'STONELEIGH' POLED PORCH AWNING 390CM
MP9554 USER GUIDE
Please read this user guide before attempting to set up your Porch Awning.
Follow the user guide carefully and keep for future reference.
A copy of the user guide is also available on our website
www.maypoleltd.com
1 |
P a g e
Advertisement
Related Manuals for MayPole MP9554
Summary of Contents for MayPole MP9554
- Page 1 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE Please read this user guide before attempting to set up your Porch Awning. Follow the user guide carefully and keep for future reference. A copy of the user guide is also available on our website www.maypoleltd.com...
- Page 2 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE WARNING – GENERAL SAFETY • Not to be used in strong winds and extreme weather conditions. • If using stepladders or a platform to set up the Porch Awning you will be working at height &...
- Page 3 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE BEFORE USE Choose a clear site that is flat. Remove any sharp objects from the pitching area which could be dangerous or potentially damage the fabric. NOTE – this Porch Awning is suitable for vehicles with an awning channel height range of 235cm –...
- Page 4 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE Insert the fibreglass roof pole into the front sleeve. Pre-assemble both corner steel poles to the adjustable legs. Insert each end of the fibreglass roof pole into both corner steel poles. Attach the canopy to the steel poles using the plastic clips. Extend the adjustable legs on the steel corner poles to the maximum height.
- Page 5 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE Buckle together the sizing strap between each leg to achieve the correct spacing. Peg down each leg at the base and all pegging points to form the shape below: Once in position; peg down the 3 guy ropes found at the front of the awning and fully tension using the adjusters provided.
- Page 6 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE Steel rear padded poles are included to enable the awning to be firmly held against the vehicle. Pre-assemble the steel poles and secure to the rear corner foam pads with the velco attachments. The poles can be adjusted to suit the height of the vehicle.
- Page 7 ‘STONELEIGH’ POLED PORCH AWNING 390CM MP9554 USER GUIDE To attach the draught skirt; insert the beading into the bottom awning channel on the vehicle and slide to the desired position. Technical Manager Maypole Ltd Oct 2022 Email: sales@maypoleltd.co.uk Web: www.maypoleltd.com...
