- Page 1 Instruction Manual YHQ80 Series Explosion-proof PTZ Dome Camera Station...
-
Page 2: Copyright Statement
Cooper Yuhua remains the right to modify the content and technical specifications of the product in this Instruction Manual without any form of notification, in order to provide the newest and most advanced product. The end users can get the latest product information on Yuhua’s website: www.eaton.com/yuhua-cctv EATON www.eaton.com... -
Page 3: Quality Guarantee
Damage caused by improper installation or operation and not in • accordance with this instruction manual. Damage caused by unauthorized disassembly. • Thunder or other force majeure natural disasters. • If any other contracts between clients and us exist, we will follow the promise or regulation strictly. EATON www.eaton.com... -
Page 4: Notice
The internal and external grounding shall be reliable. • Ensure the installation is firm and reliable, to avoid unexpected • damage of the camera. Protect the flame-proof joints from stumble and crack in • installation, operation and maintenance. EATON TMY0035 December 2024 www.eaton.com... -
Page 5: Table Of Contents
4.1 Cautions in hoisting and transportation ................... 13 4.2 Storage condition, duration and cautions ................13 Annex 1: Table of poisonous and harmful substances or elements ..........14 Annex 2: Use of drying agent ......................15 EATON TMY0035 December 2024 www.eaton.com... -
Page 6: Safety Requirement
The product shall be well packaged as new product or • equivalent in transmission. We suggest using this product with Surge Protection Devices. • Internal and external grounding shall be reliable. • EATON TMY0035 December 2024 www.eaton.com... -
Page 7: Ex Structure Instruction
All associated technical document, drawings and samples of When the ordered configuration is non ex version please disregard YHQ80 series explosion-proof integrated camera are tested and the sections related to ex instruction in the manual. certified by DNV Product Assurance AS, the certification numbers are DNV 24 ATEX 64079X, IECEx DNV 24.0007X. -
Page 8: Features
Certificate IECEx DNV 24.0007X, DNV 24 ATEX 64079X numbers: Features YHQ80 series explosion-proof PTZ dome camera set integrates high-performance colour camera, omnibearing variable speed PTZ, multifunction decoder controller, and also common communication Figure 1.4.1.2 YHQ80 Wall Mount Dimensions (in mm) protocols and speed. -
Page 9: Electrical Data
100 MΩ; Voltage withstand test: adopt voltage of 1500V, 50Hz at the power in terminals and the enclosure for one minute, with no breakdown or arcing. EATON TMY0035 December 2024 www.eaton.com... -
Page 10: Installation & Debugging
100~240VAC, or 24VAC/DC, it’s recommended to use for default IP address, user, and password can be found on the label transmission range shorter than 100 meters, refer to the wiring sticker applied onto camera housing diagram 2.9.1.2. EATON TMY0035 December 2024 www.eaton.com... -
Page 11: Camera With Cable Tail
Alarm output + (Normal opened) RJ45 Blue/white Alarm output - (Normal opened) POE signaling input Brown Audio output DC12V Brown/white Not applicable PoE Splitter YHQ80 with Ethernet output as standard version INPUT OUTPUT Figure 2.9.1.4 EATON TMY0035 December 2024 www.eaton.com... -
Page 12: Troubleshooting
Figure 3.1.1 Minitoring image display window When encountering this situation, please right-click on the desktop, select ‘Display Settings,’ and set the ‘Change the size of text, apps, and other items’ option to 100%, refer to 3.1.2. Figure 3.1.2 Display Settings EATON TMY0035 December 2024 www.eaton.com... -
Page 13: Transportation And Storage
Storage condition, duration and cautions This product can be stored for one year in an environment with a temperature range of 0℃~+40℃ and humidity not exceeding 90%. EATON TMY0035 December 2024 www.eaton.com... -
Page 14: Annex 1: Table Of Poisonous And Harmful Substances Or Elements
Treatment of this poisonous, harmful substances or elements can not carried out by user selves, please deliver it to the appointed department according to the local laws or regulation. EATON TMY0035 December 2024 www.eaton.com... -
Page 15: Annex 2: Use Of Drying Agent
A package of drying agent is provided with accessories. Put the drying agent inside the chamber after it’s well installed and wired. The place of drying agent put shall be away from the transmission element or electrical connection zone and difficult to slip to other places, avoid any connection fault or transmission fault caused by drying agent. EATON TMY0035 December 2024 www.eaton.com... - Page 16 Technical Data TMY0035 A Effective December 2024 CONFIDENTIAL — For internal use only by Eaton and Eaton authorized distributors. No.189 Liuyanghe Rd Xinbei District This information is intended to provide a Changzhou 213031 comparative analysis between Eaton’s Jiangsu, China products and those of other manufacturers...
