- Page 1 Quick Installation Guide Drapery INS-102-C034 A-06 June 2024...
- Page 2 Single Rod kit with Valance Single Rod kit Double Rod kit with Valance Double Rod kit...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Track Splicing.............4 2. Fabric Hook Installation........9 3. Track Installation..........10 ..........10 3.1 Ceiling Mount ..........14 3.2 Wall Mount 4. Valance Installation........17 5. Motor Installation..........18 6. Fabric Installation...........19 7. Remote Holder Installation......20... - Page 4 Single Rod kit accessory list: Single Rod kit Extension Bracket...
- Page 5 Double Rod kit accessory list: double rod kit extension bracket...
- Page 6 Ceiling Mount Double rod kit Single rod kit Wall Mount Double rod kit Single rod kit...
-
Page 7: Track Splicing
Track Splicing Peel off the protective plastic film from both ends of the track. If the track length is less than 98.4"(2500mm), this step can be skipped and please turn to page 9 because tracks under 98.4"(2500mm)remain as one piece without the need for joining. For tracks longer than 98.4"(2500mm), refer to page 3 for guidance, as they will be cut into 2 pieces. - Page 8 Fig 1-d Fig 1-e 3. Put the belt buckle and overlap arm into the track (Fig 1-f ), please align the combined belt buckle and overlap arm with the designated position on the track (Fig 1-g), and then slide into the track (Fig 1-h). Fig 1-f Fig 1-g Fig 1-i...
- Page 9 4. Now you will splice the overlap arm and the slip part on the track, pull the overlap arm and the slip part by hand to put them together(Fig 1-j), and after joining them (Fig 1-k), the two pieces of track will automatically move closer together (Fig 1-l). Fig 1-j Fig 1-k Fig 1-l...
- Page 10 Fig 1-m Fig 1-n Fig 1-o Fig 1-p Fig 1-q Step 2 Loosen Screws 1. Loosen the four screws on the track joint bracket connecting the two tracks. Fig 1-r Step 3 Align Tracks 1. Flip the track over and align the two tracks. Fig 1-s...
- Page 11 Step 4 Adjust Position 1. Slide the track joint bracket to the point where the two tracks disconnect. Aim to center the bracket at the disconnect point. Fig 1-t Step 5 Tighten Screws 1. Flip the drapery back and tighten the four screws securely. Fig 1-u...
-
Page 12: Fabric Hook Installation
(this step cannot be installed after the track is secured to the ceiling (next step)). Fig 2-a Fig 2-b With Fabric Hook Method 1 Method 2 Method 1 Method 2 Single rod kit Double rod kit Fig 2-c1 Fig 2-c2 Without Fabric Hook Fig 2-d... -
Page 13: Track Installation
Track Installation Choose between ceiling or wall installation for your drapery. If installing on the ceiling, fixed brackets should be used, then the installation steps refer to page 10. For wall installation, install both fixed brackets and extension brackets according to page 14. Ceiling Mount Install the track, the fixed brackets should be used. - Page 14 Step 2 Install track to the Wall Single rod kit with valance installation method: Tips: Leave at least 10cm of space for single rod kit installation. 1. Mark the holes for securing the brackets. Keep the brackets parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed...
- Page 15 Double Rod kit with valance Installation method: Tips: Leave at least 18cm of space for double rod kit installation. 1. Mark the holes for fixing the brackets. Ensure the brackets are parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed bracket. Maintain a distance of at least 8cm from the middle hole of the first fixed bracket to the holes of the second fixed bracket.
- Page 16 When you have the curtain box Tips: The internal width of the curtain box should be at least 18cm. 1. Mark the holes for securing the brackets. Ensure the brackets are parallel. Maintain a distance of at least 6cm from the wall corner to the middle hole of the first fixed bracket .
-
Page 17: Wall Mount
Track Installation Wall Mount Install the drapery on the wall, extension brackets should be used. （Single rod kit exrension brackets） Fig 3.2-a Step 1 Install the Extension Bracket Single rod kit Step 1: Draw a horizontal line at the appropriate position to ensure the brackets are parallel. - Page 18 Install the drapery on the wall, extension brackets should be used. （Double rod kit extention brackets） Fig 3.2-b Install the Extension Bracket Double rod kit Step 1: Draw a horizontal line at the appropriate position to ensure the brackets are parallel. Step 2: Mark the hole positions on the brackets to keep them level.
- Page 19 Step 2 Install track to Extension Bracket Single rod kit Rotate the lower metal buckle of the fixed bracket clockwise to the right. Snap the bracket onto the track. Return the metal buckle to its original position. Tighten the screws securely, ensuring they are firmly in place.
-
Page 20: Valance Installation
Install valance fixed bracket by putting screw in mounting hole and using bolt to Lock. The installation method for double rod kit is the same as for single rod kit Fig 4-b Fig 4-a Step 2 Insert the valance fixed sticker You can bend the valance fixed sticker with the help of the hard object so that it can better... -
Page 21: Motor Installation
Motor Installation Pull down and forward of the knob located under the motor to unlock it. Align the holes at the end of the track and insert the motor. Turn the pull knob back to its original position to securely lock the motor in place. -
Page 22: Fabric Installation
Fabric Installation Match the hooks on the drapery fabric with the hanging wheels on the track one by one. Additionally, you have the flexibility to fine-tune the drapery by adjusting the hooks up or down. Fig 6-a Fig 6-b Fig 6-c... -
Page 23: Remote Holder Installation
Remote Holder Installation...
