SMARTWINGS WM25L/V Product Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SmartWings Window Covering
Advanced Information Product Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WM25L/V and is the answer not in the manual?

Questions and answers

Related Manuals for SMARTWINGS WM25L/V

Summary of Contents for SMARTWINGS WM25L/V

  • Page 1 SmartWings Window Covering Advanced Information Product Manual...
  • Page 3 Engineering Specification – Z-Wave® Product Line Version Description This document mainly introduces the new generation SmartWings Window Covering. The content mainly includes its interfaces, accessories, features, specifications, quick start, and software function definition. This device is a security enabled Z-Wave Plus® v2 product that is able to use encrypted Z-Wave Plus v2 messages to communicate to other security S2 enabled Z-Wave Plus v2 products.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS 1. INTERFACES & INSTALLATION.......1 2. FEATURES & SPECIFICATIONS.......2 ........2 2.1 Structural Characteristics ........2 2.2 Hardware Characteristics ........3 2.3 Software Characteristi cs 3. PRODUCT QUICK START........4 ......4 3.1 Important safety information ..........4 3.2 A bout Z W ave ..........4 3.3 A bout SmartStart .......4...
  • Page 5 ..........9 4.4 ZWAVEPLUS_INFO ........10 4.5 Manufacturer Specific ............10 4.6 Version ........11 4.7 Association Group Info ..........11 4.8 Multilevel Switch ...........12 4.9 Window Covering ..........13 4.10 Notification ............13 4.11 Battery .............13 4.12 Indicator ..........14 4.13 Configuration...

  • Page 6: Interfaces & Installation

    INTERFACES & INSTALLATION Config Button QR Code Terminology Description Indicates Z-Wave network status Config Button Z-Wave network settings or Restore factory settings 2D barcode format that can contain large amounts of information in a small QR Code square of encoded blocks resembling a random checkerboard pattern. In Z-Wave, it is used to represent the S2 public part of the DSK on a device, as well as additional information needed for the inclusion process...

  • Page 7: Features & Specifications

    FEATURES & SPECIFICATIONS 2.1 Structural Characteristics Parameter Value Product Identifier SmartWings Smart Motor Dimensions 515*55*55mm White Color Usage For indoor use. Operating Temperature 32-104°F (0-40°C) Up to 80% Relative Humidity 2.2 Hardware Characteristics Parameter Value Z-Wave Module EFR32ZG23A010F512GM40 Z-Wave TX Power...

  • Page 8: Software Characteristics

    FEATURES & SPECIFICATIONS 2.3 Software Characteristics Parameter Value Wireless Technology Z-Wave Certification Type Z-Wave Plus v2 Z-Wave SDK Version 7.18.08 Z-Wave Library Type Enhanced 232 Slave Z-Wave Role Type ZWAVEPLUS_INFO_REPORT_ROLE_TYPE_SLAVE_SLEEPING_LISTENING (0x07) GENERIC_TYPE_SWITCH_MULTILEVEL (0x11) Generic Device Type SPECIFIC_TYPE_CLASS_C_MOTOR_CONTROL (0x07) Specific Device Type Support.

  • Page 9: Product Quick Start

    PRODUCT QUICK START 3.1 Important safety information Please read this Engineering Specification carefully for correct and effective use. Failure to follow the recommendations set forth by DEYI Limited may be dangerous or cause a violation of the law. The manufacturer, importer, distributor, and/or reseller will not be held responsible for any loss or damage resulting from not following any instruction in this guide or in other materials.

  • Page 10: How To Add The Product Into Z-Wave Network

    PRODUCT QUICK START 3.5 How to add the product into Z-Wave network Follow the user guide of hub to enter inclusion mode. Pairing Method 1: 1. Remove the back cover of the remote. 2. Briefly press the P button until the motor jogs once. 3.

  • Page 11: How To Remove The Product From Z-Wave Network

    PRODUCT QUICK START 3.6 How to remove the product from Z-Wave network Follow the user guide of hub to enter exclusion mode. Pairing Method 1: 1. Remove the back cover of the remote. 2. Briefly press the P button until the motor jogs once. 3.

  • Page 12: How To Factory Reset

    PRODUCT QUICK START 3.7 How to factory reset 1. Please use this procedure only when the network primary controller is missing or otherwise inoperable. 2. Remove the back cover of the remote. 3. Briefly press the P button until the motor jogs once. 4.

  • Page 13: Software Function Definition

    SOFTWARE FUNCTION DEFINITION 4.1 User Behavior Interaction User behavior Out of the Z-Wave network In the Z-Wave network Power on Send Inclusion Requests for SmartStart Inclusion networkPress and hold the Inclusion network Config Button more than 6s, enter "Include mode" Press and hold the Config Button Exclusion network more than 6s, enter "Exclusion...

  • Page 14: Basic Command Class Mapping

    SOFTWARE FUNCTION DEFINITION COMMAND_CLASS_MANUFACTURER_SPECIFIC_V2 Highest granted Security Class COMMAND_CLASS_DEVICE_RESET_LOCALLY_V1 Highest granted Security Class COMMAND_CLASS_BATTERY_V1 Highest granted Security Class Highest granted Security Class COMMAND_CLASS_POWERLEVEL_V1 Highest granted Security Class COMMAND_CLASS_FIRMWARE_UPDATE_MD_V5 COMMAND_CLASS_MULTI_CHANNEL_ASSOCI Highest granted Security Class ATION_V3 COMMAND_CLASS_INDICATOR_V3 Highest granted Security Class 4.3 Basic Command Class mapping Basic Command maps to Switch Multilevel Command Class, as shown below.

  • Page 15: Manufacturer Specific

    SOFTWARE FUNCTION DEFINITION 4.5 Manufacturer Specific The Command is used to advertise manufacturer specific information. Parameter Value Manufacturer ID 1 0x04 Manufacturer ID 2 0x5A Product Type ID 1 0x00 Product Type ID 2 0x04 0x05 Product ID 1 Product ID 2 0x0B 4.6 Version The Command may be used to obtain the Z-Wave library type, the Z-Wave...

  • Page 16: Association Group Info

    SOFTWARE FUNCTION DEFINITION 4.7 Association Group Info The Command is used to manage associations to Node ID destinations. Endpoint Root: Name Count Profile Function Basic Report(0x2003): General: Lifeline Issued when motor status changed Lifeline (Configurable by param 11). (0x0001) Switch Multilevel Report(0x2603): Issued when motor status changed (Configurable by param 11).

  • Page 17: Window Covering

    SOFTWARE FUNCTION DEFINITION 3. Switch Multilevel Start Level Change This is the command which user can move the Curtain up to the top or down to the bottom. If Up/Down Bit=0x00 Curtain move up. If Up/Down Bit=0x01 Curtain move down. Note: The Curtain will Ignore Start Level、Start Level、Dimming Duration、Inc/Dec、Step size.

  • Page 18: Notification

    SOFTWARE FUNCTION DEFINITION 4.10 Notification The Command is used to advertise events or states, such. Notification Type = Power Management (0x08) Table 4-10-1: Notification Description Alarm type Alarm Level Parameters Event AC mains disconnected 0x02 0x00 0x00 0x03 AC mains re-connected 0x03 0x00 0x00...

  • Page 19: Configuration

    SOFTWARE FUNCTION DEFINITION 4.13 Configuration The Command allows product specific configuration parameters to be changed. Note: No Bulk Support equals to True. It will return an Application Rejected Request Command when receiving Configuration Bulk Set or Get (if received without Supervision encapsulation).
  • Page 20 SOFTWARE FUNCTION DEFINITION Parameter 2: Parameter 0x02 (2) Name Set motor direction Info Set motor direction Size Min Value Properties Format Enumerated Max Value Read-only False Default Value False Advanced False Altering capabilities This parameter can be used to set the motor rotation direction. Description Value Function...
  • Page 21 SOFTWARE FUNCTION DEFINITION Parameter 4: This type of motor does not support this function， don't need to test it. Parameter 0x04 (4) Name Manually set close borders Info Manually set close borders Size Min Value Properties Format Enumerated Max Value Read-only False Default Value...
  • Page 22 SOFTWARE FUNCTION DEFINITION Parameter 6: Parameter 0x06 (6) Name Calibration the travel point Info Calibration the travel point Size Min Value Properties Format Enumerated Max Value Read-only False Default Value False Advanced Altering capabilities False Calibration the travel point. Description Value Function Up travel point.
  • Page 23 SOFTWARE FUNCTION DEFINITION Parameter 8: Parameter 0x08 (8) Name Low battery level alarm threshold Info Low battery level alarm threshold Size Min Value Properties Format Enumerated Max Value Read-only False Default Value False Advanced Altering capabilities False Configure low battery report threshold, sends low battery report via Description battery report when battery level drops under setting.
  • Page 24 SOFTWARE FUNCTION DEFINITION Parameter 10: Parameter 0x0A (10) Name Battery change report threshold Info Battery change report threshold Size Min Value Properties Format Enumerated Max Value Read-only False Default Value False Advanced Altering capabilities False Battery change auto report threshold. Description Value Function...
