GLUTE & HAMSTRING MACHINE
(4)
(4)
FOOT
FOOT
PLATE
PLATE
BODY
BODY
SLIDE
SLIDE
(2)
(2)
NOTE:
LOCATION OF (3) HAND KNOBS.
KNOBS MUST BE TIGHT PRIOR TO
USING, MACHINE TO PREVENT
MOVEMENT.
C-82626-W
FOOT CATCH
FOOT CATCH
PAD MOUNT
PAD MOUNT
(2)
(2)
BASE
BASE
(1)
(1)
Page - 1 of 3
PAD
PAD
(3)
(3)
(1)
(1)
THIS EQUIPMENT
DESIGNED BY TDS IN USA
MANUFACTURED IN CHINA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for TDS C-82626-W
Summary of Contents for TDS C-82626-W
- Page 1 PAD MOUNT BODY BODY SLIDE SLIDE BASE BASE NOTE: LOCATION OF (3) HAND KNOBS. KNOBS MUST BE TIGHT PRIOR TO THIS EQUIPMENT USING, MACHINE TO PREVENT DESIGNED BY TDS IN USA MOVEMENT. MANUFACTURED IN CHINA Page - 1 of 3...
- Page 2 C-82626-W GLUTE & HAMSTRING MACHINE PACKING LIST FOOT PLATE PAD MOUNT 1PC POST 1PC BODY 1PC BASE 1PC FOOT FOOT CATCH 1PC CATCH 1PC SLIDE PAD 2 PCS 4 X 8 CUSHION HARDWARE 1 PKG 4 PCS LITERATURE 1 PKG...
- Page 3 C-82626-W GLUTE AND HAMSTRING MACHINE ASSEMBLY INSTRUCTIONS THIS UNIT REQUIRES (1) 9/16 WRENCH AND (1) 11/16 WRENCH FOR ASSEMBLY. DO NOT TIGHTEN HARDWARE UNTIL INSTRUCTED TO. (1) PUSH (4) 2 X 4 FOOT ONTO BASE. ATTACH POST TO BASE WITH (2) 3/8 X 3 BOLTS, (1) 3/8 X 5 BOLT, (6) 3/8 FLAT WASHERS AND (3) 3/8 LOCKNUTS.
