Auvidea Hailo 15H Trinity Kit Quick Start Manual

Hailo 15H Trinity Kit
Quickstart guide
Each kit includes the following:
•
H100 Hailo 15H compute module
•
HM10 Hailo 15H memory board
•
HC10 interface adapter
•
BE323 Ethernet adapter with PoE
•
Aluminum heat spreader
•
Picoblade cable (10 pin, 1:N)
•
32GB micro SD card (Auvidea Yocto Linux installed on SD card)
•
Auvidea u-boot bootloader installed on QSPI Flash
Preconfiguration of the Hailo 15H system (the system is completely prepared, no installation required):
Static IP
Netmask
User
Password
Troubleshooting:
•
It is highly recommended to make a backup copy of the SD card before editing it
•
If the power LED on the bottom of the HC10 is not glowing, there is a problem with the PoE
connection
•
If the MCU LED is not flashing, but the PoE LED is glowing, there is a defect on the board
•
IF both LEDs light up as intended, but you are still having trouble, it is likely that there is
something wrong with the network settings or the SD card. In this case use your backup of the
SD card.
Backing up the SD card to the host:
cd ~
mkdir hailo-images
cd hailo-images
sudo dd if=/dev/sdb of=~/hailo-images/hailo15-trinity-20250127.wic
bs=4M count=625 status=progress
sync
<Eject>
Restoring the SD card from the host:
sudo dd if=~/hailo-images/hailo15-trinity-20250127.wic of=/dev/sdb
bs=4M status=progress
sync
<Eject>
Commissioning a Linux system:
1. Connecting the hardware:
•
Attach the heat spreader to the heatsink or use a 2mm aluminum plate (not included) secured
with 2x M3 screws.
•
Connect the RJ45 port to a PoE network switch using a network cable
2. System boot:
•
A green LED on the HM10 module blinks (see side of the ethernet connector)
•
The system boots within 20 seconds
3. Network configuration:
•
Disable DHCP on the host system and set a static IP
Auvidea GmbH
Egart 5
D-86920 Denklingen / Germany
192.168.100.136
255.255.255.0
root
root
Copyright 2025 Auvidea GmbH
v1.2 Jan 2025
www.auvidea.com
