- Page 1 FIS E-Series Power Meter with Data Saving User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PAGE 1.0 Functions and Features ........ 1 2.0 Specifications ........... 1 3.0 Standard Configuration ........ 2 4.0 Function ............. 2 4.1 Front of OPM ..........2 4.2 Functions ........... 3 5.0 Operational Instruction ........ 3 5.1 Turn ON/OFF ..........3 5.2 Output Power Measurement ..... -
Page 3: Functions And Features
FIS E-Series Power Meter with Data Saving 1.0 Functions and Features • Optical power test • Wave ID — Auto wavelength identification & switching • Frequency ID — Auto frequency identification • 1000 records storage or download via USB cable •... -
Page 4: Standard Configuration
3.0 Standard Configuration Name Qty. Optical Power Meter User Manual USB cable Software CD 1.5V AA battery Cotton Swabs Carry Bag 4.0 Function 4.1 Front of the OPM... -
Page 5: Functions
4.2 Functions 1. Screen - Displays the data, units, and wavelengths being used while the instrument is working. Power Key - ON/OFF the instrument 3. Power Saving setting: the unit will automatically shut off after 15 minutes of idle time, no matter the condition of the battery power supply or the AC power supply. -
Page 6: Output Power Measurement
the “Auto-off” will display on the left bottom of the screen. On the “Auto-off” status, the OPM will turn off 10 minutes automatically. 3. If you want to turn off the OPM, long press about 2 seconds. 5.2 Output Power Measurement 1. -
Page 7: General Maintenance
6.0 General Maintenance • Always keep the connector ports of your power meter clean. • Do not use dirty optical fiber connectors/adaptors, otherwise, it will damage the interface of detector that will greatly affect the performance of the unit. • Try to use only the adaptor supplied. - Page 8 161 Clear Road Oriskany, NY 13424 Ph: 315.736.2206 Toll Free: 1.800.5000.FIS(347) Fax: 315.736.2285 www.fiberinstrumentsales.com email: info@fiberinstrumentsales.com...
