigerant from a system, either for servicing or decommissioning, it is recommended good practice that all refrigerants are removed safely. When transferring refrigerant into cylinders, ensure that only appropriate refrigerant recovery cylinders are employed. Ensure that the correct number of cylinders for holding the total system charge is available.
-
Page 10: Safety Precautions
Safety Precautions Must read the warning message. Read Safety Precautions Before Operation and Installation To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. - Page 11 WARNING Place the unit on a level, sturdy section of the floor. Do not place heavy object on the power cord and take Do not cover the intake or exhaust openings with cloths care so that the cord is not compressed. or towels.
- Page 12 CAUTION Be sure the unit is properly grounded. To minimize damage to the machine due to lightning. shock and fire hazards, proper grounding is important. Do not run cord under carpeting. Do not cover cord with The power cord is equipped with a three-prong throw rugs, runners, or similar coverings.
-
Page 13: Get To Know Your Product
Get to know your product Name of each component of the product Identification of parts Model A Control panel Handle(both sides) Front panel Water level window Water bucket Caster Air outlet grille Air filter (Air inlet grille) Continuous drain hose outlet Power plug storage Model B Power cord and plug... -
Page 14: Positioning The Unit
Positioning the unit Safe distance requirements 40cm or more 40cm or more 20cm 20cm or more or more 40cm or more Front view Top view Casters(At four points on the bottom of unit) Casters can move freely. Do not force casters to move over carpet, nor move the unit with water in the bucket. (The unit may tip over and spill water.) Place the unit in an area where the temperature will not fall below in drying an adjacent enclosed storage area, such as a closet, unless 5°... - Page 15 When using your product Preparations for product use. NOTE When the water in the bucket reaches to a certain level, please be careful to move the machine to avoid it falling down. First time using Working condition requirement Precautions for use After a quick restart, Ensure the water plug wait 3 minutes for the...
-
Page 16: Optional Accessories
Accessories NOTE Items with (*) are on some models. Slight variations in design may occur. Accessories Optional accessories NOTE:Make the water pipe straight when you use it pump drain hose( 1 pc* ) Cushion pad ( 1 pc ) ( 4 pc ) Caster (For the unit with pump feature) Drain Hose ( 1 pc* ) - Page 17 Step 2 Step 1 Before inserting Correct inserted Tilt the unit on the Rotate the unit and hold Leave the unit in a it with one hand, then vertical position for and hold it with one hand,then insert two insert the other two casters half an hour before use casters WARNING:...
-
Page 18: Get To Know Your Features
Get to know your features Operation Display Control Panel Features NOTE The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly -Pump -ion 1.POWER ON/OFF button Wireless button(On some models) 2.TIMER Function Press the button to initiate the Auto start and Auto stop function, in conjunction with the UP and DOWN buttons. - Page 19 Smart dehumidifying mode (Comfort)-optional 3. The selected time will register in 5 seconds and the system will Press the button to select the Smart dehumidifying mode. automatically revert back to display the humidity. NOTE: Humidity cannot be adjusted in this mode. The unit The control will count down the time remaining until start.
-
Page 20: More Features
6. Display back in. If the error repeats, call for service. Display ambient humidity and setting humidity (humidity range: 30% to 90%); Display TIMER setting (timing range: 24 hours); Display error P2 - Bucket is full of water or bucket is not in right position. Empty the codes reminder . -
Page 21: Dump The Collected Water
Dump the collected water When your product has been in use for a while. There are three ways to remove collected water. Type 1: Type 2: Bucket drainage water hose drainage (continuous) - Page 22 Bucket drainage Type 1 Pull the bucket out halfway, then pull up the handle and lift the bucket slowly vertically to prevent spatter. Throw away the water and replace the bucket. The bucket must be in right place and securely seated for the dehumidi er to operate. The appliance will re-start when the bucket is restored in its correct position.
-
Page 23: Connect The Drain Hose
NOTE When you remove the bucket, do not touch any parts inside of the unit. Doing so may damage the product. Be sure to push the bucket gently all the way into the unit. Banging the bucket against anything or failing to push it in securely may cause the unit not to operate. - Page 24 When you remove the plastic cover, if there is some water in the back drain outlet of the unit you must dry it. Make sure the hose is secure so there are no l eaks and the end of the hose is level or down to let the water flow smoothely. Direct the hose toward the drain, making sure that there are no kinks that will stop the water flowing.
-
Page 25: Care And Maintenance
Care and Maintenance How to clean & maintenance your product. Clean the Grille and Case Use water and a mild detergent. Do not use bleach or abrasives. Do not splash water directly onto the main unit. Doing so may cause an electrical shock, cause the insulation to deteriorate, or cause the unit to rust. The air intake and outlet grilles get soiled easily, so use a vacuum attachment or brush to clean. - Page 26 When not using the unit for long time periods Step 3 Step 2 *Please refer to the actual plug, and the legend is for reference only. Step 1 Step 4 Step7 Step5 Step 6 Clean the main unit, water bucket and air filter. Wrap the cord with the power cord buckle.
-
Page 27: Technical Parameters
Technical Parameters SKU: ZX-DH-22-AZ-HM ZX-DH-35-AZ-HM ZX-DH-50-AZ-HM Power Supply 115V~60Hz Moisture removal 22.00pint/day 35.37pint/day 49.95pint/day Refrigerant R32/3.53oz R32/4.94oz R32/5.64oz Gross Weight 33.07lb 36.60lb 44.75lb Net Weight 30.86lb 33.73lb 41.45lb Dimension 15.94x8.86x16.97in 18.50x8.86x15.94in 18.82x9.92x20.04in... -
Page 28: Troubleshooting
Troubleshooting Before calling for service, review the chart below first yourself. Problem What to check Make sure the dehumidifier s plug is pushed completely into the outlet. Check the house fuse/circuit breaker box. Unit does not start Dehumidifier has reached its preset level or bucket is full. Water bucket is not in the proper position. -
Page 29: Warranty And Service
Warranty And Service This product is covered by a 12-month product and warranty from the date of initial purchase in case of any problems, please contact the Customer Service Center via the contact information listed in this User Guide. Our warranty covers replacement products by repairing or replacing any defective parts and labor necessary to bring it up to its original specifications, and we can provide a replacement product instead of repairing the defective product. - Page 32 CD001UI-DA 16120100A20695...
