- Page 1 Operating and Installation Instructions Rangetops To prevent accidents and damage to the range, you must read all instructions supplied before installing or using the appliance. en-US, CA M.-Nr. 12 002 930...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or death. - Do not use or store gasoline or other combustible liquids or vapors in the vicinity of this or any other appliance. -
Page 3: Table Of Contents
Contents IMPORTANT SAFETY INSTRUCTIONS..............IMPORTANT SAFETY INSTRUCTIONS..............Guide to the Rangetop....................13 KMR 1124-3 ........................13 KMR 1134-3 ........................14 KMR 1135-3 ........................15 KMR 1136-3 ........................16 KMR 1354-3 ........................17 KMR 1355-3........................18 KMR 1356-3 ........................19 Control panel........................20 Burner knob........................ - Page 4 Contents Cleaning and care ......................31 Rangetop ......................... 32 Dishwasher-safe grates ................... 32 Burner control knobs with stainless steel finish ..........32 Simmer burner / Power burners ................32 Cleaning the dishwasher-safe grilling grate..............33 Cleaning the griddle plate ..................... 33 Frequently asked questions..................
-
Page 5: Appropriate Use
They contain important notes on installation, safety, use and maintenance. Miele cannot be held responsible for damage caused by the non- observance of these instructions. Keep these instructions in a safe place and pass them on to any future owner. -
Page 6: Safety With Children
Unauthorized installation, maintenance, and repairs can cause considerable danger for the user. Installation, maintenance, and repairs must only be carried out by a Miele authorized technician. Maintenance by the user: Never repair or replace any part of the appliance unless the instructions specifically recommend doing so. - Page 7 The function and operation of the protective measures provided in the domestic electrical installation and in this Miele product must also be maintained in isolated operation or in operation that is not synchronized with the grid power supply, or these measures must be replaced by equivalent measures in the installation.
- Page 8 Do not open the appliance housing under any circumstances. Any repairs not performed by a Miele authorized service technician will void the warranty. Defective components should be replaced by Miele original parts only.
-
Page 9: Correct Use
IMPORTANT SAFETY INSTRUCTIONS Correct use Do not leave the rangetop unattended when cooking on high power. Spilled food will begin to smoke and cause grease splatter, which can ignite on the range. Oil and fat can catch fire if overheated. Never leave the appliance unattended when cooking with oil and fat. - Page 10 IMPORTANT SAFETY INSTRUCTIONS The rangetop gets hot when in use and remains hot for some time after being turned off. Do not touch the appliance if there is a possibility that it could still be hot. You can burn yourself on a hot rangetop. When cooking on the appliance, protect your hands by using heat-resistant pot holders or oven mitts.
- Page 11 IMPORTANT SAFETY INSTRUCTIONS Install the burner grates in an upright position to avoid scratching the cooktop. Remove all grease splatters and other flammable (food) residues on the rangetop. They are a fire hazard. Do not use pots or pans that are large enough to cover several burners.
-
Page 12: Cleaning And Maintenance
IMPORTANT SAFETY INSTRUCTIONS The grates, burner cap, bottom parts of the burner, and any other parts located near the burner flame, can still be very hot after cooking and cause burns. Do not touch these components when using the rangetop. -
Page 13: Guide To The Rangetop
Guide to the Rangetop KMR 1124-3 a Burner control knob for rear left e Power burner burner f Grates b Burner control knob for front left g Simmer burner burner c Burner control knob for front right burner d Burner control knob for rear right burner... -
Page 14: Kmr 1134-3
Guide to the Rangetop KMR 1134-3 a Burner control knob for rear left f Burner control knob for rear right burner burner b Burner control knob for front left g Power burner, front burner h Power burner, rear c Burner control knob for front center i Simmer burner burner j Grates... -
Page 15: Kmr 1135-3
Guide to the Rangetop KMR 1135-3 a Burner control knob for rear left g Power burner, rear burner h Thermostatically controlled ceramic b Burner control knob for front left burner burner i Grill c Control knob for grill j Grates d Burner control knob for front right k Simmer burner burner... -
Page 16: Kmr 1136-3
Guide to the Rangetop KMR 1136-3 a Burner control knob for rear left g Power burner, rear burner h Griddle plate b Burner control knob for front left i Thermostatically controlled ceramic burner burner c Control knob for griddle plate j Grease drip tray d Burner control knob for front right k Grates... -
Page 17: Kmr 1354-3
Guide to the Rangetop KMR 1354-3 a Backlit burner control knob for rear g Backlit burner control knob for front left burner right burner b Backlit burner control knob for front h Backlit burner control knob for rear left burner right burner c Backlit burner control knob for rear i Power burner, front... -
Page 18: Kmr 1355-3
Guide to the Rangetop KMR 1355-3 a Backlit burner control knob for rear h Power burner, front left burner i Simmer burner b Backlit burner control knob for front j Power burner, rear left burner k Thermostatically controlled ceramic c Backlit control knob for grill burner d Backlit burner control knob for front l Grill... -
Page 19: Kmr 1356-3
Guide to the Rangetop KMR 1356-3 a Backlit burner control knob for rear h Power burner, front left burner i Simmer burner b Backlit burner control knob for front j Power burner, rear left burner k Griddle plate c Backlit control knob for griddle plate l Thermostatically controlled ceramic d Backlit burner control knob for front burner... -
Page 20: Control Panel
Control panel Automatic re-ignition Burner knob Your rangetop is equipped with an With the burner knob, you can ignite the automatic re-ignition function. If the burner and regulate the flame. The flame goes out, e.g. because food has burners can be variably adjusted cooked over or there has been an air between the lowest and highest draft, the flame is automatically re-... -
Page 21: Before First Use
Before first use Cleaning the rangetop for the Seasoning the griddle plate first time You must season the griddle plate Remove any protective foil and before cooking food on it the first time. stickers. This process prevents food from sticking and protects the surface from ... -
Page 22: Operation Of The Burners
Operation of the burners Switching on during a power Fire hazard due to overheated outage food. Unattended food can overheat and If there has been a power failure, ignite. the automatic re-ignition feature will Do not leave the cooktop unattended not work properly. -
Page 23: Adjusting The Flame
Operation of the burners Visual features of gas flames Adjusting the flame The burners can be variably adjusted Yellow flames between the lowest and highest flame Call Customer settings. Service. Because the edges of the flame are much hotter than its center, the flame tips should stay beneath the bottom of the cookware. - Page 24 Operation of the burners Simmer/Power burner Knob label Description Gas supply is off: Burner off High Strongest flame setting: Maximum power of upper and lower flame rings Simmer Weakest flame setting: Upper flame ring off Minimum power of lower flame ring Grill: Ceramic burner According to the model, the range has a grill.
-
Page 25: Cookware
Cookware - Select cookware that fits the size of - All heat-resistant cookware is suitable the burner: for use. Large diameter = large burner - Cookware with a thick bottom is Small diameter = small burner preferable, as it distributes heat more - Using cookware that is too large can evenly. -
Page 26: Energy Saving Tips
Energy saving tips - Whenever possible, keep pots and pans covered while cooking. Doing so will prevent unnecessary heat loss. - Wide, shallow cookware heats up faster and is therefore preferable to tall, narrow cookware. - Cook with as little water as possible. - Reduce the power setting once the water has come to a boil or the oil/fat is hot enough for frying. -
Page 27: Operation Of The Grill
Operation of the grill The grill has a ceramic burner that Place the radiant plate on top of transfers intense heat to food, searing the frame . the outside to seal the juices. Full flexibility, depending on the food, from “Low”... -
Page 28: Turning On The Grill
Operation of the grill Turning on during a power outage Turning on the grill Danger of injury due to the Always follow USDA guidelines on food safety. manual ignition of the flat burner during a power failure! Press the control knob of the grill and Never operate the grill during a turn it counterclockwise to “High.”... -
Page 29: Operation Of The Griddle
Operation of the griddle The griddle is thermostatically Turning on during a power controlled to maintain a consistent outage temperature. To prevent food from sticking, it is necessary to “season” the The griddle plate cannot be operated griddle prior to use (see “Before using in case of a power failure. -
Page 30: Tips For Frying
Operation of the griddle Tips for frying Before each use, wipe the griddle with a damp cloth to remove dust or other residue. - Pre-heat the griddle plate thoroughly for 8 -10 minutes at the power level that you are going to be using for cooking. -
Page 31: Cleaning And Care
Cleaning and care Always clean the rangetop after each Danger of burns! use. Allow it to cool down before The burners must be turned off and cleaning. the rangetop must be cooled. To better maintain your appliance avoid the following: ... -
Page 32: Rangetop
Cleaning and care Burner control knobs with stainless Rangetop steel finish The surfaces of the burner The burner control knobs may become components and grates will slightly discolored if they are not cleaned lose their luster over time. This is regularly. -
Page 33: Cleaning The Dishwasher-Safe Grilling Grate
Remove any soiling and water with a sponge. You can clean stubborn soiling off the griddle plate with the rough side of a dish sponge and a few drops of Miele ceramic and stainless steel cleaner (see “Optional accessories”). Remove the grease catch pan and... -
Page 34: Frequently Asked Questions
You can save time and money in many cases, as you do not need to contact Miele Customer Service. Information to help you rectify faults yourself can be found at www.miele.com/ service. The following tables are designed to help you to find the cause of a malfunction or a fault and to resolve it. - Page 35 Frequently asked questions Problem Possible cause and solution The shape/color of the The burner parts are not in the proper position. gas flame changes. Position the burner parts correctly. The burner cap itself or the holes in the burner cap are dirty.
-
Page 36: Notes On Installation
*INSTALLATION* Notes on installation Distance to the range hood The minimum clearance between the appliance and a range hood above will be listed by the hood manufacturer. If there is more than one appliance installed below the range hood, each with a different safety clearance, the largest clearance must be used. -
Page 37: Weights
*INSTALLATION* Notes on installation Weights The net weight of the rangetop with accessories is as follows: Model Width Net weight including grates and burner caps KMR 1124-3 29 ¹⁵/₁₆" (762 mm) approx. 100 lbs / 45 kg KMR 1134-3 approx. 120 lbs / 55 kg KMR 1135-3 35 ¹⁵/₁₆"... -
Page 38: Dimensional Drawings
*INSTALLATION* Dimensional drawings a Side view d Gas connection b Front views e Electrical connection c Rear view... -
Page 39: Rangetops Kmr 1124-3, Kmr 113X-3, Kmr 135X-3
*INSTALLATION* Dimensional drawings Rangetops KMR 1124-3, KMR 113x-3, KMR 135x-3 Positio Dimensions Description 13" (330 mm) Maximum depth of top cabinet 18" (457 mm) Minimum distance to bottom edge of top cabinet 7¹/₂" (190.5 mm) Distance between the top edge of the countertop ... - Page 40 Please observe safe distances to rear combustible surfaces of 12" (305 mm) clearance. For zero clearance installation the Miele Backguards will satisfy the required distance to combustible surfaces. The Miele Backguard is available in 12" (305 mm) or 20" (508 mm) heights. KMR 1134-3...
- Page 41 Please observe safe distances to rear combustible surfaces of 12" (305 mm) clearance. For zero clearance installation the Miele Backguards will satisfy the required distance to combustible surfaces. The Miele Backguard is available in 12" (305 mm) or 20" (508 mm) heights. KMR 1354-3, KMR 1355-3, KMR 1356-3...
-
Page 42: Electrical Connection
Miele product must also be cause considerable danger to users. maintained in isolated operation or in Miele cannot be held liable for any operation that is not synchronized with damage arising as a result of such the grid power supply, or these work. -
Page 43: Gas Connection
*INSTALLATION* Gas connection The gas hose and power cord could be Connection to the gas supply damaged by hot spots on the may only be performed by a duly rangetop. authorized technician. This technician Make sure that the gas hose and is responsible for proper function at power cord do not come into contact the installation site. - Page 44 *INSTALLATION* Gas connection The gas connection must be made in accordance with local codes or, in the absence of local codes, with: National Fuel Gas Code ANSI Z 223.1 / NFPA No. 54 for the United States or the current Can / CGA B 149.1 and 2 Installation Codes of Gas Appliances for Canada.
-
Page 45: Burner Ratings
Burner ratings Burner ratings KMR 1124-3 Natural gas NG Btu/hr Simmer burner 12,500 Power burner 19,500 Total cooktop output 71,000 20.8 Liquid propane LP Btu/hr Simmer burner 12,500 Power burner 19,500 Total cooktop output 71,000 20.8 Burner ratings KMR 1134-3 Natural gas NG Btu/hr Simmer burner... -
Page 46: Burner Ratings Kmr 1136-3
Burner ratings Burner ratings KMR 1136-3 Natural gas NG Btu/hr Simmer burner 12,500 Power burner, rear 13,600 Power burner, front 19,500 Griddle 13,000 Total cooktop output 78,100 22.9 Liquid propane LP Btu/hr Simmer burner 12,500 Power burner, rear 13,000 Power burner, front 19,500 Griddle 13,000... -
Page 47: Burner Ratings Kmr 1355-3
Burner ratings Burner ratings KMR 1355-3 Natural gas NG Btu/hr Simmer burner 10,000 Power burner, rear 13,600 Power burner, front 19,500 Grill 19,000 Total cooktop output 111,100 32.6 Burner ratings KMR 1356-3 Natural gas NG Btu/hr Simmer burner 10,000 Power burner, rear 13,600 Power burner, front 19,500... -
Page 48: Customer Service
Contact in the event of a fault In the event of a fault which you cannot remedy yourself, please contact your Miele dealer or Miele Customer Service. You can book a Miele Service Call online at www.miele.com/service. -
Page 49: Caring For The Environment
Consult with local authorities, dealers or Miele in order to dispose of and recycle electrical and electronic appliances. Miele assumes no responsibility for deleting any personal data left on the appliance being disposed. - Page 51 Customer Service. U.S.A. Canada Miele, Inc. Importer Miele Limited National Headquarters Headquarters and Miele Centre 9 Independence Way 161 Four Valley Drive Princeton, NJ 08540 www.mieleusa.com Vaughan, ON L4K 4V8 www.miele.ca Customer Support Phone: 888-99-MIELE (64353) Customer Care Centre info@mieleusa.com...
- Page 52 KMR 1124-3, KMR 1134-3, KMR 1135-3, KMR 1136-3, KMR 1354-3, KMR 1355-3, KMR 1356-3 en-US, CA M.-Nr. 12 002 930 / 02...
