AIR ANNEXE (MP9546) FOR CROSSED
DRIVEAWAY AWNINGS (MP9544 & MP9545)
USER GUIDE
Please read this user guide before attempting to set up your Air Annexe.
Follow the user guide carefully and keep for future reference.
A copy of the user guide is also available on our website
www.maypoleltd.com
1 |
P a g e
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MayPole MP9546
Summary of Contents for MayPole MP9546
- Page 1 AIR ANNEXE (MP9546) FOR CROSSED DRIVEAWAY AWNINGS (MP9544 & MP9545) USER GUIDE Please read this user guide before attempting to set up your Air Annexe. Follow the user guide carefully and keep for future reference. A copy of the user guide is also available on our website www.maypoleltd.com...
- Page 2 AIR ANNEXE (MP9546) FOR CROSSED DRIVEAWAY AWNINGS (MP9544 & MP9545) USER GUIDE WARNING – GENERAL SAFETY • Not to be used in strong winds and extreme weather conditions. • If using stepladders or a platform to set up the Air Annexe you will be working at height &...
- Page 3 Choose a clear site that is flat. Remove any sharp objects from the pitching area which could be dangerous or potentially damage the fabric or puncture the air tubes. NOTE – this Air Annexe is only compatible with the Maypole Crossed Air Driveway Awning for Campervans (MP9544) & Crossed Air Driveway Awning for Motorhomes (MP9545).
- Page 4 AIR ANNEXE (MP9546) FOR CROSSED DRIVEAWAY AWNINGS (MP9544 & MP9545) USER GUIDE Locate the air valve found on the air tube at the front of the Annexe. Insert the adaptor into the top cap on the air valve. Inflate the air beam to approx.6-7 PSI. Remove the adaptor from the valve and securely tighten the top cap.
- Page 5 AIR ANNEXE (MP9546) FOR CROSSED DRIVEAWAY AWNINGS (MP9544 & MP9545) USER GUIDE Once in position; peg down all of the guy ropes attached to the Annexe. It is recommended each peg is driven fully into the ground at an angle of 45 Degrees away from the pegging point.
- Page 6 AIR ANNEXE (MP9546) FOR CROSSED DRIVEAWAY AWNINGS (MP9544 & MP9545) USER GUIDE Attach the elasticated toggles to the rear air beam. Then attach the top 2 front buckles: Peg out the 2 pegging points found at the front of the inner tent.
