Sony TC-800 Servicing Manual

For U.S. A.
Power requirement :
Track :
Reel :
Tape speed:
Recording time:
(with 900' (275 m) tape
Transistor :
Diode :
Frequency response :
Bias frequency :
Motor :
Speaker :
Power output:
Input Jack :
Output Jack:
Other Jack:
Power consumption :
Battery life:
Dimension :
Weight :
Accessories :
Optional accessories :
Specifications
DC 12
AC 117V 60¢/s
Dual
13 cm (5") or smaller
19 cm/s (7-1/2 ips), 9.5 cm/s (3-3/4 ips), 4.75 cm/s (1-7/8 ips)
1.5 hours in total at 9.5cm/s (3-3/4 ips)
3 hours in total at 4.75 cm/s (1-7/8 ips)
14
11
50~18,000 c/s at 19 cm (7-1/2 ips)
50~13,000 c/s at 9.5cm/s (3-3/4 ips)
50~7,000 c/s at 4.75 cm/s (1-7/8 ips)
Approx. 55 ke
D-503F DC Motor
8%16cm (3-1/8 6-1/4") dynamic
Max. 1 watt
Microphone (1) Sensitivity 0.195 mV
Auxiliary (1) Sensitivity 0.055 V
Monitor (1) Sensitivity 0.775 V
Remote control (1)
Speed control (1)
AC 6W
6.5 hours recording with supplied batteries
322 (W) X 107 (H) X 261 mm (D) (12-1/4 x 4-1/5 10-1/4" }
5.4kg (11 Ibs. 13 ozs.) with battery
SONY Cardioid microphone F-85, ''D!" — © NI Yo
——
Impedance 600 ohms
Impedance 100k ohms
Impedance 10k ohms
size super batteries, 5" empty reel,
Power supply cord, Connection cord,
Earphone
Speed slow-down control RM-5, Car
battery cord DCC-2AW, Carrying case
