FIS
FIBER OPTIC THERMAL STRIPPER
INSTRUCTIONAL MANUAL
FIS FIBER OPTIC THERMAL STRIPPER
Congratulations on the purchase of the new fiber optic thermal stripper. This product is optimized
to remove 900um or 250um buffer from one or two fibers at once or ribbon fiber in preparation of
cleaving a fiber for mechanical or fusion splicing. This tool is fast and great for new technicians.
1. Features a rugged all-metal body increasing the durabiity in the field or cable assembly shop.
2. Built-in rechargable lithium battery makes tool portable for many fiber optics applications.
3. Onboard (8) temperature level heating modes accommodate a variety for different buffer and
fanout kit furcation compounds to optimize fiber stripping environment and needs.
4. Fiber alignment tray squares buffer to blade for straight removal of jacket for connectorization.
5. Strip multiple fibers, standard tray can strip 2 fibers, optional ribbon alignment tray available.
Fiber Instrument Sales Inc.
161 Clear Road
Oriskany, NY 13424
315.736-2206
www.fiberinstrumentsales.com
PART NUMBER: F1-9998
Maximum Stripping Length
Optimized Fiber Stripping
Suitable Optical Fiber Cladding Diamater
Dimension (inches)
Stripping Width of the Blade Edge
Heating Temperature
Power
Weight
Automatic Shut Off Time
TOOL FUNCTIONS
Upper Cover
Silicone Pads
Stripping Blade
Heating Level Indicator
Heating Plate with
Temperature Level Mode Key
Measurement Scale (mm)
250µm Bare Fiber/900µm Buffer
125µm
4.68" L x 1.59" W x 1.22"H
o
150
C / 302
Adapter: DC 12V
Built-in Battery: 7.4V 3500mAh
0.54 lbs
6 minutes of Inactivity
Power On/Off &
Mode Switch Button
Power Save Lite
Heater On Light
Charging Port
32mm
20mm
o
F
